SMDIG02680K100KM00 datasheet, PDF

Datasheet> All Categories > Passive components> SMDIG02680K100KM00

SMDIG02680K100KM00: DescriptionFilm Capacitors SMD-PPS 0.068 uF 400 VDC 10.2x7.6x5 SC4030; CategoryPassive components; File Size171KB，7 Pages; ManufacturerWIMA; Websitehttps://www.wima.de/

Download Datasheet Parametric View All

SMDIG02680K100KM00 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	SMDIG02680K100KM00	-	-	View	Buy Now

SMDIG02680K100KM00 Overview

Film Capacitors SMD-PPS 0.068 uF 400 VDC 10.2x7.6x5 SC4030

SMDIG02680K100KM00 Parametric

Parameter Name	Attribute value
Product Attribute	Attribute Value
Manufacturer	WIMA
Product Category	Film Capacitors
Termination Style	SMD/SMT
Product	SMD Film Capacitors
Dielectric	Polyphenylene Sulfide (PPS)
Capacitance	0.068 uF
Voltage Rating AC	400 VAC
Voltage Rating DC	200 VDC
Tolerance	10 %
Package / Case	4030
Length	10.2 mm
Width	7.6 mm
Height	5 mm
Packaging	Bulk
Type	Metallized Polyphenylene Sulfide (PPS), SMD Film Capacitors with Box Encapsulation
Capacitance - nF	68 nF
Capacitance - pF	68000 pF

Preview

Download Datasheet

View All

WIMA SMD-PPS

Metallized Polyphenylene-Sulphide (PPS) SMD Film Capacitors with

Box Encapsulation. Capacitances from 0.01

to 2.2

mF.

Rated Voltages from 63 VDC to 1000 VDC. Size Codes from 1812 to 6054.

Special Features

Size codes 1812, 2220, 2824,

4030,5040 and 6054 with PPS

and encapsulated

Operating temperature up to 140° C

Self-healing

Suitable for lead-free soldering

Low dissipation factor

Low dielectric absorption

Very constant capacitance value

versus temperature

According to RoHS 2011/65/EU

Electrical Data

Capacitance range:

0.01

F to 2.2

Rated voltages:

63 VDC, 100 VDC, 250 VDC, 400 VDC,

630 VDC, 1000 VDC

Capacitance tolerances:

±20%, ±10% (±5% available subject

to special enquiry)

Operating temperature range:

–55) C to +140) C

Climatic test category:

55/140/56 in accordance with IEC

Insulation resistance

at +20+ C:

test



0.33



1 x 10

M¸

(mean value: 3 x 10

M¸)



3 x 10

M¸

(mean value: 6 x 10

M¸)

63 VDC 50 V

100 VDC 100 V



250 VDC 100 V

Test voltage:

1.6 U

, 2 sec.

Voltage derating:

For DC and AC voltages a voltage

derating factor of 1% per K must be

applied from +100+ C and of 2% per K

from +125+ C.

Reliability:

Operational life



300 000 hours

Failure rate



2 fit (0.5 x U

and 40+ C)

Typical Applications

For general applications in high

temperature circuits e.g.

By-pass

Blocking

Coupling and decoupling

Timing

Filtering

Oscillating circuits

0.33

< C



2.2



3000 sec (M¸ x

mF)

(mean value: 6000 sec)



6000 sec (M¸ x

mF)

(mean value: 12 000 sec)

Measuring time: 1 min.

Dissipation factors

at +20) C: tan

at f

1 kHz

10 kHz

100 kHz



0.1



15 x 10

-4



20 x 10

-4



50 x 10

-4

0.1

< C



1.0



20 x 10

-4



25 x 10

-4

–

C > 1.0



20 x 10

-4

–

Construction

Dielectric:

Polyphenylene-sulphide (PPS) film

Capacitor electrodes:

Vacuum-deposited

Internal construction:

Maximum pulse rise time:

for pulses equal to the rated voltage

Capacitance

0.01

0.033

0.1

0.33

1.0

...

0.022

0.068

0.22

0.68

2.2

Pulse rise time V/

sec

max. operation/test

100 VDC 250 VDC 400 VDC

25/250

15/150

10/100

5/50

3/30

30/300

20/200

12/120

6/60

–

35/350

25/250

15/150

8/80

–

63 VDC

25/250

15/150

10/100

5/50

3/30

630 VDC 1000 VDC

40/400

28/280

–

45/450

32/320

–

Plastic film

Vacuum-deposited

electrode

Metal contact layer

(schoopage)

Terminating plate

Dip Solder Test/Processing

Resistance to soldering heat:

Test Tb in accordance with DIN IEC

60068-2-58/DIN EN 60384-20.

Soldering bath temperature max. 260+ C.

Soldering duration max. 5 sec.

Change in capacitance

C/C



5 %.

Soldering process:

Re-flow soldering (see temperature/time

graphs page 13).

Packing

Available taped and reeled in blister pack.

Detailed taping information and graphs

at the end of the catalogue.

For further details and graphs please

refer to Technical Information.

Encapsulation:

Solvent-resistant, flame-retardant plastic

case, UL 94 V-0

Terminations:

Tinned plates.

Marking:

Box colour: Black.

04.16
