Crystal Units
Surface Mount Type CX5032GB (CX-53F)
5.0×3.2mm for Consumer Products
Features
• Crystal unit for Consumer Products
• Small and low profile (T=1.1mm max.)
(5.0×3.2×1.0mm)
• Ceramic package
• Reflow compatible
How to Order
CX5032GB 27000
□□ □ □ □ □□
①
②
③ ④⑤⑥ ⑦
①
Series
③
Load Capacitance
H0
EQ
12 pF
-10
to
+70°C
②
Frequency
④
Frequency Tolerance
H
±20×10
-
6
±30×10
-
6
Applications
• Digital Electronics
• Consumer Products
• Car audio and accessories
⑤
Operating Temp. Range
⑥
Frequency Temp. Stability
⑦
Individual Specification
Packaging (Tape & Reel 3000/ 1000 pcs./ reel)
RoHS Compliant
Specifications
Item
Frequency Range
Overtone Order
Load Capacitance
Frequency Tolerance
Motional Series Resistance
Drive Level
Operating Temp. Range
Storage Temp. Range
Frequency Temp. Characteristics
• Please contact us for other specifications.
Symbol
f
_nom
OT
CL
f
_tol
R1
DL
T
_use
T
_stg
f
_tem
±20
Table 1
Table 2
Specification
7372.8 to 54000
Fundamental
8
12
Units
kHz
―
pF
×10
-
6
ohm
μW
°C
°C
×10
-
6
25°C±3°C
Remarks
-10
to
+70
-40
to
+85
±30
Freq. deviation from the value at 25°C
Table1 Motional Series Resistance
Frequency Range
7372.8≤f
_nom
<
9500kHz
9500≤f
_nom
<10000kHz
10000≤f
_nom
<14000kHz
14000≤f
_nom
<20000kHz
20000≤f
_nom
<30000kHz
30000≤f
_nom
≤54000kHz
Motional Series Resistance
300Ω max.
200Ω max.
150Ω max.
100Ω max.
70Ω max.
50Ω max.
Table2 Level of Drive
Frequency Range
7372.8≤f
_nom
<16000kHz
16000≤f
_nom
<25000kHz
25000≤f
_nom
≤54000kHz
Level of Drive
10μW (500μW max.)
10μW (300μW max.)
10μW (100μW max.)
Dimensions
(Unit: mm)
Recommended Land Pattern
(Unit: mm)
3.2±0.2
5.0±0.2
+0.1
1.10
−0.2
1.9
2.0
4.1
CONNECTION
(TOP VIEW)
1.9
C 0.3
1.3
2.4
1.3
2.4
