HOME PHONE NETWORKING
BANDPASS FILTER
Supports HomePNA
™
1M8 Technology
Includes protection circuitry, isolation and
EMI filtering
Designed to withstand 235°C peak infrared
reflow temperature
Electrical Specifications @ 25°C — Operating Temperature -40°C to 85°C
PARAMETER
HPN 1M8 Insertion Loss
6.0 MHz
7.5 MHz
9.0 MHz
HPN 1M8 Attenuation
1.0 MHz
27 MHz
HPN 1M8 Return Loss
(6.0 MHz to 9.0 MHz)
Isolation
TEST CONDITION
Input (1-2), Output (10-9)
HP-8751A S21 100
Ω
MIN.
NOM.
3.2
2.8
3.4
50
60
14 avg.
2000
60
70
MAX.
4
3.5
4
UNITS
dB
dB
dB
dB
dB
dB
Vrms
Input (1-2), Output (10-9)
HP-8751A S21 100
Ω
Input (10-9), 100
Ω
(1-2)
HP-8751A S11 100
Ω
Pins (1-2) short to (10-9) shorted
NOTE:
Filters are shipped in tubes unless Tape & Reel is specified. Please add the suffix
"T"
(i.e.B6003T) for Tape & Reel orders.
Mechanical
B6003
.930 MAX
23,62
16X .090
2,29
.510 MAX
12,95
DATE CODE
COUNTRY OF ORIGIN
Schematic
CHIP
.540
13,72
(+) 1
1:1
MEDIA
10 TIP
B6003
Band
Pass
Filter
(-) 2
Z
9 RING
16X .018
0,46
7X .100
2,54
.700
17,78
.100
2,54
7X .100 (=.700)
2,54 (=17,78)
16X .040
1,02
GND 3
SUGGESTED PAD LAYOUT
.380
9,65
0° – 8°
.225
5,72
16X .035
0,89
Weight
. . . . . . . . . . . . . .2.5 grams
Tape & Reel
. . . . . . . . . . . .250/reel
Tube
. . . . . . . . . . . . . . . . . .20/tube
Dimensions:
Inches
mm
Unless otherwise specified, all tolerances are ± .010
0,25
.004/0,10
16 SURFACES
16X .035
0,89
For More Information :
UNITED STATES
(Worldwide)
12220 World Trade Drive
San Diego, CA 92128
U.S.A.
http://www.pulseeng.com
TEL: 858 674 8100
FAX: 858 674 8262
UNITED KINGDOM
(Northern Europe)
1 & 2 Huxley Road
The Surrey Research Park
Guildford, Surrey GU2 5RE
United Kingdom
TEL: 44 1483 401700
FAX: 44 1483 401701
FRANCE
SINGAPORE
(Southern Europe) (Southern Asia)
Zone Industrielle
F-39270
Orgelet
France
TEL: 33 3 84 35 04 04
FAX: 33 3 84 25 46 41
150 Kampong Ampat
#07-01/02
KA Centre
Singapore 368324
TEL: 65 6287 8998
FAX: 65 6280 0080
TAIWAN, R.O.C.
(Northern Asia)
3F-4, No. 81, Sec. 1
HsinTai Wu Road
Hsi-Chih, Taipei Hsien
Taiwan, R.O.C.
Tel: 886 2 2698 0228
FAX: 886 2 2698 0948
HONG KONG
(China/Hong Kong)
9/F, Phase 2, Tai Sang
Shatin Warehouse Centre
6 Wong Chuk Yeung Street
Fotan, Shatin, Hong Kong
TEL: 852 2788 6588
FAX: 852 2776 1055
DISTRIBUTOR
Performance warranty of products offered on this data sheet is limited to the parameters specified. Data is subject to change without notice. Other brand and product names mentioned herein may
be trademarks or registered trademarks of their respective owners.
Printed on recycled paper. ©2003, Pulse Engineering, Inc.
B916.A (12/03)
