Chip NTC Thermistor

ABNTC-0805

FEATURES:

• Large B constant for high temperature sensing capability

• Designed for high density

• Available in standard EIA compatible case size

• Internal electrode designed for enhanced reliability

• Excellent aging stability

RoHS/RoHS II Compliant

2.0 x 1.25 x 0.85 mm

.

APPLICATIONS:

• For temperature measurement or sensor: Digital thermometer,

measuring instruments, temperature controller

• For temperature compensation: transistor circuit, TCXO, Crystal

Oscillator

• LED lighting driver, Notebook, Cell Phone, Power Supplies, Disk Drive

STANDARD SPECIFICATIONS:

Operating Temperature:

-55˚C ~+125˚C

Storage Temperature:

-10˚C ~ +40˚C and RH 75% (Max.)

Part

Number

Resistance at 25 C

R25

(kΩ)

2.0

5.0

6.8

10

15

22

47

50

68

100

150

220

330

470

680

1300

o

B constant

(25-50

o

C)

(K)

3950

3450

3950

3500

4050

4150

4250

4300

4350

4400

4500

4700

Max.

Permissive

Operating

Current

(25

o

C)

(mA)

1.0

0.60

0.50

0.40

0.44

0.32

0.31

0.20

0.18

0.16

0.14

0.11

0.08

0.06

0.05

0.04

0.03

Thermal Time

Dissipation

Rated Electric

Constant

Factor

(mW/

o

C)

Power (mW)

ABNTC-0805-202Δ-3950□

ABNTC-0805-502Δ-3950□

ABNTC-0805-682Δ-3950□

ABNTC-0805-103Δ-3450□

ABNTC-0805-103Δ-3950□

ABNTC-0805-153Δ-3500□

ABNTC-0805-223Δ-4050□

ABNTC-0805-473Δ-4150□

ABNTC-0805-503Δ-4150□

ABNTC-0805-683Δ-4150□

ABNTC-0805-104Δ-4250□

ABNTC-0805-154Δ-4300□

ABNTC-0805-224Δ-4350□

ABNTC-0805-334Δ-4400□

ABNTC-0805-474Δ-4500□

ABNTC-0805-684Δ-4500□

ABNTC-0805-135Δ-4700□

<5sec

2.0

200

Δ Please specify the tolerance code of R25 (F=±1%, H=±3%, J=±5%, K=±10%).

:

□: Please specify the tolerance code of B value (F=±1%, H=±3%).

Test Conditions

Unless otherwise specified, the standard atmospheric conditions for measurement/test as:

a. Ambient Temperature: 20±15

o

C

o

C

b. Relative

Humidity:

65±20%

c. Air

Pressure: 86 kPa to 106 kPa

ABRACON IS

ISO 9001 / QS 9000

ISO 9001:2008

CERTIFIED

30332 Esperanza, Rancho Santa Margarita, California 92688

Visit

www.abracon.com

for Terms & Conditions of Sale

Revised: 05.05.14

tel 949-546-8000

|

fax 949-546-8001

| www.abracon.com
