AQ2A1-C2-T24VDC datasheet, PDF

Datasheet> All Categories > LED optoelectronic/LED> photoelectric> AQ2A1-C2-T24VDC

AQ2A1-C2-T24VDC: DescriptionSolid State Relays - PCB Mount SSR 2A 125VAC 24VDC RANDOM; CategoryLED optoelectronic/LED photoelectric; File Size194KB，8 Pages; ManufacturerPanasonic; Websitehttp://www.panasonic.co.jp/semicon/e-index.html; Environmental Compliance

Download Datasheet Parametric Compare View All

AQ2A1-C2-T24VDC Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	AQ2A1-C2-T24VDC	-	-	View	Buy Now

AQ2A1-C2-T24VDC Overview

Solid State Relays - PCB Mount SSR 2A 125VAC 24VDC RANDOM

AQ2A1-C2-T24VDC Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	Panasonic
package instruction	1.772 X 0.945 INCH, 0.354 INCH HEIGHT, ROHS COMPLIANT PACKAGE-4
Reach Compliance Code	unknown
Other features	HIGH RELIABILITY, UL RECOGNIZED
Configuration	SINGLE
control voltage	21.6 V
input type	DC
Maximum insulation voltage	3000 V
Number of components	1
Maximum on-state current	2 A
Maximum operating temperature	80 °C
Minimum operating temperature	-30 °C
Optoelectronic device types	TRIGGER OUTPUT SSR
Output circuit type	Triac
total height	24 mm
total length	45 mm

Preview

Download Datasheet

View All

Please contact us

about TÜV certified

products.

SIL type SSR with

9mm thickness

controls up to 3A

AQ8 RELAYS

5. High dielectric strength: 3,000 V AC

(between input and output)

6. Two kinds of terminals distance are

available. (5.08 mm and 7.62 mm)

(.200

and .300 inch)

7. High reliability, long life and

maintenance-free

FEATURES

1. Slim with 9 mm

.354 inch

thickness

The thin type (45 mm long

24 mm high

9 mm wide)

(1.772×.945×.354 inch)

permits high density mounting.

2. Excellent in noise resistance

Since the input and output are insulated

by the phototriac coupler, the noise on

the output side is not fed back to the input

side.

3. Snubber circuit integrated

The snubber circuit is integrated to

prevent malfunction caused by the rapid

rise of the voltage on the output side,

such as inductive load and noise.

4. Zero-cross and random types are

available.

The zero-cross type generates minimal

noise by suppressing occurrence of radio

frequency interference (RFI) and electro-

magnetic interference (EMI).

The random type features a short

operation time which permits phase

control.

TYPICAL APPLICATIONS

1. Most suitable as drivers for small

size AC motors, solenoids, solenoid

valves and so on.

2. Copying equipment

3. Air conditioners

4. Industrial equipment such as NC

machines, sequencers, robots, etc.

RoHS compliant

ORDERING INFORMATION

Load current

Load voltage

1: 75 to 125 V AC

2: 75 to 250 V AC

Input terminal distance

C1: 5.08 mm

.200 inch

C2: 7.62 mm

.300 inch

Type

ZT: Zero-cross type

T: Random type

Input voltage

5, 12, 24 V DC

–1–

ASCTB213E 201410-T

AQ2A1-C2-T24VDC Related Products

	AQ2A1-C2-T24VDC	AQ3A1-C1-T5VDC	AQ3A1-C2-ZT5VDC	AQ2A1-C1-T24VDC	AQ2A1-C1-ZT5VDC	AQ3A1-C1-ZT24VDC	AQ2A1-C1-T5VDC	AQ3A1-C1-T24VDC	AQ2A1-C1-T12VDC
Description	Solid State Relays - PCB Mount SSR 2A 125VAC 24VDC RANDOM	Solid State Relays - PCB Mount 3A 5V Non-Zero Cross	Solid State Relays - PCB Mount 3A 5V Zero Cross	Solid State Relays - PCB Mount 2A 24V Non-Zero Cross	Solid State Relays - PCB Mount 2A 5V Zero Cross	Solid State Relays - PCB Mount 3A 24V Zero Cross	Solid State Relays - PCB Mount 2A 5V Non-Zero Cross	Solid State Relays - PCB Mount AQ-A Solid State Relay	Solid State Relays - PCB Mount 2A 12V Non-Zero Cross
Is it Rohs certified?	conform to	conform to	conform to	conform to	conform to	conform to	conform to	conform to	conform to
Maker	Panasonic	Panasonic	Panasonic	Panasonic	Panasonic	Panasonic	Panasonic	Panasonic	Panasonic
package instruction	1.772 X 0.945 INCH, 0.354 INCH HEIGHT, ROHS COMPLIANT PACKAGE-4	1.772 X 0.945 INCH, 0.354 INCH HEIGHT, ROHS COMPLIANT PACKAGE-4	1.772 X 0.945 INCH, 0.354 INCH HEIGHT, ROHS COMPLIANT, SIL-4	1.772 X 0.945 INCH, 0.354 INCH HEIGHT, ROHS COMPLIANT PACKAGE-4	1.772 X 0.945 INCH, 0.354 INCH HEIGHT, ROHS COMPLIANT, SIL-4	1.772 X 0.945 INCH, 0.354 INCH HEIGHT, ROHS COMPLIANT, SIL-4	1.772 X 0.945 INCH, 0.354 INCH HEIGHT, ROHS COMPLIANT PACKAGE-4	1.772 X 0.945 INCH, 0.354 INCH HEIGHT, ROHS COMPLIANT PACKAGE-4	1.772 X 0.945 INCH, 0.354 INCH HEIGHT, ROHS COMPLIANT PACKAGE-4
Reach Compliance Code	unknown	unknown	compliant	unknown	compliant	compliant	unknown	unknown	unknown
Other features	HIGH RELIABILITY, UL RECOGNIZED	HIGH RELIABILITY, UL RECOGNIZED	HIGH RELIABILITY, UL RECOGNIZED, WITH SNUBBER CIRCUIT, WITH ZERO CROSS OVER CIRCUIT	HIGH RELIABILITY, UL RECOGNIZED	HIGH RELIABILITY, UL RECOGNIZED, WITH SNUBBER CIRCUIT, WITH ZERO CROSS OVER CIRCUIT	HIGH RELIABILITY, UL RECOGNIZED, WITH SNUBBER CIRCUIT, WITH ZERO CROSS OVER CIRCUIT	HIGH RELIABILITY, UL RECOGNIZED	HIGH RELIABILITY, UL RECOGNIZED	HIGH RELIABILITY, UL RECOGNIZED
Configuration	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE
Maximum insulation voltage	3000 V	3000 V	3000 V	3000 V	3000 V	3000 V	3000 V	3000 V	3000 V
Number of components	1	1	1	1	1	1	1	1	1
Maximum on-state current	2 A	3 A	3 A	2 A	2 A	3 A	2 A	3 A	2 A
Maximum operating temperature	80 °C	80 °C	80 °C	80 °C	80 °C	80 °C	80 °C	80 °C	80 °C
Minimum operating temperature	-30 °C	-30 °C	-30 °C	-30 °C	-30 °C	-30 °C	-30 °C	-30 °C	-30 °C
Optoelectronic device types	TRIGGER OUTPUT SSR	TRIGGER OUTPUT SSR	TRIGGER OUTPUT SSR	TRIGGER OUTPUT SSR	TRIGGER OUTPUT SSR	TRIGGER OUTPUT SSR	TRIGGER OUTPUT SSR	TRIGGER OUTPUT SSR	TRIGGER OUTPUT SSR
control voltage	21.6 V	4 V	-	21.6 V	-	-	4 V	21.6 V	9.6 V
input type	DC	DC	-	DC	-	-	DC	DC	DC
Output circuit type	Triac	Triac	-	Triac	-	-	Triac	Triac	Triac
total height	24 mm	32 mm	-	24 mm	-	-	24 mm	32 mm	24 mm
total length	45 mm	43 mm	-	45 mm	-	-	45 mm	43 mm	45 mm
