Precision SMD TCXO/VCTCXO
AST3TQ53
Moisture Sensitivity Level (MSL) – 3
FEATURES:
• Standard available frequencies:
10.00, 12.80, 16.384, 19.20, 19.44,
• LVCMOS Output or Clippled Sine Wave output
• Frequency stabilities to include ±50ppb, ±100ppb and ±280ppb
over -40ºC to +85ºC operating temperature range
• Excellent Phase Noise, Harmonics and Spurious content
• Typical rms jitter of 400fs @ 40MHz carrier & 1.0ps @ 10MHz
carrier over 12kHz to 20MHz BW
20.00, 24.576, 25.00, 26.00, 30.72, 40.00 MHz
ESD Sensitive
Pb
RoHS/RoHS II Compliant
5.0 x 3.2 x 2.0mm
APPLICATIONS:
• COTS Military Radios & other Communication Hardware
• WiMax,
• LTE, BTS
• CATV, LAN, LMDS
• GPS Tracking with Hold-Over accuracy
• Test & Measurement Equipment
• Point-to-Point communication networks
STANDARD SPECIFICATIONS:
Maximum Rating
Parameters
Storage Temperature Range
Supply Voltage
Control Voltage
ESD, HBM/CDM/MM
Rating
-55 to +125°C
-0.5 to 6V
0 to 3V
4kV/2kV/200V
Key Electrical Specifications
Parameters
Frequency Range
Standard Frequencies
Minimum
Typical
Maximum
Units
MHz
MHz
ppm
ppb
ppb
ppb
ppb
ppb
ppm
ppm
V
mA
V
V
<±13
±1
100
ppm
%
kΩ
To be with-in ±500
ppb of Fc @ 25°C
(at shipping)
Relative to carrier
Option “5”
Option “1”
Option “2”
Notes
10
40
10.00, 12.80, 16.384, 19.20, 19.44, 20.00,
24.576, 25.00, 26.00, 30.72, 40.00
±0.5
±50
±100
±280
±100
±200
±3.0
+3.3
±1.0
±4.6
+3.465
6.0
+2.5
Initial Frequency Tolerance
(@+25°C) at shipping
Frequency Stability Options (Ref. to Frequency @+25°C)
-40°C to +85°C
-40°C to +85°C
-40°C to +85°C
Frequency Stability vs. Supply Voltage
Change (Vdd±5%)
Frequency Stability vs. Load Change
(Load±5%)
Aging (first year @+25°C)
Aging (20 years @+25°C)
Supply Voltage (Vdd)
+3.135
Supply Current (Icc)
Control Port (
Applicable for VCTCXO only)
Control Voltage Range (Vc)
+0.5
Center Control Voltage (Vc)
Frequency Tuning Range
Tuning Slope
Linearity
Port Impedance
ABRACON IS
ISO9001:2008
CE RTIFIED
CE RTIFIED
No load
+1.5
+1.5
±5
±7
Positive
LLC
2 Faraday, Suite# B
|
Irvine
|
CA 92618
Revised: 04.02.15
Ph. 949.546.8000
|
Fax. 949.546.8001
Visit
www.abracon.com
for Terms and Conditions of Sale
