Amphenol
®
IDS-46-8
Max-M12 Connector
Amphenol Industrial Products Group introduces our
ruggedized M12 high speed data connector, the Max-M12.
High speed data transmission connection systems
have traditionally been implemented into commercial
applications with little regard to high vibration, high
temperature and overall harsh environment demands.
With the increased implementation of these high speed
Datalink connection systems into more heavy duty / harsh
environment surroundings, the need for a more robust and
ruggedized connection system has surfaced.
Based on the IEC 61076-2-101 and SAE J 2839 standards
the Max-M12 connection system makes it the perfect
solution for the ultra rugged applications that sometimes
exist in markets dealing with Heavy Equipment, Rail &
Mass Transit, Process Control, Factory Automation, etc.
Features:
• HDM 12 Versions Available
- Plastic or Metal (for shielding)
- 90° right angle and straight connector offerings
- 3, 4, and 5 way circuit patterns
- A, B, D & P polarity codes – based on
IEC 61076-2-101
- Terminals for solder to wire or pins for PCB applications
• Available as stand-alone connectors & cable assemblies
(standard and overmolded)
• Terminals capable of being terminated to:
- 0.8 mm2 (18 AWG) or 0.5 mm2 (20 AWG)
conductors as defined by SAE J1128 and 0.75 mm2
and 0.50 mm2 conductors as defined by ISO 6722
• 444 N (100 LBF) pull force on cable
• Backward compatible with IEC 61076-2-101 (M12)
• More resistant to terminal damage
• Extreme environmental testing based on J2839 requirements
- High pressure wash down
• Provisions for overall cable shield or drain wire to the
connector plug housing
• RoHS compliant
www.amphenol-industrial.com
Max-M12 Connector
SPECIFICATION
Operating Voltage
Current Rating
Temperature Rating
Dielectric Withstanding Voltage
Insulation Resistance
Rated Impulse Voltage
Contact Resistance
Vibration, Sine
Shock, Half Sine
Temperature Life
Durability
Salt Fog
Protection Class
Wire Gauge
Cable OD.
Recommended Torque
Connector Retention
Contact Retention
Panel Thickness
Shell Plating
HOW TO ORDER
5 pin - 60V AC/DC
3 & 4 pin - 250V AC/DC
4A MAX.
-55ºC - +125ºC
-55ºC - +150ºC (with Viton Seals)
1000V
>20 Megohms
1500V
<10 mΩ
10 - 2000 Hz, 20g, <1 us
10 CYCLES, 50g, 11ms, <1 us
1000H AT 125ºC + 3ºC
100 CYCLES MIN.
240H
IP67 or Above
0.5 mm2 (20AWG) or
0.8 mm2 (18AWG)/ 0.75 mm2
ø 12.7 MAX.
M12 THREAD, 0.8 - 1.0 Nm
444 N MIN
110 N MIN
1-6 mm
Nickel
SAE J2839, 4 . 2 . 3 . 20
SAE J2839, 4 . 2 . 3 . 18
IEC 60664
IEC 60512
TEST 5B
SAE J2839, 4 . 2 . 3 . 13
IEC 60512,
IEC 60664-1
IEC 60512
SAE J2839, 4 . 2 . 3 . 15
SAE J2839, 4 . 2 . 3 . 16
SAE J2839, 4 . 2 . 3 . 7
SAE J2839, 4 . 2 . 3 . 11
SAE J2839, 4 . 2 . 3 . 12
IEC 60529
SAE J1128 / ISO 6722
TEST 4A
SAE J2839, 4 . 2 . 3 . 3
HDM12
+
P
+
M
+
05
+
D
+
1
+
ST
+
M
+
V
+
H
+
P
1
HDM12
Product
Line
P
2
P
Shell Line
Plug
M
3
M
Gender
Male
4
05
Insert
Arrangement
03
3 Pole
A
5
D
Coding
A-Coding
6
1
Contact
Finish
1
Gold
7
ST
Backshell
ST
Straight
M
8
M
Backshell
Material
Metal
V
9
V
Seal
Viton
Rubber
Seal
Omit for
Standard
Rubber
Seal
H
10
H
Voltage
Rating
240V AC/
DC
Omit for
Standard
60V AC/
DC
11
P
Contact Style
PR
PC Tail
Contacts
Right Angle
PC Tail
Contacts
Straight
Omit for
Solder
Contacts
1
2
3
4
5
6
7
8
9
10
11
HDM12
R
Receptacle
F
Female
04
4 Pole
B
B-Coding
2
Silver
RA
Right
Angle
No
Backshell
P
Plastic
Omit
for no
Backshell
PS
05
5 Pole
D
P
D-Coding
P-Coding
4
Nickel
XX
Example Order:
HDM12, Receptacle, Female, 4 Pole, A-Coding, Silver, Straight, Metal, Standard Rubber Seal,
240V AC/DC, Straight PC Tail Contacts:
HDM12 R F 04 A 2 ST M H PS
