Unshielded Surface Mount Inductors
R*
-94K
-96K
-00K
-02K
-04K
-06K
-08K
-10K
-12K
-14K
-16K
-18K
-20K
M83446/31
01F
02F
03F
04F
05F
06F
07F
08F
09F
10F
11F
12F
13F
– SERIES MIL1330 PHENOLIC CORE
0.10
40
25.0
680.0
0.08
0.12
40
25.0
640.0
0.09
0.15
38
25.0
600.0
0.10
0.18
35
25.0
550.0
0.12
0.22
33
25.0
510.0
0.14
0.27
33
25.0
430.0
0.16
0.33
30
25.0
410.0
0.22
0.39
30
25.0
365.0
0.30
0.47
30
25.0
330.0
0.35
0.56
30
25.0
300.0
0.50
0.68
28
25.0
275.0
0.60
0.82
28
25.0
250.0
0.85
1.00
25
25.0
230.0
1.00
1380
1300
1230
1120
1040
975
830
710
660
550
500
420
390
Actual Size
Military QPL Approval
M83446/31 Phenolic Core
M8344632 Iron Core
M83446/33 Ferrite Core
† Ordering Note
Military parts must be ordered to the
M83446/ part number
Physical Parameters
Inches
A
0.300 to 0.325
B
0.105 to 0.125
C
0.125 to 0.145
D
0.020 Min.
E
0.040 to 0.060
F
0.190 (Ref. only)
G
0.070 (Ref. only)
Weight Max
(Grams) 0.30
Operating Temperature Range
Phenolic: –55°C to +125°C
Iron and Ferrite: –55°C to +105°C
Current Rating at 90°C Ambient
Phenolic: 35°C Rise
Iron and Ferrite: 15°C Rise
Maximum Power Dissipation at 90°C Ambient
Phenolic: 0.210 W
Iron: 0.090 W
Ferrite: 0.073 W
Marking
API/SMD; inductance with units and tolerance;
date code (YYWWL) followed by an M.
Example: 1330-42K
API/SMD
8.2uH±10%
0601A M
Packaging
Tape & reel (16mm): 7" reel, 500 pieces max.;
13" reel, 2200 pieces max.
Made In the U.S.A.
Millimeters
7.62 to 8.26
2.67 to 3.18
3.18 to 3.68
0.508 Min.
1.02 to 1.52
4.83 (Ref. only)
1.78 (Ref. only)
-22K
-24K
-26K
-28K
-30K
-32K
-34K
-36K
-38K
-40K
-42K
-44K
-46K
-48K
-50K
-52K
-54K
M83446/32 – SERIES MIL1330 IRON CORE
01F
1.20
25
7.9
150.0
0.18
02F
1.50
28
7.9
140.0
0.22
03F
1.80
30
7.9
125.0
0.30
04F
2.20
30
7.9
115.0
0.40
05F
2.70
37
7.9
100.0
0.55
06F
3.30
45
7.9
90.0
0.85
07F
3.90
45
7.9
80.0
1.00
08F
4.70
45
7.9
75.0
1.20
09F
5.60
50
7.9
65.0
1.80
10F
6.80
50
7.9
60.0
2.00
11F
8.20
55
7.9
55.0
2.70
12F
10.00
55
7.9
50.0
3.30
13F
12.0
45
2.5
40.0
2.70
14F
15.0
45
2.5
35.0
2.80
15F
18.0
45
2.5
30.0
3.10
16F
22.0
45
2.5
25.0
3.30
17F
27.0
45
2.5
20.0
3.50
M83446/33 – SERIES MIL1330 FERRITE CORE
01F
33.0
35
2.5
24.0
3.40
02F
39.0
35
2.5
22.0
3.60
03F
47.0
35
2.5
20.0
4.50
04F
56.0
35
2.5
18.0
5.70
05F
68.0
35
2.5
15.0
6.70
06F
82.0
35
2.5
14.0
7.30
07F
100.0
35
2.5
13.0
8.00
08F
120.0
30
0.79
12.0
13.00
09F
150.0
30
0.79
11.0
15.00
10F
180.0
30
0.79
10.0
17.00
11F
220.0
30
0.79
9.0
21.00
12F
270.0
30
0.79
8.0
25.00
13F
330.0
30
0.79
7.0
28.00
14F
390.0
30
0.79
6.5
35.00
15F
470.0
30
0.79
6.0
42.00
16F
560.0
30
0.79
5.0
46.00
17F
680.0
30
0.79
4.2
60.00
18F
820.0
30
0.79
3.8
65.00
19F
1000.0
30
0.79
3.4
72.00
620
560
480
415
355
285
263
239
195
185
160
144
160
157
149
144
140
-56K
-58K
-60K
-62K
-64K
-66K
-68K
-70K
-72K
-74K
-76K
-78K
-80K
-82K
-84K
-86K
-88K
-90K
-92K
130
125
110
100
92
88
84
66
61
57
52
47
45
40
36
35
30
29
28
Parts listed above are QPL/MIL qualified
*Complete part # must include series # PLUS the dash #
For surface finish information, refer to www.delevanfinishes.com
270 Quaker Rd., East Aurora NY 14052 • Phone 716-652-3600 • Fax 716-652-4814 • E-mail: apisales@delevan.com • www.delevan.com
1/2009
