Z: Tape and reel packing (picked from the 6/7/8/9/10-pin side)
Notes: 1. *48 V coil type: Single side stable only
2. In case of 5 V transistor drive circuit, it is recommended to use 4.5 V type relay.
–1–
ASCTB14E 201407-T
TQ
TYPES
■
Standard PC board terminal and self-clinching terminal
1. Standard (B.B.M.) type
1) Standard PC board terminal
Contact
arrangement
Nominal coil
voltage
3
5
6
9
12
24
48
V DC
V DC
V DC
V DC
V DC
V DC
V DC
4.5 V DC
Single side stable
Part No.
TQ2-3V
TQ2-4.5V
TQ2-5V
TQ2-6V
TQ2-9V
TQ2-12V
TQ2-24V
TQ2-48V
1 coil latching
Part No.
TQ2-L-3V
TQ2-L-4.5V
TQ2-L-5V
TQ2-L-6V
TQ2-L-9V
TQ2-L-12V
TQ2-L-24V
—
2 coil latching
Part No.
TQ2-L2-3V
TQ2-L2-4.5V
TQ2-L2-5V
TQ2-L2-6V
TQ2-L2-9V
TQ2-L2-12V
TQ2-L2-24V
—
2 Form C
Standard packing (2 Form C): Tube: 50 pcs.; Case: 1,000 pcs.
2) Self-clinching terminal
Contact
arrangement
Nominal coil
voltage
3 V DC
4.5 V DC
5
2 Form C
6
9
12
24
48
V DC
V DC
V DC
V DC
V DC
V DC
Single side stable
Part No.
TQ2H-3V
TQ2H-4.5V
TQ2H-5V
TQ2H-6V
TQ2H-9V
TQ2H-12V
TQ2H-24V
TQ2H-48V
1 coil latching
Part No.
TQ2H-L-3V
TQ2H-L-4.5V
TQ2H-L-5V
TQ2H-L-6V
TQ2H-L-9V
TQ2H-L-12V
TQ2H-L-24V
—
2 coil latching
Part No.
TQ2H-L2-3V
TQ2H-L2-4.5V
TQ2H-L2-5V
TQ2H-L2-6V
TQ2H-L2-9V
TQ2H-L2-12V
TQ2H-L2-24V
—
Note: Types (“-3” to the end of part No.) designed to withstand strong vibration caused, for example, by the use of terminal cutters, can also be ordered.
However, please contact us if you need parts for use in low level load.
2. M.B.B. type
1) Standard PC board terminal
Contact arrangement
Nominal coil voltage
3 V DC
4.5 V DC
5 V DC
6 V DC
9 V DC
12 V DC
24 V DC
Single side stable
Part No.
TQ2-2M-3V
TQ2-2M-4.5V
TQ2-2M-5V
TQ2-2M-6V
TQ2-2M-9V
TQ2-2M-12V
TQ2-2M-24V
2 Form C
Standard packing: Tube: 50 pcs.; Case: 1,000 pcs.
2) Self-clinching terminal
Contact arrangement
Nominal coil voltage
3 V DC
4.5 V DC
2 Form C
5
6
9
12
24
V DC
V DC
V DC
V DC
V DC
Single side stable
Part No.
TQ2H-2M-3V
TQ2H-2M-4.5V
TQ2H-2M-5V
TQ2H-2M-6V
TQ2H-2M-9V
TQ2H-2M-12V
TQ2H-2M-24V
Standard packing: Tube: 50 pcs.; Case: 1,000 pcs.
Notes: 1. Latching types are available by request. Please consult us for details.
3. Types (“-1” to the end of part No.) designed to withstand strong vibration caused, for example, by the use of terminal cutters, can also be ordered.
However, please contact us if you need parts for use in low level load and low thermal power.
–2–
ASCTB14E 201407-T
TQ
■
Surface-mount terminal
1) Tube packing
Contact
arrangement
Nominal coil
voltage
1.5 V DC
3
5
6
9
12
24
48
V DC
V DC
V DC
V DC
V DC
V DC
V DC
4.5 V DC
2c
Single side stable
Part No.
TQ2S -1.5V
TQ2S -3V
TQ2S -4.5V
TQ2S -5V
TQ2S -6V
TQ2S -9V
TQ2S -12V
TQ2S -24V
TQ2S -48V
1 coil latching
Part No.
TQ2S -L-1.5V
TQ2S -L-3V
TQ2S -L-4.5V
TQ2S -L-5V
TQ2S -L-6V
TQ2S -L-9V
TQ2S -L-12V
TQ2S -L-24V
—
2 coil latching
Part No.
TQ2S -L2-1.5V
TQ2S -L2-3V
TQ2S -L2-4.5V
TQ2S -L2-5V
TQ2S -L2-6V
TQ2S -L2-9V
TQ2S -L2-12V
TQ2S -L2-24V
—
: For each surface-mounted terminal identification, input the following letter. SA type: A, SL type: L, SS type: S
Standard packing: Tube: 50 pcs.; Case: 1,000 pcs.
2) Tape and reel packing
Contact
arrangement
Nominal coil
voltage
1.5 V DC
3
V DC
4.5 V DC
5 V DC
2 Form C
6
9
12
24
48
V DC
V DC
V DC
V DC
V DC
Single side stable
Part No.
TQ2S -1.5V-Z
TQ2S -3V-Z
TQ2S -4.5V-Z
TQ2S -5V-Z
TQ2S -6V-Z
TQ2S -9V-Z
TQ2S -12V-Z
TQ2S -24V-Z
TQ2S -48V-Z
1 coil latching
Part No.
TQ2S -L-1.5V-Z
TQ2S -L-3V-Z
TQ2S -L-4.5V-Z
TQ2S -L-5V-Z
TQ2S -L-6V-Z
TQ2S -L-9V-Z
TQ2S -L-12V-Z
TQ2S -L-24V-Z
—
2 coil latching
Part No.
TQ2S -L2-1.5V-Z
TQ2S -L2-3V-Z
TQ2S -L2-4.5V-Z
TQ2S -L2-5V-Z
TQ2S -L2-6V-Z
TQ2S -L2-9V-Z
TQ2S -L2-12V-Z
TQ2S -L2-24V-Z
—
: For each surface-mounted terminal identification, input the following letter. SA type: A, SL type: L, SS type: S
Standard packing: Tape and reel: 500 pcs.; Case: 1,000 pcs.
Note: Tape and reel packing symbol “-Z” is not marked on the relay. “X” type tape and reel packing (picked from 1/2/3/4-pin side) is also available.
RATING
■
Standard PC board terminal and self-clinching terminal
1. Coil data
[Standard (B.B.M.) type]
1) Single side stable (2 Form C)
Nominal coil
voltage
3
V DC
Pick-up voltage
(at 20°C
68°F)
Drop-out voltage
(at 20°C
68°F)
Nominal operating
current
[±10%] (at 20°C
68°F)
46.7 mA
31.1
28.1
23.3
15.5
11.7
8.3
mA
mA
mA
mA
mA
mA
Coil resistance
[±10%] (at 20°C
68°F)
64.3
Ω
144.6
Ω
178
Ω
257
Ω
579
Ω
1,028
Ω
2,880
Ω
7,680
Ω
Nominal operating
power
Max. applied voltage
(at 20°C
68°F)
4.5 V DC
5 V DC
6 V DC
9 V DC
12 V DC
24 V DC
48
V DC
140 mW
75%V or less of
nominal voltage*
(Initial)
10%V or more of
nominal voltage*
(Initial)
150%V of
nominal voltage
200 mW
300 mW
120%V of
nominal voltage
6.25 mA
2) 1 coil latching (2 Form C)
Nominal coil
voltage
3
5
6
9
12
24
V DC
V DC
V DC
V DC
V DC
V DC
75%V or less of
nominal voltage*
(Initial)
75%V or less of
nominal voltage*
(Initial)
Set voltage
(at 20°C
68°F)
Reset voltage
(at 20°C
68°F)
Nominal operating
current
[±10%] (at 20°C
68°F)
33.3 mA
22.2 mA
20 mA
16.7 mA
11.1 mA
8.3 mA
6.3 mA
Coil resistance
[±10%] (at 20°C
68°F)
90
250
360
810
1,440
3,840
Ω
Ω
Ω
Ω
Ω
Ω
202.5
Ω
100 mW
150%V of
nominal voltage
Nominal operating
power
Max. applied voltage
(at 20°C
68°F)
4.5 V DC
150 mW
–3–
ASCTB14E 201407-T
TQ
3) 2 coil latching (2 Form C)
Nominal coil
voltage
3
5
6
9
12
24
V DC
V DC
V DC
V DC
V DC
V DC
75%V or less of
nominal voltage*
(Initial)
75%V or less of
nominal voltage*
(Initial)
Set voltage
(at 20°C
68°F)
Reset voltage
(at 20°C
68°F)
Nominal operating
current
[±10%] (at 20°C
68°F)
Set coil
Reset coil
66.7 mA
44.4 mA
40
mA
33.3 mA
22.2 mA
16.7 mA
12.5 mA
66.7 mA
44.4 mA
40
mA
33.3 mA
22.2 mA
16.7 mA
12.5 mA
Coil resistance
[±10%] (at 20°C
68°F)
Set coil
45
125
180
405
720
1,920
Ω
Ω
Ω
Ω
Ω
Ω
101.2
Ω
Reset coil
45
125
180
405
720
1,920
Ω
Ω
Ω
Ω
Ω
Ω
300 mW
300 mW
120%V of
nominal voltage
150%V of
nominal voltage
101.2
Ω
200 mW
200 mW
Nominal operating
power
Set coil
Reset coil
Max. applied voltage
(at 20°C
68°F)
4.5 V DC
[M.B.B. type]
Nominal coil
voltage
3
5
6
9
12
24
V DC
V DC
V DC
V DC
V DC
V DC
80%V or less of
nominal voltage*
(Initial)
10%V or more of
nominal voltage*
(Initial)
Pick-up voltage
(at 20°C
68°F)
Drop-out voltage
(at 20°C
68°F)
Nominal operating
current
[±10%] (at 20°C
68°F)
66.7 mA
44.4 mA
40 mA
33.3 mA
22.2 mA
16.7 mA
8.3 mA
Coil resistance
[±10%] (at 20°C
68°F)
45
Ω
101
Ω
125
Ω
180
Ω
405
Ω
720
Ω
2,880
Ω
200 mW
150%V of
nominal voltage
Nominal operating
power
Max. applied voltage
(at 20°C
68°F)
4.5 V DC
*Pulse drive (JIS C 5442-1986)
2. Specifications
Characteristics
Arrangement
Contact
Initial contact resistance, max.
Contact material
Nominal switching capacity
Max. switching power
Max. switching voltage
Max. switching current
Min. switching capacity (Reference value)*
1
Single side stable
Nominal
operating power 1 coil latching
2 coil latching
Insulation resistance (Initial)
Between open contacts
Electrical
characteristics
Breakdown
voltage (Initial)
Between contact and coil
Between contact sets
Temperature rise (at 20°C
68°F)
Operate time [Set time] (at 20°C
68°F)
Release time [Reset time] (at 20°C
68°F)
Shock
resistance
Vibration
resistance
Functional
Destructive
Item
2 Form C, 2 Form D (M.B.B.)
Max. 50mΩ (By voltage drop 6 V DC 1A)
Ag+Au clad
1 A 30 V DC, 0.5 A 125 V AC (resistive load)
30 W (DC), 62.5 V A (AC) (resistive load)
110 V DC, 125 V AC
1A
10μA 10mV DC
Standard (B.B.M) type: 140 mW (3 to 12 V DC), 200 mW (24 V DC), 300 mW (48 V DC)
M.B.B. type: 200 mW
100 mW (3 to 12 V DC), 150 mW (24 V DC)
200 mW (3 to 12 V DC), 300 mW (24 V DC)
Min. 1,000MΩ (at 500V DC)
Measurement at same location as “Initial breakdown voltage” section.
Standard (B.B.M) type: 750 Vrms for 1min. (Detection current: 10 mA),
M.B.B. type: 300 Vrms for 1 min. (Detection current: 10 mA)
1,000 Vrms for 1min. (Detection current: 10 mA)
1,000 Vrms for 1min. (Detection current: 10 mA)
Max. 50°C (By resistive method, nominal coil voltage applied to the coil; contact carrying current: 1A.)
Max. 3 ms [Max. 3 ms] (Nominal coil voltage applied to the coil, excluding contact bounce time.)
Max. 3 ms [Max. 3 ms] (Nominal coil voltage applied to the coil, excluding contact bounce time.)
(without diode)
Min. 490 m/s
2
(Half-wave pulse of sine wave: 11 ms; detection time: 10μs.)
Min. 980 m/s
2
(Half-wave pulse of sine wave: 6 ms.)
10 to 55 Hz at double amplitude of 3 mm (Detection time: 10μs.)
10 to 55 Hz at double amplitude of 5 mm
Standard (B.B.M) type: Min. 10
8
, M.B.B. type: Min. 10
7
Standard (B.B.M) type: Min. 2×10
5
(1 A 30 V DC resistive), Min. 10
5
(0.5 A 125 V AC resistive)
M.B.B. type: Min. 10
5
(1 A 30 V DC resistive)
Standard (B.B.M) type:
Ambient temperature: –40°C to +70°C
–40°F to +158°F;
Humidity: 5 to 85% R.H. (Not freezing and condensing at low temperature)
M.B.B. type:
Ambient temperature: –40°C to +50°C
–40°F to +122°F;
Humidity: 5 to 85% R.H. (Not freezing and condensing at low temperature)
20 cpm
Approx. 1.5 g
.053 oz
Specifications
Rating
Mechanical
characteristics
Functional
Destructive
Mechanical (at 180 cpm)
Electrical (at 20 cpm)
Expected life
Conditions
Conditions for operation, transport and
storage*
2
Max. operating speed (at rated load)
Unit weight
Notes: *1 This value can change due to the switching frequency, environmental conditions, and desired reliability level, therefore it is recommended to check this with the
actual load. TX/TX-S/TX-D relay AgPd contact type are available for low level load switching (10V DC, 10mA max. level).
*2 Refer to “AMBIENT ENVIRONMENT” in GENERAL APPLICATION GUIDELINES.
My programmer is TOP2005. If I want to use the programmer to write data directly to the 24C02 memory chip, then I change the content of the 00H address of the HEX file to 01H. In this way, can I compl...
The NUCLEO-G071RB development board used in this experiment is provided by [font=sans-serif][url=https://www.stmcu.com.cn/index.p%20...%20/261/layout/product]https://www.stmcu.com.cn/index.p ... /261/...
I would like to ask if there are any brothers who have done robot painting, what problems should be paid attention to when doing it? Can everyone come and talk about it?...
[i=s]This post was last edited by paulhyde on 2014-9-15 03:18[/i] This competition is really good. Although the question looks kind, the indicators are too high!!!...
This is what I did. Please help me see where I did wrong: 1. The u-boot environment variables are as follows: QQ2440 # printenv bootargs=root=/dev/nfs rw nfsroot=172.16.1.248:/home/yf/project nfsaddrs...
Now, the AC is input to the AD port of the PIC16F877A microcontroller through the op amp. The program code is in assembly, so I don't quite understand it. It seems that the program is written like thi...
Today's computer peripherals are pursuing high speed and high versatility. In order to meet user needs, seven companies led by Intel launched the USB (Universal Serial Bus) bus protocol in 1994, wh...[Details]
With the promotion of the construction of intelligent communities in the country, anti-theft systems have become essential equipment for intelligent communities. Especially in recent years, the urg...[Details]
Due to the significant increase in electronic devices in automotive and industrial applications, the automotive and industrial markets continue to play an important role in China's electronics in...[Details]
When choosing a laptop battery, you should consider several factors, such as power, appearance, and quality.
Regarding power, we often see that a manufacturer uses values such as the number ...[Details]
Power management solutions for today's portable application processors are becoming increasingly integrated. Total power consumption, standby and sleep current consumption affect battery size, bill...[Details]
The solidification and modularization of intelligent video analysis algorithms are the current trends in the application of intelligent video analysis technology. It perfectly combines intelligent ...[Details]
The data collector of the automatic weather station is generally designed based on a single-chip microcomputer or a PC/104 bus controller. It has the characteristics of good compatibility with PC, low...[Details]
1. What is temperature?
Heat is a type of molecular motion. The hotter an object is, the faster its molecules move. Absolute zero is defined as the temperature at which all molecular motion ...[Details]
1. Background:
The instrument system parameter detection and control of the chemical production workshop of Tangshan Coal Gas Coking Plant are all analog instruments, some of which are eve...[Details]
LED lamps and bulbs are now rapidly replacing incandescent, halogen and CFL (compact fluorescent lamp) light sources in many general lighting applications. Flyback DC/DC converters are the power su...[Details]
We know that the inverter consists of two parts: the main circuit and the control circuit. Due to the nonlinearity of the main circuit (switching action), the inverter itself is a source of harmoni...[Details]
To understand how and why OLED power supply affects display image quality, you must first understand OLED display technology and power supply requirements. This article will explain the latest OLED...[Details]
introduction
Incandescent bulbs can emit a variety of light, but in specific applications, only green, red, and yellow light are usually needed - such as traffic lights. If an incand...[Details]
The rectified DC voltage is then converted back to AC using power electronics such as insulated gate bipolar transistors.
The output voltage is switched on and off at a high frequency, control...[Details]
At present, how various communication technologies will evolve after 3G is a focus of great concern in the industry. Especially for TD-SCDMA, whether it can achieve smooth evolution to the next gen...[Details]
Embedded System
京公网安备 11010802033920号
EEWORLD
