General Purpose, Pulse and DC Transient Suppression
PME261 Metallized Impregnated Paper,
10.2 – 25.4 mm Lead Spacing, 400 – 1,000 VDC
Overview
The PME261 is multilayer metallized paper, encapsulated
and impregnated in self-extinguishing material, meeting the
requirements of UL 94 V–0.
Applications
For general use in DC and low frequency pulse applications.
Benefits
• Voltage range: 400 – 1,000 VDC; 220 – 500 VAC
• Capacitance range: 0.001 – 1 µF
• Lead spacing: 10.2 – 25.4 mm
• Capacitance tolerance: ±10%, ±20%, ±5% on request
• Climatic category: 40/70/56, IEC 60068–1
• Tape and reel packaging in accordance with IEC 60286–2
• RoHS Compliant and lead-free terminations
• Operating temperature range of −40°C to +70°C in
AC applications
Click image above for interactive 3D content
Open PDF in Adobe Reader for full functionality
Legacy Part Number System
PME261
Series
Metallized Paper
K
Rated Voltage (VAC)
K = 220
E = 300
J = 500
A
Lead Spacing (mm)
A = 10.2
B = 15.2
C = 20.3
E = 25.4
5100
Capacitance Code (pF)
The last three digits
represent significant
figures. First digit
specifies the total
number of digits in the
capacitance value.
K
Capacitance
Tolerance
J = ±5%
K = ±10%
M = ±20%
R30
Packaging
See Ordering
Options Table
New KEMET Part Number System
P
Capacitor
Class
P = Paper
561
Series
Metallized
Paper
General
Purpose
H
Lead Spacing
(mm)
H = 10.2
Q = 15.2
C = 20.3
E = 25.4
E
Size Code
See
Dimension
Table
103
Capacitance Code (pF)
First two digits indicate the two
most significant digits of the
capacitance value in picofarads.
The third digit is the number of
following zeroes.
K
Capacitance
Tolerance
J = ±5%
K = ±10%
M = ±20%
220
Rated Voltage
(VAC)
220 = 220
300 = 300
500 = 500
A
Packaging
See Ordering
Options
Table
One world. One KEMET
© KEMET Electronics Corporation • P.O. Box 5928 • Greenville, SC 29606 • 864-963-6300 • www.kemet.com
F3070_PME261 • 7/27/2017
1
Film Capacitors – General Purpose, Pulse and DC Transient Suppression
PME261 Metallized Impregnated Paper, 10.2 – 25.4 mm Lead Spacing, 400 – 1,000 VDC
Benefits cont'd
• Operating temperature range of −40°C to +100°C in DC
• Approved according to SE–MIL–QPL
applications
• The capacitors meet the most stringent IEC humidity class,
• Excellent self-healing properties. Ensures long life even
56 days
when subjected to frequent over-voltages.
• The impregnated paper ensures excellent stability giving
• Good resistance to ionization due to impregnated dielectric outstanding reliability properties, especially in applications
• IEC Publication 166 Type 1
having continuous operation
• High dV/dt capability
Ordering Options Table
Lead
Spacing
Nominal
(mm)
Lead Length
(mm)
KEMET
Lead and
Packaging
Code
C
A
L
Type of Leads and Packaging
Standard Lead and Packaging
Options
Bulk (Bag) – Short Leads
Bulk (Bag) – Max Length Leads
Tape & Reel (Standard Reel)
Other Lead and Packaging
Options
Tape & Reel (Large Reel)
Ammo Pack
Standard Lead and Packaging
Options
Bulk (Bag) – Short Leads
Bulk (Bag) – Max Length Leads
Tape & Reel (Standard Reel)
Other Lead and Packaging
Options
Tape & Reel (Large Reel)
Standard Lead and Packaging
Options
Bulk (Tray) – Short Leads
Bulk (Bag) – Max Length Leads
Tape & Reel (Standard Reel)
Other Lead and Packaging
Options
Tape & Reel (Large Reel)
Standard Lead and Packaging
Options
Bulk (Tray) – Short Leads
Bulk (Bag) – Max Length Leads
Legacy
Lead and
Packaging
Code
R06
R17
R19T0
10.2
6 +0/−1
17 +0/−1
H
0
= 18.5 ±0.5
H
0
= 18.5 ±0.5
H
0
= 18.5 ±0.5
P
LAF3
R19T1
R30XA
Native 10.2
formed to 7.5
15.2
6 +0/−1
30 +5/−0
H
0
= 18.5 ±0.5
H
0
= 18.5 ±0.5
C
A
L
R06
R30
R19T0
P
R19T1
20.3
6 +0/−1
30 +5/−0
H
0
= 18.5 ±0.5
H
0
= 18.5 ±0.5
6 +0/−1
30 +5/−0
C
A
L
R06
R30
R19T0
P
R19T1
25.4
C
A
R06
R30
© KEMET Electronics Corporation • P.O. Box 5928 • Greenville, SC 29606 • 864-963-6300 • www.kemet.com
F3070_PME261 • 7/27/2017
2
Film Capacitors – General Purpose, Pulse and DC Transient Suppression
PME261 Metallized Impregnated Paper, 10.2 – 25.4 mm Lead Spacing, 400 – 1,000 VDC
Dimensions – Millimeters
FRONT VIEW
L
SIDE VIEW
B
H
d
p
LL
Size Code
HE
HL
QE
QM
QP
CE
CG
CJ
CP
EH
EL
p
10.2
10.2
15.2
15.2
15.2
20.3
20.3
20.3
20.3
25.4
25.4
±0.4
±0.4
±0.4
±0.4
±0.4
±0.4
±0.4
±0.4
±0.4
±0.4
±0.4
3.9
5.1
5.2
7.3
7.8
7.6
8.4
9.0
11.3
10.6
15.3
B
Maximum
Maximum
Maximum
Maximum
Maximum
Maximum
Maximum
Maximum
Maximum
Maximum
Maximum
7.5
10.5
10.5
13.0
13.5
14.0
14.0
15.0
16.5
17.3
22.0
H
Maximum
Maximum
Maximum
Maximum
Maximum
Maximum
Maximum
Maximum
Maximum
Maximum
Maximum
13.5
13.5
18.5
18.5
18.5
24.0
24.0
24.0
24.0
30.5
30.5
L
Maximum
Maximum
Maximum
Maximum
Maximum
Maximum
Maximum
Maximum
Maximum
Maximum
Maximum
0.6
0.6
0.8
0.8
0.8
0.8
0.8
0.8
0.8
1
1
d
±0.05
±0.05
±0.05
±0.05
±0.05
±0.05
±0.05
±0.05
±0.05
±0.05
±0.05
Nominal Tolerance Nominal Tolerance Nominal Tolerance Nominal Tolerance Nominal Tolerance
Note: See Ordering Options Table for lead length (LL) options.
© KEMET Electronics Corporation • P.O. Box 5928 • Greenville, SC 29606 • 864-963-6300 • www.kemet.com
F3070_PME261 • 7/27/2017
3
Film Capacitors – General Purpose, Pulse and DC Transient Suppression
PME261 Metallized Impregnated Paper, 10.2 – 25.4 mm Lead Spacing, 400 – 1,000 VDC
Performance Characteristics
Rated Voltage V
R
(VDC)
Rated Voltage V
R
(VAC)
Capacitance Range (µF)
Capacitance Tolerance
Temperature Range
Climatic Category
Dissipation Factor tanδ
400
220
0.0082 – 1.0
630
300
0.001 – 0.15
1000
500
0.001 – 0.1
±10%, ±20%, ±5% on request
−40 to +70°C
−40 to +100°C
40/070/56
Maximum Values at +23°C
1 kHz
Minimum Values Between Terminals
1.3%
Measured at +20°C, According to IEC 60384–2
Insulation Resistance
C ≤ 0.33 µF
C > 0.33 µF
≥ 12,000 MΩ
≥ 4,000 MΩ • µF
PME261 K measured at 100 VDC after 60 seconds, +23°C
PME261 E and J measured at 500 VDC after 60 seconds, +23°C
Environmental Test Data
Test
Vibration
Bump
Solderability
Passive Flammability
Damp Heat Steady State
IEC Publication
IEC 60068–2–6 Test Fc
IEC 60068–2–29 Test Eb
IEC 60068–2–20 Test Ta
IEC 60695–2–2
IEC 60068-2-3 Test Ca
4,000 bumps at 390 m/s
2
Solder globule method
Wetting time
for d ≤ 0.8 < 1 second
for d > 0.8 < 1.5 seconds
Procedure
3 directions at 2 hours each 10 – 55 Hz at 0.75 mm or 98 m/s
2
+40°C and 90 – 95% RH, 56 days
Environmental Compliance
All KEMET Metallized Impregnated Paper capacitors are RoHS Compliant.
© KEMET Electronics Corporation • P.O. Box 5928 • Greenville, SC 29606 • 864-963-6300 • www.kemet.com
F3070_PME261 • 7/27/2017
4
Film Capacitors – General Purpose, Pulse and DC Transient Suppression
PME261 Metallized Impregnated Paper, 10.2 – 25.4 mm Lead Spacing, 400 – 1,000 VDC
Table 1 – Ratings & Part Number Reference
Capacitance
Value (µF)
0.0082
0.010
0.015
0.022
0.033
0.047
0.068
0.1
0.15
0.22
0.33
0.47
0.68
1
0.001
0.0015
0.0022
0.0033
0.0047
0.0068
0.01
0.015
0.022
0.033
0.047
0.068
0.1
0.15
0.001
0.0015
0.0022
0.0033
0.0047
0.0068
0.01
0.015
0.022
0.033
0.047
0.068
0.1
Maximum
Dimensions in mm
B
H
L
3.9
3.9
5.1
5.1
5.2
5.2
7.3
7.3
7.6
8.4
11.3
10.6
15.3
15.3
3.9
3.9
3.9
3.9
3.9
3.9
5.1
5.1
5.2
5.2
7.3
7.3
7.6
9.0
3.9
3.9
3.9
3.9
5.1
5.1
5.2
5.2
7.3
7.8
7.6
9.0
11.3
7.5
7.5
10.5
10.5
10.5
10.5
13.0
13.0
14.0
14.0
16.5
17.3
22.0
22.0
7.5
7.5
7.5
7.5
7.5
7.5
10.5
10.5
10.5
10.5
13.0
13.0
14.0
15.0
7.5
7.5
7.5
7.5
10.5
10.5
10.5
10.5
13.0
13.5
14.0
15.0
16.5
13.5
13.5
13.5
13.5
18.5
18.5
18.5
18.5
24.0
24.0
24.0
30.5
30.5
30.5
13.5
13.5
13.5
13.5
13.5
13.5
13.5
13.5
18.5
18.5
18.5
18.5
24.0
24.0
13.5
13.5
13.5
13.5
13.5
13.5
18.5
18.5
18.5
18.5
24.0
24.0
24.0
Lead
Spacing (p)
10.2
10.2
10.2
10.2
15.2
15.2
15.2
15.2
20.3
20.3
20.3
25.4
25.4
25.4
10.2
10.2
10.2
10.2
10.2
10.2
10.2
10.2
15.2
15.2
15.2
15.2
20.3
20.3
10.2
10.2
10.2
10.2
10.2
10.2
15.2
15.2
15.2
15.2
20.3
20.3
20.3
dV/dt
(V/µs)
2,000
2,000
2,000
2,000
1,600
1,300
1,100
850
700
560
430
370
300
220
2,000
2,000
2,000
2,000
2,000
2,000
2,000
2,000
2,000
2,000
1,600
1,200
900
650
2,000
2,000
2,000
2,000
2,000
2,000
2,000
2,000
2,000
2,000
2,000
1,400
950
New Kemet
Part Number
P561HE822(1)220(2)
P561HE103(1)220(2)
P561HL153(1)220(2)
P561HL223(1)220(2)
P561QE333(1)220(2)
P561QE473(1)220(2)
P561QM683(1)220(2)
P561QM104(1)220(2)
P561CE154(1)220(2)
P561CG224(1)220(2)
P561CP334(1)220(2)
P561EH474(1)220(2)
P561EL684(1)220(2)
P561EL105(1)220(2)
P561HE102(1)300(2)
P561HE152(1)300(2)
P561HE222(1)300(2)
P561HE332(1)300(2)
P561HE472(1)300(2)
P561HE682(1)300(2)
P561HL103(1)300(2)
P561HL153(1)300(2)
P561QE223(1)300(2)
P561QE333(1)300(2)
P561QM473(1)300(2)
P561QM683(1)300(2)
P561CE104(1)300(2)
P561CJ154(1)300(2)
P561HE102(1)500(2)
P561HE152(1)500(2)
P561HE222(1)500(2)
P561HE332(1)500(2)
P561HL472(1)500(2)
P561HL682(1)500(2)
P561QE103(1)500(2)
P561QE153(1)500(2)
P561QM223(1)500(2)
P561QP333(1)500(2)
P561CE473(1)500(2)
P561CJ683(1)500(2)
P561CP104(1)500(2)
Legacy
Part Number
PME261KA4820(1)(2)
PME261KA5100(1)(2)
PME261KA5150(1)(2)
PME261KA5220(1)(2)
PME261KB5330(1)(2)
PME261KB5470(1)(2)
PME261KB5680(1)(2)
PME261KB6100(1)(2)
PME261KC6150(1)(2)
PME261KC6220(1)(2)
PME261KC6330(1)(2)
PME261KE6470(1)(2)
PME261KE6680(1)(2)
PME261KE7100(1)(2)
PME261EA4100(1)(2)
PME261EA4150(1)(2)
PME261EA4220(1)(2)
PME261EA4330(1)(2)
PME261EA4470(1)(2)
PME261EA4680(1)(2)
PME261EA5100(1)(2)
PME261EA5150(1)(2)
PME261EB5220(1)(2)
PME261EB5330(1)(2)
PME261EB5470(1)(2)
PME261EB5680(1)(2)
PME261EC6100(1)(2)
PME261EC6150(1)(2)
PME261JA4100(1)(2)
PME261JA4150(1)(2)
PME261JA4220(1)(2)
PME261JA4330(1)(2)
PME261JA4470(1)(2)
PME261JA4680(1)(2)
PME261JB5100(1)(2)
PME261JB5150(1)(2)
PME261JB5220(1)(2)
PME261JB5330(1)(2)
PME261JC5470(1)(2)
PME261JC5680(1)(2)
PME261JC6100(1)(2)
Capacitance
Value (µF)
B (mm)
H (mm)
L (mm)
Lead Spacing (p)
dV/dt (V/µs)
New KEMET
Part Number
Legacy
Part Number
(1) K = ±10%, M = ±20%, J = ±5% on request.
(2) Insert lead and packaging code. See Ordering Options Table for available options.
© KEMET Electronics Corporation • P.O. Box 5928 • Greenville, SC 29606 • 864-963-6300 • www.kemet.com
F3070_PME261 • 7/27/2017
5
京公网安备 11010802033920号
EEWORLD
