Product data sheet
Characteristics
XCKD25H0P16
limit switch XCKD - M18 metal end plunger -
1NC+1NO - slow - M16
Product availability: Non-Stock - Not normally stocked in distribution facility
Main
Commercial Status
Range of product
Series name
Product or component
type
Device short name
Sensor design
Body type
Head type
Material
Body material
Head material
Fixing mode
Movement of operating
head
Type of operator
Type of approach
Number of poles
Contacts type and
composition
Contacts operation
Commercialised
OsiSense XC
Standard format
Limit switch
XCKD
Compact
Fixed
M18 plunger head
Metal
Zamak
Zamak
By the head
Linear
Spring return plunger metal
Vertical approach
2
1 NC + 1 NO
Slow-break, break before make
The information provided in this documentation contains general descriptions and/or technical characteristics of the performance of the products contained herein.
This documentation is not intended as a substitute for and is not to be used for determining suitability or reliability of these products for specific user applications.
It is the duty of any such user or integrator to perform the appropriate and complete risk analysis, evaluation and testing of the products with respect to the relevant specific application or use thereof.
Neither Schneider Electric Industries SAS nor any of its affiliates or subsidiaries shall be responsible or liable for misuse of the information contained herein.
Complementary
Switch actuation
Electrical connection
Cable entry
Contacts insulation form
Positive opening
Positive opening minimum force
Minimum force for tripping
Minimum actuation speed
Maximum actuation speed
Repeat accuracy
Contact code designation
On end
Screw-clamp terminals, clamping capacity: 1 x 0.5...2 x 2.5 mm²
1 entry tapped for M16 x 1.5 cable gland, cable outer diameter: 0.16...0.31 in
(4...8 mm)
Zb
With
45 N
15 N
6 m/min
1.64 ft/s (0.5 m/s)
0.1 mm on the tripping points with 1 million operating cycles
Q300, DC-13 (Ue = 250 V, Ie = 0.27 A) conforming to IEC 60947-5-1 appendix A
Q300, DC-13 (Ue = 250 V, Ie = 0.27 A) conforming to EN 60947-5-1
A300, AC-15 (Ue = 240 V, Ie = 3 A) , Ithe = 10 A conforming to IEC 60947-5-1
appendix A
A300, AC-15 (Ue = 240 V, Ie = 3 A) , Ithe = 10 A conforming to EN 60947-5-1
300 V conforming to CSA C22.2 No 14
500 V degree of pollution 3 conforming to IEC 60947-1
300 V conforming to UL 508
<= 25 MOhm conforming to IEC 60255-7 category 3
6 kV conforming to IEC 60947-1
6 kV conforming to IEC 60664
10 A cartridge fuse gG
[Ui] rated insulation voltage
Resistance across terminals
[Uimp] rated impulse withstand voltage
Short circuit protection
Feb 29, 2016
1
Electrical durability
5000000 cycles, DC-13, 48 V, 9 W, operating rate: <= 60 cyc/mn, load factor: 0.5,
DC conforming to IEC 60947-5-1 appendix C
5000000 cycles, DC-13, 24 V, 13 W, operating rate: <= 60 cyc/mn, load factor:
0.5, DC conforming to IEC 60947-5-1 appendix C
5000000 cycles, DC-13, 120 V, 7 W, operating rate: <= 60 cyc/mn, load factor:
0.5, DC conforming to IEC 60947-5-1 appendix C
10000000 cycles
1.22 in (31 mm)
2.56 in (65 mm)
1.18 in (30 mm)
0.49 lb(US) (0.22 kg)
(13-14)NO
(21-22)NC
Mechanical durability
Width
Height
Depth
Product weight
Terminals description ISO n°1
Environment
Shock resistance
Vibration resistance
IK degree of protection
Class of protection against electric shock
Ambient air temperature for operation
Ambient air temperature for storage
Protective treatment
Product certifications
50 gn (duration = 11 ms) conforming to IEC 60068-2-27
25 gn (f = 10...500 Hz) conforming to IEC 60068-2-6
IK06 conforming to EN 50102
Conforming to NF C 20-030
Conforming to IEC 61140
-13...158 °F (-25...70 °C)
-40...158 °F (-40...70 °C)
TC
CCC
CSA
UL
EN 60204-1
EN 60947-5-1
IEC 60204-1
IEC 60947-5-1
UL 508
CSA C22.2 No 14
Standards
Ordering and shipping details
Category
Discount Schedule
GTIN
Nbr. of units in pkg.
Package weight(Lbs)
Product availability
Returnability
Country of origin
22418 - LIMIT SWITCH,IEC,XCKP&XCKT
T
003389110201529
1
0.70
Non-Stock - Not normally stocked in distribution facility
Y
ID
Offer Sustainability
Sustainable offer status
RoHS
REACh
Product environmental profile
Product end of life instructions
Green Premium product
Compliant - since 1103 -
Available
Schneider Electric declaration of conformity
Reference not containing SVHC above the threshold
Download Product Environmental
Need no specific recycling operations
Contractual warranty
Period
18 months
