SPECIFICATIONS
PARAMETERS
RATED VOLTAGE
OPERATING VOLTAGE RANGE
RATED CURRENT (MAX)
MINIMUM SPL @ 10 CM
RESONANT FREQUENCY
TONE OR PULSE RATE
OPERATING TEMPERATURE
STORAGE TEMPERATURE
HOUSING MATERIAL
TERMINAL MATERIAL
WEIGHT
VALUES
110
30 ~ 120
17
98
2,800 ± 500
CONTINUOUS
-20 ~ +60
-30 ~ +70
ABS
Ni PLATED
BRASS
43
UNITS
Vac
Vac/Vdc
mA
dBA
Hz
0 pulse/sec
°C
°C
-
-
grams
THIS DOCUMENT CONTAINS DATA PROPRIETARY TO
PROJECTS UNLIMITED, INC. ANY USE OR
REPRODUCTION, IN ANY FORM, WITHOUT PRIOR
WRITTEN PERMISSION OF PROJECTS UNLIMITED,
INC. IS PROHIBITED.
LTR
-
A
B
C
D
©2003, Projects Unlimited Inc.
RELEASED FROM ENGINEERING
REVISED TONE OR PULSE RATE
REVISED OPERATING VOLTAGE RANGE
REVISED TO INVETOR 3-D DRAWING TEMPLATE
REVISED OPERATING VOLTAGE RANGE
DESCRIPTION
REVISION HISTORY
3/22/2006
1/29/2007
11/30/2007
3/7/2008
4/27/2012
DATE
APPROVED
R.W.
B.R.
B.R.
M.L.
10.5
43
20
13
8
8.5 6.5
28
35.7
7.7
33
NOTES:
1. ALL DIMENSIONS ARE IN MILLIMETERS.
2. SPECIFICATIONS SUBJECT TO CHANGE OR WITHDRAWL
WITHOUT NOTICE.
3. THIS PART IS RoHS 2002/95/EC COMPLIANT.
UNLESS OTHERWISE
SPECIFIED:
DIMENSIONS ARE IN
MILLIMETERS,
TOLERANCES
ARE ±0.5 AND
ANGLES ARE ±3°.
Designed by
Date
Checked by
Date
Approved by
Date
Drawn Date
SIZE
T.G.
3/22/2006
B.R.
3/22/2006
E.P.
3/22/2006
3/7/2008
A3
AI-4328-P-C120D-R
Indicator
Edition
Sheet
AI-4328-P-C120D-R.idw
-
1/1
