Solid State Relay
OCMOS FET
PS7141-1C,PS7141L-1C
8-PIN DIP, 400 V BREAK DOWN VOLTAGE
TRANSFER TYPE
2-ch Optical Coupled MOS FET
−NEPOC
Series−
DESCRIPTION
The PS7141-1C and PS7141L-1C are transfer type solid state relays containing normally open (N.O.) contact and
normally close (N.C.) contact on output side.
They are suitable for analog signal control because of their low offset and high linearity.
The PS7141L-1C has a surface mount type lead.
FEATURES
• 2 channel type (1 a + 1 b output)
• Low LED operating current (I
F
= 2 mA)
• Designed for AC/DC switching line changer
• Small package (8-pin DIP)
• Low offset voltage
• Ordering number of taping product : PS7141L-1C-E3, E4: 1 000 pcs/reel
<R>
• Pb-Free product
• Safety standards
• UL approved: File No. E72422
• BSI approved: No. 8245/8246
• CSA approved: No. CA 101391
APPLICATIONS
• Exchange equipment
• Measurement equipment
• FA/OA equipment
Document No. PN10280EJ02V0DS (2nd edition)
Date Published July 2006 NS CP(K)
The mark <R> shows major revised points.
The revised points can be easily searched by copying an "<R>" in the PDF file and specifying it in the "Find what:" field.
1997, 2006
PS7141-1C,PS7141L-1C
<R>
ORDERING INFORMATION
Part Number
Order Number
Solder Plating
Specification
PS7141-1C
PS7141L-1C
PS7141L-1C-E3
PS7141L-1C-E4
PS7141-1C-A
PS7141L-1C-A
PS7141L-1C-E3-A
PS7141L-1C-E4-A
Pb-Free
Magazine case 50 pcs
Packing Style
Safety Standard
Approval
Application Part
Number
*1
Standard products PS7141-1C
(UL, BSI, CSA
Embossed Tape 1 000 pcs/reel approved)
*1
For the application of the Safety Standard, following part number should be used.
ABSOLUTE MAXIMUM RATINGS (T
A
= 25°C, unless otherwise specified)
Parameter
Diode
Forward Current (DC)
Reverse Voltage
Power Dissipation
Peak Forward Current
MOS FET
Break Down Voltage
Continuous Load Current
Pulse Load Current
*2
*1
Symbol
I
F
V
R
P
D
I
FP
V
L
I
L
I
LP
Ratings
50
5.0
50
1
400
150
300
Unit
mA/ch
V
mW/ch
A/ch
V
mA/ch
mA/ch
(AC/DC Connection)
Power Dissipation
Isolation Voltage
*3
P
D
BV
P
T
T
A
T
stg
375
1 500
850
−40
to +85
−40
to +100
mW/ch
Vr.m.s.
mW
°C
°C
Total Power Dissipation
Operating Ambient Temperature
Storage Temperature
*1
PW = 100
µ
s, Duty Cycle = 1%
*2
PW = 100 ms, 1 shot
*3
AC voltage for 1 minute at T
A
= 25°C, RH = 60% between input and output
Pins 1-4 shorted together, 5-8 shorted together.
RECOMMENDED OPERATING CONDITIONS (T
A
= 25°C)
Parameter
LED Operating Current
LED Off Voltage
Symbol
I
F
V
F
MIN.
2
0
TYP.
10
MAX.
20
0.5
Unit
mA
V
4
Data Sheet PN10280EJ02V0DS
