D.C. geared motors with brushes
➜
1.2 Nm
10 and 17 Watts
A range of D.C. geared motors with solid metal gears
■
Mechanical rating of gearbox with output shaft
stalled : 1.2 Nm
■
10 and 17 Watt motor power
■
Available in either 12, 24 or 48 V D.C.
■
Gearbox ratios options for 20 to 100 rpm
Specifications
17 Watts
Type
Voltage
Output speed
Ratios (i)
(rpm)
100
26
80
32.5
60
130/3
38
67.6
30
598/7
20
130
General characteristics
Motor
Gearbox
Maximum permitted torque from
gearmotor under continuous
conditions for 10 millions turns Nm
Axial load (dynamic) daN
Radial load (dynamic) daN
Max. output (W)
Nominal output (W)
Gearbox case temperature rise (°C)
Weight (g)
82 802 0
12 V
17 Watts
82 802 0
24 V
10 Watts
82 812 0
12 V
10 watts
82 812 0
24 V
82 802 0X00026Z
82 802 0X032.5Z
82 802 0X43.33Z
82 802 0X067.6Z
82 802 0X85.43Z
82 802 0X00130Z
82 800 0
81 032 1
1.2
3.5
5
16.3
15.7
44
670
●
●
●
●
●
●
82 802 0Y00026Z
82 802 0Y032.5Z
82 802 0Y43.33Z
82 802 0Y067.6Z
82 802 0Y85.43Z
82 802 0Y00130Z
82 800 0
81 032 1
1.2
3.5
5
17
15.6
40
670
●
●
●
●
●
●
82 812 0X00026Z
82 812 0X032.5Z
82 812 0X43.33Z
82 812 0X067.6Z
82 812 0X85.43Z
82 812 0X00130Z
82 810 0
81 032 1
1.2
3.5
5
10.3
9.4
45
670
●
●
●
●
●
●
82 812 0Y00026Z
82 812 0Y032.5Z
82 812 0Y43.33Z
82 812 0Y067.6Z
82 812 0Y85.43Z
82 812 0Y00130Z
82 810 0
81 032 1
1.2
3.5
5
9.5
8.7
46
670
●
●
●
●
●
●
Products adaptations, available on request
■
■
■
■
■
■
■
■
■
Special supply voltages
Special lead lengths
Optional encoder
Special connectors
Special output shafts
Special gearbox ratios
Special gear material
Special output bearings
Special mounting plate
Products and specifications subject to change without notice.
Order/Technical Support - Tel: (800) 677-5311 / FAX: (800) 677-3865 / www.crouzet-usa.com
4/20
Curves
The shaded zone represents the operating range of the geared motor.
The horizontal line marks the maximum torque available in continuous duty cycle for a given life.
For higher torque ratings, service life will be reduced.
Nominal speed and torque curves
82 802 0
mN.m
10000
Nominal speed and torque curves
82 812 0
mN.m
10000
3000
3000
12V
1000
1000
24V-48V
300
1
300
1
100
3
10
20 30
100 200 300
100
3
10
20 30
100 200 300
B
RPM
B
RPM
Dimensions
82 802 0 Standard
25.3 25.3
19.85 19.85
1
126 mm
1.85
1.6
81.6 max.
27.25
21.5
85 max.
4
39.7
29.1
14.5
3
25.1
25.1
15
26.9 max.
2
64.1 max.
B
4 holes M4 depth 7.5 mm
C
3 holes M5 at 120° depth 7.5 mm
D
2 tags IEC 760 series 4.8 x 0.5 mm
E
7 mm across flats
F
(shaft pushed-in
←
)
82 812 0 Standard
25.3 25.3
19.85 19.85
1
111 mm
1.85
7
-0
Ø8
-0.015
Ø12
5
1.6
81.6 max.
27.25
21.5
85 max.
4
39.7
29.1
14.5
3
25.1
25.1
15
26.9 max.
2
64.1 max.
B
8 holes M4 depth 7.5 mm
C
3 holes M5 at 120° depth 7.5 mm
D
2 tags IEC 760 series 4.8 x 0.5 mm
E
7 mm across flats
F
(shaft pushed-in
←
)
Products and specifications subject to change without notice.
Order/Technical Support - Tel: (800) 677-5311 / FAX: (800) 677-3865 / www.crouzet-usa.com
4/21
7
-0
Ø8
-0.015
Ø12
4
5
