GaAs IC SPDT Reflective Switch
Positive Control DC - 2.5 GHz
FEATURES
AWS5502
PRELIMINARY DATA SHEET - Rev 1.0
Low Insertion Loss (0.4 dB @ 0.9 GHz)
Complementary Positive Control Voltages (0/
+3V to 0/+5V)
Positive Voltage Supply (+3 to +5 V)
Low DC Power Consumption
Ultra Miniature 6 Lead SOT-6 Package
APPLICATIONS
Selection of Synthesizers
Filters
Amplifiers in Dual Mode & Dual Band Hand-
sets
PRODUCT DESCRIPTION
The AWS5502 is a Single Pole Double Throw GaAs
MMIC Switch assembled in a SOT-6 plastic package.
The AWS5502 is designed for analog and digital
application that require low insertion loss,
small size,
and low cost. State selection is achieved with
a complimentary positive voltage (requires positive
bias Vs, and blocking caps) or negative voltage
(no Vs or blocking caps required).
S14
SOT-6
6 Pin Plastic Package
Table 1: Pin Description
PIN
RF
OUT 2
(J3)
FU N C TION
RFOUT (J2)
GND
RFIN (J1)/Vs
RFOUT 1 (J2)
V2
V1
D ESC R IPTION
RF port (can be used as an i nput or as an
output)
Ground connecti on (keep as short as
possi ble)
RF common port and bi as voltage for posi ti ve
control (3V to 5V)
RF port (can be used as an i nput or as an
output)
C ontrol voltage 2 (low 0V , hi gh 3V to 5V )
C ontrol voltage 1 (low 0V , hi gh 3V to 5V)
1
C
1
GND
2
5
V
1
V
2
C
4
RF
OUT 1
(J2)
1
6
2
3
4
5
6
RF
IN
(J1)
3
4
C
2
R1
V
s
10KΩ
DC blocking capacitors (C
1, 2, 4
) & biasing resistor must
be supplied externally for positive voltage operation.
C
1, 2, 4
= 100 pF for operation >500 MHz.
Figure 1: Pin Layout
08/2001
AWS5502
ELECTRICAL CHARACTERISTICS
Table 2: Absolute Minimum and Maximum Ratings
PAR AMETER
RF Input Power
> 500 MHz, 0/+7 V C ontrol
C ontrol Voltage
Operati ng Temperature
Storage Temperature
Q
JC
MIN
-
-0.2
-40
-50
-
MAX
2
+8
+125
+150
25
U N IT
W
V
o
C
°C
o
C /W
Stresses in excess of the absolute ratings may cause permanent
damage. Functional operation is not implied under these conditions.
Exposure to absolute ratings for extended periods of time may
adversely affect reliability.
Table 3: Operating Ranges at 25° C (0, +3V)
PAR AMETER
Swi tchi ng C haracteri ti cs
5
C ON D ITION
Ri se, Fall (10/90% or 90/10% RF)
On, Off (50% C TL to 90%/10% RF)
Vi deo Feedthru
For Two-tone Input Power +10 dBm
@ +3V
@ +5V
FR EQU EN C Y
-
0.5 - 2.0 GHz
0.5 - 2.0 GHz
0.5 - 2.0 GHz
MIN
-
-
-
TYP
10
20
25
+45
+21
+28
MAX
-
-
-
U N IT
ns
ns
mV
dB m
dB m
Intermodulati on Intercept Poi nt (IP3)
Input Power for 1dB C ompressi on
C ontrol Voltage
V
LOW
= 0 to 0.2 V @ 20 uA Max
V
HIGH
= +3 V @ 100 uA Max to +5 V @ 200 uA Max
V
S
= V
HIGH
+ 0.2V
The device may be operated safely over these conditions; however, parametric performance is guaranteed
only over the conditions defined in the electrical specifications.
Notes:
1. All measurements made in a 50 ohm system, unless otherwise specified.
2. DC = 300 kHz.
3. Insertion loss changes by 0.003 dB/°C.
4. Insertion loss state.
5. Video feedthru measured wirh 1 ns rise time pulse and 500 MHz bandwidth.
2
PRELIMINARY DATA SHEET - Rev 1.0
08/2001
AWS5502
Table 4: Electrical Specifications at 25 °C (0, +3V)
PAR AMETER
Inserti on Loss
1
FR EQU EN C Y
2
DC
DC
DC
DC
DC
DC
DC
DC
- 0.5
- 1.0
- 2.0
- 2.5
- 0.5
- 1.0
- 2.0
- 2.5
GHz
GHz
GHz
GHz
GHz
GHz
GHz
GHz
MIN
-
-
-
-
22
17
11
10
-
-
TYP
0.4
0.45
0.6
0.9
25
20
14
13
1.2:1
1.5:1
MAX
0.5
0.6
0.8
1.1
-
-
-
-
1.3:1
1.7:1
U N IT
dB
dB
dB
dB
dB
dB
dB
dB
-
-
3
Isolati on
VSWR
4
D C - 1.0 GHz
D C - 2.5 GHz
Table 5: Truth Table: Positive Operation
V
1
V
High
0
V
2
0
V
High
J
1
- J
2
Insertion
Isolation
J
1
- J
3
Isolation
Insertion
V
High
= +3 to +5 V (V
S
= V
High
+ 0.2 V)
Figure 2: Text Circuit Schematic
PRELIMINARY DATA SHEET - Rev 1.0
08/2001
3
AWS5502
PACKAGE OUTLINE
θ
SYMBOLS
DIMENSIONS IN MILLIMETERS
DIMENSIONS IN INCHES
A
A1
A2
b
C
D
E
e
H
L
θ1
MIN
1.00
0.00
0.70
0.35
0.10
2.70
1.40
2.60
0.37
1°
NOM
1.10
−−−
0.80
0.40
0.15
2.90
1.60
1.90(TYP)
2.80
−−−
5°
MAX
1.30
0.10
0.90
0.50
0.25
3.10
1.80
3.00
−−−
9°
NOM
0.043
−−−
0.031
0.016
0.006
0.114
0.063
0.075(TYP)
0.102
0.110
0.015
−−−
1°
5°
MIN
0.039
0.00
0.027
0.014
0.004
0.106
0.055
MAX
0.051
0.004
0.035
0.020
0.010
0.122
0.071
0.118
−−−
9°
NOTES:
1. Package body sizes exclude mold flash and gate burrs.
2. Dimension L is measured in gage plane
3. Coplanarity: 0.1000 mm
4. Tolerance + 0.1000 mm (4 mil) unless otherwise specified.
Figure 3: S14 Package Outline
4
PRELIMINARY DATA SHEET - Rev 1.0
08/2001
AWS5502
