P26F-1D-BL Overview

Pushbutton Switches PUSHBUTTON SWITCH

P26F-1D-BL Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Carling Technologies
Objectid	1731323506
Reach Compliance Code	compliant
ECCN code	EAR99
compound_id	69840651
body width	13.3 mm
body height	13.76 mm
Body length or diameter	30.04 mm
Contact (AC) maximum rated R load	6A@125VAC
Maximum contact current (AC)	6 A
Maximum contact voltage (AC)	125 V
Electrical life	25000 Cycle(s)
Installation features	PANEL MOUNT-THREADED
Maximum operating force	3.61 N
Maximum operating temperature	85 °C
Minimum operating temperature
surface mount	NO
Switch action	LATCHED AND MOMENTARY
switch function	SPST
Switch type	PUSHBUTTON SWITCH
Termination type	WIRE

Preview

Download Datasheet

View All

P26-Series

PUSHBUTTON SWITCHES

The P26-Series pushbutton switches are single pole, AC rated for 6 amps at 125 VAC and suitable for shallow

back panel applications. These switches are momentary action with a medium actuation force (13 oz. typical).

The P26-Series switch is equipped with a slow-make, slow-break contact mechanism.

Product Highlights:

6A 125VAC, 3A 277VAC rated

Momentary On or Momentary Off circuitry

4 bushing size combinations

Round Metal, Concave Metal and Nylon Style

Actuators

Typical Applications:

Intercoms

Security System

Electronic Signs

Marine

Lighting
