30mm Push Button Accessories
ER
Metal legend plates are
engraved in horizontal and
vertical orientations, one
per side.
EM
EMERGENCY STOP
LP41
Legend plate Ø 60mm
yellow with black text.
GE
N
Ø60mm
Title
AUTO
CLOSE
DOWN
EMERGENCY STOP
FAST
HAND
HAND, O, AUTO
INCH
LEFT
OFF
ON
OPEN
Cat No.
LP09
LP08
LP07
LP41
LP12
LP10
LP36
LP14
LP18
LP16
LP15
LP07
Title
OVER
POWER ON
RESET
REVERSE
RIGHT
RUN
SLOW
START
STOP
TRIP
UNDER LOAD
Cat No.
LP74
LP20
LP13
LP04
LP17
LP24
LP11
LP01
LP02
LP19
LP108
STOP
CY
Ø30mm
Replacement Bulbs
LED Bulbs
Color
Voltage
110V AC
White
110V AC
Green 110V AC
Red
110V AC
Amber 110V AC
Blue
110V AC
Yellow 110V AC
110V DC
White
110V
Green 110V
Red
110V
Amber 110V
Blue
110V
Yellow 110V
Cat No.
Color
Voltage
230V AC
White
230V AC
Green 230V AC
Red
230V AC
Amber 230V AC
Blue
230V AC
Yellow 230V AC
230V DC
White
230V
Green 230V
Red
230V
Amber 230V
Blue
230V
Yellow 230V
Cat No.
LED Bulbs
Color
Voltage
12V AC/DC
White
12V AC/DC
Green 12V AC/DC
Red
12V AC/DC
Amber 12V AC/DC
Blue
12V AC/DC
Yellow 12V AC/DC
Supply Voltage
12V
24V
48V
110V
240V
Color
Clear
Clear
Clear
Clear
Clear
Filament Bulbs
Voltage
12V AC/DC
24V AC/DC
48V AC/DC
110V AC/DC
230V AC/DC
Cat No.
Cat No.
BA15D12
BA15D24
BA15D48
BA15D110
BA15D220
MCB15112
MCB15312
MCB15412
MCB15512
MCB15612
MCB15812
24V AC/DC
White
24V AC/DC
Green 24V AC/DC
Red
24V AC/DC
Amber 24V AC/DC
Blue
24V AC/DC
Yellow 24V AC/DC
DC
DC
DC
DC
DC
DC
MCB151110
MCB153110
MCB154110
MCB155110
MCB156110
MCB158110
MCB15124
MCB15324
MCB15424
MCB15524
MCB15624
MCB15824
MCB151110D
MCB153110D
MCB154110D
MCB155110D
MCB156110D
MCB158110D
48V AC/DC
White
48V AC/DC
Green 48V AC/DC
Red
48V AC/DC
Amber 48V AC/DC
Blue
48V AC/DC
Yellow 48V AC/DC
DC
DC
DC
DC
DC
DC
MCB151230
MCB153230
MCB154230
MCB155230
MCB156230
MCB158230
MCB15148
MCB15348
MCB15448
MCB15548
MCB15648
MCB15848
MCB151230D
MCB153230D
MCB154230D
MCB155230D
MCB156230D
MCB158230D
Maximum Power Consumption:
These bulbs use high brightness LED chips which last for more than 100,000 hours and consume very little power. Heat
generated by LED based bulbs is negligible, therefore no damage to the body of the lamp or any operator in case of Illuminated
push buttons occurs.
These bulbs can be used to replace 12V AC/DC, 24V AC/DC, 48V AC/DC, 110V AC or DC and 240V AC or DC circuits directly.
LED color indication is given on the bulb for easy identification.
54
Altech Corp.
®
• 35 Royal Road • Flemington, NJ 08822-6000 • Phone (908)806-9400 • FAX (908)806-9490 • www.altechcorp.com
These bulbs are available in various colors and voltages. LED based bulbs are a direct replacement for filament bulbs and do not
require having to change any other components in your existing operator or pilot light.
Power (max) in Watts
0.5W
0.5W
0.5W
0.5W
1W
LED
Current
max 20mA
max 20mA
max 20mA
max 20mA
max 20mA
Power (max) in Watts
2W
2W
5W
5W
6W
FILAMENT BULBS
Current
max 166mA
max 85mA
max 105mA
max 45mA
max 25mA
30mm Push Button Accessories
Lenses for pilot lights
Color
White
Green
Red
Amber
Blue
Clear
Yellow
Padlock
Lenses and Replacement Boots
Cat No.
PLL1
PLL3
PLL4
PLL5
PLL6
PLL7
PLL8
Cat. No. PAM
Cat. No. PAP
Lenses for illuminated actuators
Color
White
Green
Red
Amber
Blue
Clear
Yellow
Cat No.
ALL1
ALL3
ALL4
ALL5
ALL6
ALL7
ALL8
For mushroom actuator:
For projecting actuator:
Actuator Lock Plate
Cat. No.: ALP101
Rubber Boots for Booted Actuators
Color
Cat No.
White
BT1
Black
BT2
Green
BT3
Red
BT4
Blue
BT6
Yellow
BT8
1.2mm Actuator Rubber Washer
Cat. No.: ARW1.2
3.2mm Actuator Rubber Washer
Cat. No.: ARW3.2
Replacement Key
Cat. No.: KY30
Bulb Extractor
Cat. No.: 2BA15SE
Cat #.
SC25
SC45
SC65
SC90
Contact Block Installation Screws
Dimensions
M4
M4
M4
M4
x
x
x
x
25
45
65
90
mm
mm
mm
mm
Used With
S11 only
S11 + S12 (2NO + 2NC)
2 x S11 + S12 (3NO +3NC)
2 x S11 + 2 x S12 (4NO+4NC)
S11
S12
Description
1 Normally Open + 1 Normally Closed
Silver Contacts
2 Normally Open + 2 Normally Closed
Silver Contacts
Contact Installation Screws
Type
SC25
SC45
SC65
SC90
Cat. No.
S11
Contact Elements
For additional contacts, see diagram at right.
Dimensions
M4 x 25 mm
M4 x 45 mm
M4 x 65 mm
M4 x 90 mm
S11 + S12
*
*
* When using more than two contact blocks, additonal
screws must be purchased separately (SC45 and SC90).
Used with
S11
S11 + S12
2x S11 + S12
2x S11 + 2x S12
S 12
S 12
S12
S12
1NO + 1NC
S11
contact
+ SC25
2NO + 2NC
S11 + S12
contact
+ SC45
3NO + 3NC
2x S11 + S12
contact
+ SC65
4NO + 4NC
2x S11 + 2x S12
contact
+ SC90
Altech Corp.
®
• 35 Royal Road • Flemington, NJ 08822-6000 • Phone (908)806-9400 • FAX (908)806-9490 • www.altechcorp.com
55
