KBPC10,15,25,35 SERIES
SINGLE-PHASE SILICON BRIDGE
Reverse Voltage -
50 to 1000 Volts
Forward Current -
10.0/15.0/25.0/35.0 Amperes
Features
Surge overload 200-400 amperes peak
Low forward voltage drop
Mounting position: Any
Electrically isolated base-1800 volts
Solderable 0.25 FASTON terminals
Materials used carries U/L recognition
DIMENSIONS
DIM
A
B
C
D
E
F
H
inches
Min.
0.432
1.12
0.612
0.672
0.512
-
Max.
0.442
1.13
0.692
0.752
0.590
1.0
Min.
10.97
28.4
15.5
17.1
13
-
mm
Max.
11.23
28.7
17.6
19.1
15
25.4
Note
DIM
A
B
C
D
E
F
G
H
0.672
inches
Min.
0.432
1.12
0.410
1.2
0.672
DIMENSIONS
mm
Max.
0.442
1.13
0.490
-
0.752
Min.
10.97
28.4
10.4
30.5
17.1
Max.
11.23
28.7
12.4
-
19.1
Note
0.04(1.0) DIA Typ.
0.752
17.1
19.1
HOLE FOR NO.8 SCREW 0.193(4.9) DIA
HOLE FOR NO. 8 SCREW 0.193(4.9) DIA
Maximum Ratings and Electrical Characteristics
Ratings at 25 ambient temperature unless otherwise specified. Resistive or inductive load 60Hz
For capacitive load, derate current by 20%.
KBPC10005
KBPC1001
KBPC1501
KBPC2501
KBPC3501
KBPC1002
KBPC1502
KBPC2502
KBPC3502
KBPC1004
KBPC1504
KBPC2504
KBPC3504
KBPC1006
KBPC1506
KBPC2506
KBPC3506
KBPC1008
KBPC1508
KBPC2508
KBPC3508
KBPC1010
KBPC1510
KBPC2510
KBPC3510
Symbols
KBPC15005
KBPC25005
KBPC35005
Units
Maximum repetitive peak reverse voltage
Maximum RMS bridge input voltage
Maximum average forward
rectified output current at T
C
=55
Peak forward surge current, 8.3mS single
half sine-wave superimposed on rated load
Maximum forward Voltage drop per
element at 5.0/7.5/12.5/17.5A peak
Maximum DC reverse current at rated
DC blocking voltage per element T
A
=25
Operating temperature range
Storage temperature range
Note:
(1) Also available on
KBPC10W / 15W / 25W / 35W
series
V
RRM
V
RMS
I
(AV)
I
FSM
V
F
I
R
T
J
T
STG
50
35
100
70
200
140
400
280
600
420
800
560
1000
700
Volts
Volts
Amps
Amps
Volts
A
KBPC10: 10.0
KBPC15: 15.0
KBPC25: 25.0
KBPC35: 35.0
KBPC10: 200.0 KBPC15: 300.0
KBPC25: 300.0 KBPC35: 400.0
1.2
10.0
-55 to +125
-55 to +150
1
