NTHS Series
www.vishay.com
Vishay Dale
NTC Thermistors, SMD 0402, 0603, 0805, 1206 Chip
FEATURES
• Extended resistance values available in
standard sizes
• Wraparound Ni barrier terminations with
100 % Sn
• Allows design flexibility for use with hybrid
circuitry
• High-density monolithic construction with glass overcoat
• Material categorization: for definitions of compliance
please see
www.vishay.com/doc?99912
APPLICATIONS
QUICK REFERENCE DATA
PARAMETER
Resistance value at 25 °C
Tolerance on
R
25
-value
B
25/75
-value
B
25/85
-value
Tolerance on B
25/85
- value,
B
25/75
-value
Operating temperature range
at zero power (intermittent)
VALUE
4.7K to 350K
± 1, ± 2, ± 3, ± 5, ± 10
3477 to 4247
3486 to 4261
±3
-40 to +125 (150)
UNIT
Ω
%
K
K
%
°C
Temperature sensing, protection and compensation in
industrial, telecom and consumer applications.
Examples are:
• Battery chargers
• Power suppliers
• Office equipment
• LCD compensation
• In-car entertainment
DESIGN-IN SUPPORT
For complete curve computation please visit the “My Vishay NTC
curve” at:
www.vishay.com/thermistors/curve-computation-list/
or sent your part number to
thermistor1@vishay.com
to
obtain a calculation spreadsheet.
NTHS PRODUCT DATA AND
R
25
RESISTANCE RANGE AVAILABILITY
CURVE
2
11
1
5
17
4
B
25/75
(K)
3477
3691
3964
3964
4064
4247
B
25/85
(K)
3486
3715
3974
3974
4073
4262
TCR
(%/K)
-3.84
-4.13
-4.39
-4.39
-4.50
-4.67
NTHS0402
(kΩ)
10 to 12
30 to 34
68 to
100
(1)
47 to 50
250
350
80
2.0
5
NTHS0603
(kΩ)
6.8 to 12
22 to 32
50 to 100
40 to 50
150 to 220
250 to 350
125
3.0
8
NTHS0805
(kΩ)
4.7 to 10
15 to 30
33 to 78
25 to 47
100 to 200
200 to 300
210
3.5
10
NTHS1206
(kΩ)
6 to 10
20 to 33
38 to 100
30 to 44
100 to 220
200 to 330
280
4.0
13
R
25
± TOL.
AVAILABILITY
3, 5, 10
3, 5, 10
1, 2, 3, 5, 10
3, 5, 10
3, 5, 10
3, 5, 10
Maximum dissipation at 25 °C in mW
Dissipation factor in mW/K
Thermal time constant in s
Note
(1)
Only
R
tolerance values ± 3 %, ± 5 %, and ± 10 % are available for NTHS0402N01N types.
25
STANDARD RESISTANCE VALUES
at 25 °C in
Ω
4.7K
5.0K
6.8K
10K
12K
15K
20K
22K
30K
33K
47K
50K
68K
100K
150K
200K
220K
250K
330K
Note
• Most popular and available values.
Revision: 24-Nov-15
Document Number: 33008
1
For technical questions, contact:
thermistor1@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
NTHS Series
www.vishay.com
Vishay Dale
GLOBAL PART NUMBER INFORMATION
Global Part Numbering: NTHS1206N02N1002JE (preferred part number format)
N
T
H
S
1
2
0
6
N
0
2
N
1
0
0
2
J
E
GLOBAL
MODEL
NTHS0402
NTHS0603
NTHS0805
NTHS1206
CONDUCTOR
TYPE
Nickel barrier
CURVE
01
02
04
05
11
17
CHARACTERISTIC
N
RESISTANCE
VALUE
1002
= 10K
TOLERANCE
CODE
F
=±1%
G
=±2%
H
=±3%
J
=±5%
K
= ± 10 %
PACKAGING
F
= Lead (Pb)-free,
bulk
E
= Lead (Pb)-free,
T/R (2K pcs, full)
U
= Lead (Pb)-free,
T/R (5K pcs, full)
DIMENSIONS
in inches (millimeters)
BW
L
W
t
PART NUMBER
NTHS0402
NTHS0603
NTHS0805
NTHS1206
L
0.040 ± 0.004
(1.02 ± 0.10)
0.063 ± 0.008
(1.60 ± 0.20)
0.079 ± 0.008
(2.01 ± 0.20)
0.126 ± 0.008
(3.20 ± 0.20)
W
0.022 ± 0.006
(0.56 ± 0.15)
0.031 ± 0.008
(0.80 ± 0.20)
0.049 ± 0.008
(1.25 ± 0.20)
0.063 ± 0.008
(1.60 ± 0.20)
BW
0.010 ± 0.004
(0.25 ± 0.10)
0.010 ± 0.006
(0.25 ± 0.15)
0.012 ± 0.006
(0.30 ± 0.15)
0.018 ± 0.008
(0.46 ± 0.20)
t
max.
0.028
(0.71)
0.039
(1.00)
0.057
(1.45)
0.071
(1.80)
Note
• Thickness of the part is depending on the resistance value and curve
Revision: 24-Nov-15
Document Number: 33008
2
For technical questions, contact:
thermistor1@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
