LPS5010-821MRC

Description
Fixed Inductors LPS5010 Low Profile .82uH 1.5A 20% SMD
CategoryPassive components
File Size186KB,2 Pages
ManufacturerCOILCRAFT
Websitehttp://www.coilcraft.com/
Download Datasheet Parametric View All

LPS5010-821MRC Online Shopping

Suppliers Part Number Price MOQ In stock
LPS5010-821MRC - - View Buy Now

LPS5010-821MRC Overview

Fixed Inductors LPS5010 Low Profile .82uH 1.5A 20% SMD

LPS5010-821MRC Parametric

Parameter NameAttribute value
Product AttributeAttribute Value
ManufacturerCOILCRAFT
Product CategoryFixed Inductors
RoHSDetails
ProductPower Inductors
Termination StyleSMD/SMT
Termination-
Mounting StyleSMD/SMT
PackagingCut Tape
PackagingMouseReel
PackagingReel
Factory Pack Quantity1000
Web
page
Sample
& buy
Tools &
software
Support
& FAQ
Document 536-1
Shielded Power Inductors – LPS5010
• Very low DCR; excellent current handling
• 5.0 × 5.0 mm footprint; less than 1.0 mm tall
Designer’s Kit C407
contains 3 each of all values
Core material
Ferrite
Core and winding loss
See
www.coilcraft.com/coreloss
Environmental
RoHS compliant, halogen free
Terminations
RoHS compliant matte tin over nickel over silver.
Other terminations available at additional cost.
Weight
70 – 75 mg
Ambient temperature
–40°C to +85°C with (40°C rise)
Irms
current.
Maximum part temperature
+125°C (ambient + temp rise).
Derating.
Storage temperature
Component: –40°C to +125°C.
Tape and reel packaging: –40°C to +80°C
Resistance to soldering heat
Max three 40 second reflows at
+260°C, parts cooled to room temperature between cycles
Moisture Sensitivity Level (MSL)
1 (unlimited floor life at <30°C /
85% relative humidity)
Failures in Time (FIT) / Mean Time Between Failures (MTBF)
38 per billion hours / 26,315,789 hours, calculated per Telcordia SR-332
Packaging
1000/7″ reel; 3000/13″ reel Plastic tape: 12 mm wide,
0.3 mm thick, 8 mm pocket spacing, 1.02 mm pocket depth
Recommended pick and place nozzle
OD: 5 mm; ID:
2.5 mm
PCB washing
Tested to MIL-STD-202 Method 215 plus an additional
aqueous wash. See
Doc787_PCB_Washing.pdf.
Part number
1
Isat
(A)
DCR SRF
2
max
3
4
Inductance
typ
10% 20% 30%
±20% (µH) (Ohms) (MHz) drop drop drop
5
Irms
(A)
6
20°C 40°C
rise rise
2.0
1.2
0.90
0.88
0.86
0.85
0.75
0.74
0.73
0.68
0.46
0.40
0.33
0.25
0.21
0.19
0.17
0.15
0.13
0.11
2.7
1.5
1.4
1.2
1.1
0.98
0.92
0.85
0.80
0.75
0.62
0.55
0.44
0.35
0.28
0.25
0.23
0.20
0.185
0.150
1. Please specify
termination
and
packaging
codes:
LPS5010-684MRC
Termination: R
= RoHS compliant matte tin over
nickel over silver.
Special order, added cost:
Q
= RoHS tin-silver-copper (95.5/4/0.5)
or
P
= non-RoHS tin-lead (63/37).
Packaging: C
= 7″ machine-ready reel. EIA-481
embossed plastic tape (1000 parts
per full reel).
B
= Less than full reel. In tape, but not
machine ready.
To have a leader and trailer added
($25 charge), use code letter C
instead.
D
= 13″ machine-ready reel. EIA-481
embossed plastic tape. Factory
order only, not stocked (3500 parts
per full reel).
2. Inductance tested at 100 kHz, 0.1 Vrms using an
Agilent/HP 4192A. Inductance at 1 MHz is the same for
parts with SRF
≥10
MHz.
3. DCR measured on a micro-ohmmeter.
4. SRF measured using Agilent/HP 8753ES or equivalent.
5. DC current at 25°C that causes the specified induc-
tance drop from its value without current.
Click for temperature derating information.
6. Current that causes the specified temperature rise from
25°C ambient. This information is for reference only and
does not represent absolute maximum ratings.
Click for temperature derating information.
7. Electrical specifications at 25°C.
Refer to Doc 362 “Soldering Surface Mount Components”
before soldering.
LPS5010-471MR_
LPS5010-821MR_
LPS5010-152MR_
LPS5010-222MR_
LPS5010-332MR_
LPS5010-472MR_
LPS5010-562MR_
LPS5010-682MR_
LPS5010-103MR_
LPS5010-153MR_
LPS5010-223MR_
LPS5010-333MR_
LPS5010-473MR_
LPS5010-683MR_
LPS5010-104MR_
LPS5010-124MR_
LPS5010-154MR_
LPS5010-224MR_
LPS5010-334MR_
LPS5010-474MR_
LPS5010-564MR_
LPS5010-684MR_
0.47
0.82
1.5
2.2
3.3
4.7
5.6
6.8
10
15
22
33
47
68
100
120
150
220
330
470
560
680
0.038
0.058
0.072
0.100
0.125
0.175
0.240
0.255
0.350
0.500
0.670
1.05
1.45
2.00
3.10
3.50
4.25
6.25
8.60
12.7
15.7
20.0
290
195
168
144
105
76
75
71
51
39
32
26
20
15
12
11
9.0
7.0
5.5
4.5
3.1
2.3
1.7
1.4
1.1
0.95
0.90
0.82
0.66
0.55
0.47
0.38
0.31
0.26
0.21
0.20
0.18
0.15
0.12
0.090
3.3
2.5
1.8
1.5
1.2
1.1
0.97
0.90
0.72
0.59
0.51
0.42
0.34
0.29
0.23
0.22
0.20
0.16
0.13
0.11
3.4
2.6
1.9
1.6
1.3
1.1
1.00
0.93
0.74
0.62
0.53
0.43
0.36
0.30
0.24
0.23
0.21
0.17
0.14
0.11
4.0 0.090 0.10 0.10
3.7 0.090 0.097 0.10
0.10 0.135
0.090 0.125
US
+1-847-639-6400 sales@coilcraft.com
UK
+44-1236-730595 sales@coilcraft-europe.com
Taiwan
+886-2-2264 3646 sales@coilcraft.com.tw
China
+86-21-6218 8074 sales@coilcraft.com.cn
Singapore
+ 65-6484 8412 sales@coilcraft.com.sg
Document 536-1
Revised 09/02/15
© Coilcraft Inc. 2017
This product may not be used in medical or high
risk applications without prior Coilcraft approval.
Specification subject to change without notice.
Please check web site for latest information.
