Contents
Harmony
™
9001K/SK/KX
30 mm push buttons
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
9001K heavy-duty operators with chrome-plated bezels:
Product range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Specifications
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
References
v
Push buttons and mushroom operators
.
v
Multi-function operators
. . . . . . . . . . .
v
v
v
v
v
v
v
v
. . . . . . . . . . . . . . . . . . . . 10
. . . . . . . . . . . . . . . . . . . . 12
Selector switches
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Pilot lights
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Specialty operators
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Contact blocks
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Light modules
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Legend plates
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Accessories
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Replacement parts
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
9001SK corrosion-resistant operators with black plastic bezels:
Product range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Specifications
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
References
v
Push buttons and mushroom operators
.
v
Multi-function operators
. . . . . . . . . . .
v
v
v
v
v
v
v
v
. . . . . . . . . . . . . . . . . . . . 41
. . . . . . . . . . . . . . . . . . . . 43
Selector switches
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Pilot lights
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Specialty operators
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Contact blocks
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Light modules
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Legend plates
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Accessories
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Replacement parts
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
9001KX multi-function operators with chrome-plated
square-head bezels:
Product range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Specifications
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
References
v
Push buttons with contacts
. . .
v
Push buttons without contacts
.
v
v
v
v
v
. . . . . . . . . . . . . . . . . . . . . . . . . . 70
. . . . . . . . . . . . . . . . . . . . . . . . . . 71
Selector switches
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Contact blocks
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Pilot lights
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Legend plates
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Accessories
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
3
Introduction
Harmony
™
9001K/SK/KX
30 mm push buttons
Introduction
1
2
3
4
5
6
7
8
9
10
Schneider Electric’s Harmony
™
9001 30 mm push buttons, pilot lights, selector
switches and mushroom head operators provide robust and reliable solutions for a
wide range of heavy industry applications.
b
9001K
operators are rugged and include chrome-plated bezels. (See page 5.)
b
9001SK
operators include black plastic bezels for corrosion-resistant applications.
(See page 36.)
b
9001KX
operators include chrome-plated square bezels and provide multi-function
operation. (See page 66.)
Product features:
b
Heavy duty, oil-tight, dust-tight, and water-tight without boots. Most units are IP66
rated and are UL types 4, 4X and 13.
b
FINGERSAFE
™
contact blocks and light modules for improved safety
b
Interchangeable light modules, contact blocks, color caps, pilot light lenses and
mushroom heads reduce inventory
b
Integrated earth ground connection (no ground wires required)
b
Easy installation with octagonal ring nut
b
Metal or plastic legend plates
Contact block features:
b
Clear window for status of contact operation and troubleshooting
b
Color coded for easy identification
b
Single screw mounting for quick installation
b
Side-by-side and/or stacked mounting to minimize enclosure space requirements
Light module features:
b
Low-cost incandescent lamps or energy-efficient, long-life LED lamps
b
Wide range of voltages from 24V to 600V
All products are:
b
UL listed and CSA certified
b
CE declaration of conformity
b
RoHS compliant
4
Product range
Harmony
™
9001K/SK/KX
30 mm push buttons
9001K – Complete units
Contact functions
Complete units
Push buttons, spring return
1
2
Full guard
9001KR1ppp See page 10
No guard
9001KR3ppp See page 10
Extended guard
9001KR2ppp See page 10
Mushroom head push buttons
3
4
Spring return 1-3/8 or 2-1/4 in (35 or 57 mm)
9001KR2ppH13 See page 10
Push-pull 1-5/8 in (41 mm)
9001KRppp See page 10
Turn-to-release, trigger action
9001KR16
(1)
See page 12
5
Selector switches, key switches and joystick controllers
6
7
8
9
10
References:
page 10
Dimensions:
page 30
Mounting:
page 31
Selector switches
9001KSppFBHpp See pages 13 to 15
Key switches
9001KSppKpHpp See pages 13 to 15
Joystick controllers
9001KppHp See page 18
Light functions
Pilot lights
BA 9s base mounted super bright LED
9001KPppp See page 17
BA 9s incandescent bulb
9001KPppp See page 17
(1) Complies with EN418/ISO13850 standards for Emergency Stop push buttons when used with circular Legend Plate 9001KN8330 (90 mm diameter) or 9001KN9330 (60 mm diameter).
503591
See page 26.
503590
Specifications:
page 7
5
