Selector SwitcheS
Series PB
Technical specifications
Operating force
Contact resistance
Insulating resistance
Dielectric strength
Electrical rating
(ohmic resistance)
Max. current
Temperature
Life cycle (mechanical)
Shock
Vibration
Weight
Materials:
Housing material
Contacts
Printed circuit board
Mounting
Stops
Terminal
PPO (Noryl)
High-quality gold alloy
FR3 PCB, copper-plated; Au over Nii
Front-mounting, snap-in endcaps. Mounting of
units through integrated pins.
setting through factory only
Solder pins: 0,6 x 0,6 (spacing 2,54)
ca 300 cN (with tactile feeling)
0,1
10
3
M
500 V
0,1 A / 50 V
Q
0,5 A (not switchable)
– 20 to + 80°C
10
6
operations
50 g, 11 ms
15 g, 10 – 2.000 Hz
ca. 2 g
max
Features
Selector switch, just 6 mm wide for compact construction of
multiplemodule rows
10 switching positions
Connection via solder pins
Codes (2)
Switching position
10
10
10
Code
BCD
BCD-Complement
Single pole repeating
Readout
0–9
0–9
+ / – alt.
Truth table-no.
(refer to description)
1
11
4
PCB terminal
1
5
2
Code
C
E
P
Terminals (3)
Terminals
Solder pins
Code
1
Accessories
Stock codes
Endcap left
Endcap right
Housing, 6 mm
Code
E
609 – 1346
609 –1347
609 –1348
PCB versions (4)
PCB version
PCB flush with housing with solder pins
For detailed information and the layout of the details described above,
please do not hesitate to ask for our technical specifications and drawing.
Switching position
10
Window cutout
B=3
H=4
Number height
3
Dimensions in mm
PCB–Terminals
Size of front panal 1– 2,4
Size of front panal 1–2,4
Spacing 2,54
Spacing 5,08
Spacing 2,54
Spacing 2,54
Spacing 5,08
Spacing 2,54
Front panel
cut-out
Front panel
cut-out
5
5
6
6
