SMT POWER INDUCTORS
Unshielded Drum Core - PF0581NL Series
Height:
4.42mm Max
Footprint:
10.32mm Typ x 9.32mm Max
Current Rating:
up to 2.5A
Inductance Range:
10µH to 560µH
260°C reflow peak temperature qualified
Electrical Specifications @ 25°C — Operating Temperature -40°C to +125°C
6
Part
5
Number
PF0581.103NL
PF0581.123NL
PF0581.153NL
PF0581.183NL
PF0581.223NL
PF0581.273NL
PF0581.333NL
PF0581.393NL
PF0581.473NL
PF0581.563NL
PF0581.683NL
PF0581.823NL
PF0581.104NL
PF0581.124NL
PF0581.154NL
PF0581.184NL
PF0581.224NL
PF0581.274NL
PF0581.334NL
PF0581.394NL
PF0581.474NL
PF0581.564NL
Inductance
@Irated
1
(μH TYP)
9.5
11
14
17
21
26
31
37
45
53
65
78
95
110
140
170
210
260
310
370
450
530
Irated
2
(A)
2.50
2.30
2.00
1.90
1.70
1.50
1.30
1.20
1.10
1.00
0.93
0.85
0.76
0.70
0.63
0.56
0.53
0.46
0.42
0.39
0.35
0.32
DCR
(mΩ MAX)
43
48
60
66
84
96
115
151
166
199
233
262
333
376
500
620
721
949
1100
1245
1526
1870
Inductance
@0Adc
(μH ±10%)
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
Saturation
3
Current
Isat
(A)
2.50
2.30
2.00
1.90
1.70
1.50
1.30
1.20
1.10
1.00
0.93
0.85
0.76
0.70
0.63
0.56
0.53
0.46
0.42
0.39
0.35
0.32
Heating
4
Current Idc
(A)
3.25
3.15
2.70
2.50
2.25
2.05
1.90
1.73
1.65
1.52
1.37
1.29
1.16
1.10
0.97
0.84
0.79
0.68
0.63
0.60
0.53
0.51
Mechanical
.174
4,42
MAX
.071
TYP
1,80
Schematic
1
XXXNL
DATE CODE
.367
9,32
MAX
(1)
(2)
.375
9,52
TYP
2
Ø
.406
TYP
10,32
.005/0,13
.079
TYP
2,00
.201
5,10
.415
TYP
10,54
SUGGESTED PAD LAYOUT
Weight
. . . . . . . . . . .1.2 grams
Tape & Reel
. . . . . . . .900/reel
.409
Ø
10,40
.945
± .012
24,00
± 0,30
.472
12,00
Dimensions:
Inches
mm
Unless otherwise specified,
all tolerances are ± .004
0,10
TAPE & REEL LAYOUT
USER DIRECTION OF
USA 858 674 8100
•
Germany 49 7032 7806 0
•
Singapore 65 6287 8998
•
Shanghai
86 21 54643211 / 2
•
China 86 755 33966678
•
Taiwan 886 3 4641811
www.pulseeng.com
15
SPM2007 (11/07)
SMT POWER INDUCTORS
Unshielded Drum Core - PF0581NL Series
Notes from Tables
1. Inductance at Irated is a typical inductance value for the compo-
nent taken at rated current.
2. The rated current listed is the lower of the saturation current @
25°C or the heating current.
3. The saturation current, Isat, is the current at which the
component inductance drops by 10% (maximum) at an ambient
temperature of 25°C. This current is determined by placing the
component in the specified ambient environment and applying a
short duration pulse current (to eliminate self-heating effects) to
the component.
4. The heating current, I
DC
, is the DC current required to raise
the component temperature by approximately 45°C. The heating
current is determined by mounting the component on a typical
PCB and applying current for 30 minutes.
5. Optional Tape & Reel packaging can be ordered by adding a "T"
suffix to the part number (i.e. PF0581.103NL becomes
PF0581.103NLT). Pulse complies to industry standard tape and
reel specification EIA481.
6. The temperature of the component (ambient plus temperature
rise) must be within the stated operating temperature range.
Typical Inductance vs Current Characteristics
Percentage of the initial inductance
110
100
90
80
70
60
50
0
0.2
0.4
0.6
0.8
1.0
1.2
1.4
1.6
1.8
Normalized Isat
USA 858 674 8100
•
Germany 49 7032 7806 0
•
Singapore 65 6287 8998
•
Shanghai
86 21 54643211 / 2
•
China 86 755 33966678
•
Taiwan 886 3 4641811
www.pulseeng.com
16
SPM2007 (11/07)
