DATA SHEET
COMPOUND TRANSISTOR
AN1A3Q
on-chip resistor PNP silicon epitaxial transistor
For mid-speed switching
FEATURES
• On-chip bias resistor
(R
1
= 1.0 kΩ, R
2
= 10 kΩ)
• Complementary transistor with AA1A3Q
PACKAGE DRAWING (UNIT: mm)
ABSOLUTE MAXIMUM RATINGS (Ta = 25°C)
°
Parameter
Collector to base voltage
Collector to emitter voltage
Emitter to base voltage
Collector current (DC)
Collector current (Pulse)
Total power dissipation
Junction temperature
Storage temperature
Symbol
V
CBO
V
CEO
V
EBO
I
C(DC)
I
C(pulse)
*
P
T
T
j
T
stg
Ratings
−60
−50
−5
–100
–200
250
150
−55
to +150
Unit
V
V
V
mA
mA
mW
°C
°C
* PW
≤
10 ms, duty cycle
≤
50 %
ELECTRICAL CHARACTERISTICS (Ta = 25°C)
°
Parameter
Collector cutoff current
DC current gain
DC current gain
Collector saturation voltage
Low level input voltage
High level input voltage
Input resistance
E-to-B resistance
Turn-on time
Storage time
Turn-off time
Symbol
I
CBO
h
FE1
**
h
FE2
**
V
CE(sat)
**
V
IL
**
V
IH
**
R
1
R
2
t
on
t
stg
t
off
V
CC
=
−5
V, R
L
= 1 kΩ
V
I
=
−5
V, PW = 2
µ
s
duty cycle≤2 %
Conditions
V
CB
=
−50
V, I
E
= 0
V
CE
=
−5.0
V, I
C
=
−5.0
mA
V
CE
=
−5.0
V, I
C
=
−50
mA
I
C
=
−5.0
mA, I
B
=
−0.25
mA
V
CE
=
−5.0
V, I
C
=
−100
µ
A
V
CE
=
−0.2
V, I
C
=
−5.0
mA
−2.0
0.7
7
35
80
60
200
−0.04
−0.7
−1.0
1.0
10
1.3
13
0.2
5.0
6.0
−0.2
−0.5
MIN.
TYP.
MAX.
−100
100
Unit
nA
−
−
V
V
V
kΩ
kΩ
µ
s
µ
s
µ
s
** Pulse test PW
≤
350
µ
s, duty cycle
≤
2 %
