06031A220J4T4A datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> capacitor> 06031A220J4T4A

06031A220J4T4A: DescriptionCeramic Capacitor, Multilayer, Ceramic, 100V, 5% +Tol, 5% -Tol, C0G, 30ppm/Cel TC, 0.000022uF, Surface Mount, 0603, CHIP; CategoryPassive components capacitor; File Size90KB，5 Pages; ManufacturerAVX; Environmental Compliance

Download Datasheet Parametric View All

06031A220J4T4A Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	06031A220J4T4A	-	-	View	Buy Now

06031A220J4T4A Overview

Ceramic Capacitor, Multilayer, Ceramic, 100V, 5% +Tol, 5% -Tol, C0G, 30ppm/Cel TC, 0.000022uF, Surface Mount, 0603, CHIP

06031A220J4T4A Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Objectid	1695246565
package instruction	, 0603
Reach Compliance Code	compliant
ECCN code	EAR99
Factory Lead Time	32 weeks
YTEOL	7
capacitance	0.000022 µF
Capacitor type	CERAMIC CAPACITOR
dielectric materials	CERAMIC
high	0.9 mm
JESD-609 code	e3
length	1.6 mm
Installation features	SURFACE MOUNT
multi-layer	Yes
negative tolerance	5%
Number of terminals	2
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Package shape	RECTANGULAR PACKAGE
Package form	SMT
method of packing	TR, PAPER, 13 INCH
positive tolerance	5%
Rated (DC) voltage (URdc)	100 V
Guideline	AEC-Q200
size code	0603
surface mount	YES
Temperature characteristic code	C0G
Temperature Coefficient	30ppm/Cel ppm/°C
Terminal surface	Matte Tin (Sn) - with Nickel (Ni) barrier
Terminal shape	WRAPAROUND
width	0.81 mm

Preview

Download Datasheet

View All

Automotive MLCC

Automotive

GENERAL DESCRIPTION

AVX Corporation has supported the Automotive Industry requirements for Multilayer

Ceramic Capacitors consistently for more than 10 years. Products have been de- veloped

and tested specifically for automotive applications and all manufacturing facilities are

QS9000 and VDA 6.4approved.

As part of our sustained investment in capacity and state of the art technology, we are now

transitioning from the established Pd/Ag electrode system to a Base Metal Electrode

system (BME).

AVX is using AECQ200 as the qualification vehicle for this transition. A detailed qualification

package is available on request and contains results on a range of part numbers including:

•

X7R dielectric components containing BME electrode and copper

terminations with a Ni/Sn plated overcoat.

•

X7R dielectric components, BME electrode with epoxy finish for conductive glue mounting.

•

X7R dielectric components BME electrode and soft terminations with a Ni/Sn plated over-

coat.

•

NP0 dielectric components containing Pd/Ag electrode and silver termination with a Ni/Sn

plated overcoat.

HOW TO ORDER

0805

Size

0402

0603

0805

1206

1210

1812

Voltage

10V =Z

16V =Y

25V =3

50V =5

100V =1

200V =2

250V = V

500V =7

Dielectric

NP0 = A

X7R = C

X8R =F

104

Capacitance

Code (In pF)

2Significant

Digits + Numberof

Zeros

e.g. 10µF =106

Capacitance

Tolerance

F =±1%

(≥10pF)*

G =±2%

(≥10pF)*

J =±5%

(≤1µF)

K =±10%

M =±20%

*NPOonly

Failure Rate

4 = Automotive

Terminations

T = Plated Ni and Sn

Z =FLEXITERM

U =Conductive Epoxy**

**X7R & X8Ronly

Packaging

2 = 7" Reel

4 =13" Reel

Special Code

A = Std. Product

Contact factory for availability of Tolerance Options for Specific PartNumbers.

NOTE: Contact factory for non-specified capacitancevalues.

0402 case size available in T termination only.

COMMERCIAL VS AUTOMOTIVE MLCC PROCESS COMPARISON

Administrative

Design

Dicing

Lot Qualification

(Destructive Physical

Analysis - DPA)

Visual/Cosmetic Quality

Application Robustness

Commercial

Standard Part Numbers.

No restriction on who purchases these parts.

Minimum ceramic thickness of 0.020"

Side & End Margins = 0.003" min

As per EIA RS469

Automotive

Specific Automotive Part Number. Used to control

supply of product to Automotive customers.

Minimum Ceramic thickness of 0.029" (0.74mm)

on all X7R product.

Side & End Margins = 0.004" min

Cover Layers = 0.003" min

Increased sample plan –

stricter criteria.

100% inspection

Increased sampling for accelerated wave solder on

X7R and NP0 followed by lot by lot reliability testing.

Standard process and inspection

Standard sampling for accelerated

wave solder on X7R dielectrics

All Tests have Accept/Reject Criteria 0/1
