ALUMINUM ELECTROLYTIC CAPACITORS
ET
Bi-Polarized, Wide Temperature Range
series
Bi-polarized series for operations over wide temperature range of – 55 ~ +105
°C
.
Adapted to the RoHS directive (2002/95/EC).
ET
High
Temperature
VP
Specifications
Item
Category Temperature Range
Rated Voltage Range
Rated Capacitance Range
Capacitance Tolerance
Leakage Current
tan
δ
Performance Characteristics
– 55 ~ +105°C
6.3 ~ 100V
0.47 ~ 1000µF
± 20% at 120Hz, 20°C
After 5 minutes' application of rated voltage, leakage current is not more than 0.03CV or 3 (µA), whichever is greater.
Measurement frequency : 120Hz, Temperature : 20°C
Rated voltage (V)
tan
δ
(MAX.)
6.3
0.24
10
0.20
16
0.16
6.3
4
8
10
3
6
25
0.16
16
2
4
35
0.14
25
2
4
50
0.12
35
2
3
50
2
3
63
0.10
63
2
3
100
0.09
100
2
3
Measurement frequency : 120Hz
Stability at Low Temperature
Rated voltage (V)
Z– 25°C / Z+20°C
Impedance ratio
ZT / Z20 (
MAX.
)
Z– 40°C / Z+20°C
Endurance
After 1000 hours' application of rated voltage at 105°C with the
polarity inverted every 250 hours, capacitors meet the
characteristic requirement listed at right.
Capacitance change
tan
δ
Leakage current
Within ±20% of initial value
200% or less of initial specified value
Initial specified value or less
Shelf Life
Marking
After storing the capacitors under no load at 105°C for 1000 hours, and after performing voltage treatment based on JIS C 5101-4
clause 4.1 at 20°C, they will meet the specified value for endurance characteristics listed above.
Printed with white color letter on black sleeve.
Radial Lead Type
Type numbering system (Example : 10V 47
µ
F)
f
Sleeve (P.E.T.)
D+
0.5MAX
d
UET 1 A 4 7 0 MED
P ±
0.5
1 2 3 4 5 6 7 8 9 10 11
Configuration
Capacitance tolerance (±20%)
Rated Capacitance (47
m
F)
Rated voltage (10V)
Series name
Type
Configuration
Pb-free leadwire
f
D
Pb-free PET sleeve
5
DD
6.3
ED
8 á 10
PD
12.5 á 16
HD
f
(
f
6.3up)
Pressure
relief vent
L+
MAX
15
MIN
f
D
4
MIN
(L < 20) 1.5
(L 20) 2.0
5 6.3 8 10 12.5 16
P 2.0 2.5 3.5 5.0 5.0 7.5
f
d 0.5 0.5 0.6 0.6 0.6 0.8
(mm)
•
Please refer to page 21 about the end seal configulation.
Dimensions
Cap. (µF)
V
Code
6.3
0J
10
1A
16
1C
25
1E
35
1V
0.47
1
2.2
3.3
4.7
10
22
33
47
100
220
330
470
1000
R47
010
2R2
3R3
4R7
100
220
5
×
11
330
470 6.3
×
11
8
×
11.5
101
221 10
×
12.5
331 10
×
16
471 10
×
20
102 12.5
×
25
46
61
104
168
229
300
550
5
×
11
6.3
×
11
6.3
×
11
10
×
12.5
10
×
16
10
×
20
12.5
×
20
16
×
25
5
×
11
42 6.3
×
11
57 6.3
×
11
8
×
11.5
67
125 10
×
12.5
204 10
×
20
275 12.5
×
20
371 12.5
×
25
668 16
×
25
30
51
63
89
139
279
346
460
746
5
×
11
5
×
11
6.3
×
11
8
×
11.5
10
×
12.5
10
×
16
12.5
×
25
12.5
×
25
16
×
25
16
×
31.5
5
×
11
23
34 6.3
×
11
8
×
11.5
55
79 10
×
12.5
100 10
×
12.5
164 10
×
20
336 12.5
×
25
414 16
×
25
543 16
×
25
871
25
40
68
89
111
196
364
493
586
50
1H
5
×
11
5
×
11
5
×
11
5
×
11
6.3
×
11
8
×
11.5
10
×
12.5
10
×
16
10
×
20
12.5
×
25
16
×
25
16
×
31.5
63
1J
8
12
18
22
6.3
×
11
29
6.3
×
11
51
8
×
11.5
82
10
×
16
107
10
×
20
146
10
×
20
264 12.5
×
25
443
16
×
31.5
593
26
31
53
96
129
157
275
486
100
2A
5
×
11
5
×
11
6.3
×
11
8
×
11.5
8
×
11.5
10
×
12.5
10
×
20
12.5
×
20
12.5
×
25
16
×
25
10
15
22
32
39
64
114
164
200
304
Case size
Rated
φ
D
×
L (mm)
ripple
Rated Ripple (mArms) at 105°C 120Hz
Frequency coefficient of rated ripple current
Cap.(µF)
Frequency
0000
~ 4700
0100
~ 4700
1000
50 Hz
0.75
0.80
0.85
120 Hz
1.00
1.00
1.00
300 Hz
1.35
1.23
1.10
1 kHz
1.57
1.34
1.13
10 kHz ~
2.00
1.50
1.15
Please refer to page 21, 22, 23 about the formed or taped product spec.
Please refer to page 3 for the minimum order quantity.
CAT.8100V
