SMT POWER INDUCTORS
Unshielded Drum Core - PF0504NL Series
Height:
11.43mm Max
Footprint:
18.54mm x 15.24mm Max
Current Rating:
up to 20A
Inductance Range:
0.68µH to 150µH
260°C reflow peak temperature qualified
Leaded technology compatible
Electrical Specifications @ 25°C — Operating Temperature -40°C to +125°C
6
Part
5
Number
PF0504.681NL
PF0504.122NL
PF0504.222NL
PF0504.332NL
PF0504.392NL
PF0504.472NL
PF0504.682NL
PF0504.103NL
PF0504.183NL
PF0504.223NL
PF0504.333NL
PF0504.403NL
PF0504.473NL
PF0504.104NL
PF0504.154NL
Inductance
1
@ Irated
(µH TYP)
0.68
1.2
2.2
3.3
3.9
4.7
6.8
10
18
22
33
40
47
100
150
Irated
2
(A)
20.0
17.7
14.7
13.7
11.7
10.8
9.0
7.1
6.0
5.4
4.4
4.0
3.5
2.3
2
DCR
(mΩ MAX)
2.0
2.6
3.7
4.3
6.7
6.9
9.8
15
25
27
42
50
55
153
200
Inductance
@ 0A
DC
(µH ±20%)
0.68
1.2
2.2
3.3
3.9
4.7
6.8
10
18
22
33
40
47
100
150
Saturation Current
3
I
SAT
(A)
64
48
35
29
26
24
20
16
13
11
9
8
7
5
4
Heating Current
4
I
DC
(A)
20.0
17.7
14.7
13.7
11.7
10.8
9.0
7.1
6.0
5.4
4.4
4.0
3.5
2.3
2
Mechanical
Dot locates
start lead
Schematic
.110
2,79 REF
.450
11,43 MAX
1
.730
18,54
MAX
PF0504.XXXNL
Date Code
Country of Origin
.490
12,45 REF
2
.600
15,24 MAX
.005/0,13
.945
24,00
.115
2,92 REF
SUGGESTED PAD LAYOUT
Weight
. . . . . . . . . . .6.0 grams
Tape & Reel
. . . . . . . .160/reel
Dimensions:
Inches
mm
Unless otherwise specified,
all tolerances are ± .004
0,10
.742
18,85
1.732
± .012
44,00
± 0,30
.522
13,25
TAPE & REEL
LAYOUT
.612
15,55
USER DIRECTION
OF FEED
USA 858 674 8100
•
Germany 49 7032 7806 0
•
Singapore 65 6287 8998
•
Shanghai
86 21 54643211 / 2
•
China 86 755 33966678
•
Taiwan 886 3 4641811
www.pulseeng.com
23
SPM2007 (11/07)
SMT POWER INDUCTORS
Unshielded Drum Core - PF0504NL Series
Notes from Tables
1. Inductance at Irated is a typical inductance value measured when
the inductor is subjected to the rated current.
2. The rated current listed is the lower of the saturation current @
25°C or the heating current.
3. The saturation current, Isat, is the current at which the
component inductance drops by 20% (maximum) at an ambient
temperature of 25°C. This current is determined by placing the
component in the specified ambient environment and applying a
short duration pulse current (to eliminate self-heating effects) to
the component.
4. The heating current, I
DC
, is the DC current required to raise the
component temperature by approximately 40°C. The heating
current is determined by mounting the component on a typical
PCB and applying current for 30 minutes.
5. Optional Tape & Reel packaging can be ordered by adding a "T"
suffix to the part number (i.e. PF0504.681NL becomes
PF0504.681NLT). Pulse complies to industry standard tape and
reel specification EIA481.
6. The temperature of the component (ambient plus temperature
rise) must be within the stated operating temperature range.
Inductance vs Current Characteristics
Percentage of the initial inductance
120%
100%
80%
60%
40%
20%
0%
0.0
0.2
0.4
0.6
0.8
1.0
1.2
1.4
1.6
Normalized Isat
USA 858 674 8100
•
Germany 49 7032 7806 0
•
Singapore 65 6287 8998
•
Shanghai
86 21 54643211 / 2
•
China 86 755 33966678
•
Taiwan 886 3 4641811
www.pulseeng.com
24
SPM2007 (11/07)
