Dimensions: mm (in.)
106-MH7310A-EV
7.20
(.283)
2
(.079)
3
(.118)
2.90
(.114)
2.54
(.10)
3
(.118)
.62
(.024)
Ref. #:
MS-101195
2.54
(.10)
.5
(.02)
9
0
1
2 3
7 8
9.80
(.386)
2.80
(.10)
106-MH7316A-EV
B
C
D
E
A
F
0
1
Electrical Specifications:
•
Rating
•
•
•
Non-Switching: 100mA/50V DC
Switching: 25mA/24V DC
Contact Resistance: 100mΩ Max. (initial)
Dielectric Strength: 250V AC for 1 min.
Insulation Resistance: 100MΩ min. 250VDC
Rotary Dip Switches
106-MH7310A-EV, 106-MH7316A-EV
Available from Mouser Electronics
www.mouser.com
1-800-346-6873
Specifications are subject to change without notice. No liability or warranty implied by this information. Environmental compliance based on producer documentation.
4
.20
(.008)
ON
OFF
7
8
9
5
6
.60
(.024)
2.54
(.10)
1.20 (.047)
TYPE
CODE
POSITION
0
1
2
1
2
4
8
10 STEP
3
4
5
6
2
1
C
2
3
4
5
6
11
(.433)
6.50
(.256)
16 STEP
7
8
9
A
4
8
C
B
C
D
E
P.C.B. Layout
2.54
(.10)
F
Circuit Chart
Mechanical Specifications:
•
Operating Temperature: -25°C - +80°C
•
Storage Temperature: -40°C - +85°C
•
Operation Force: 200gf cm Max.
Note:
•
RoHS Compliant
