L-Series - UL489 Miniature Molded Case Circuit Breaker -
2 pole D-Trip /
DC
Rated
Current
0.2A
0.5A
1.0A
1.6A
2.0A
3.0A
4.0A
5.0A
6.0A
8.0A
10A
12A
13A
15A
16A
20A
25A
30A
32A
40A
50A
60A
63A
Type/
Cat. No.
DC2DU02L
DC2DU05L
DC2DU1L
DC2DU1.6L
DC2DU2L
DC2DU3L
DC2DU4L
DC2DU5L
DC2DU6L
DC2DU8L
DC2DU10L
DC2DU12L
DC2DU13L
DC2DU15L
DC2DU16L
DC2DU20L
DC2DU25L
DC2DU30L
DC2DU32L
DC2DU40L
DC2DU50L
DC2DU60L
DC2DU63L
C and D Trip, Less than 10A
120
60
40
20
Minutes
LISTED
E305318
10
8
6
4
2
1
40
20
10
5
Tripping time t
1
0.5
Seconds
0.05
0.1
Two Pole
Standard Pack:
4
Weight:
1.7kg (3.74 lb.)
0.01
C
1
2
3
4
Multiple of Rated Current
D
5 6 7 8 9 10 12 14 16 20
1.05 1.3
C and D Trip, 10A and higher
7200
3600
2400
1200
Minutes
Tripping time t
DC Version Current/ Voltage Rating
0.2-63A/125/250VDC
Calibration Temperature
Operating Temperature
Storage Temperature
Terminal Size Acceptability:
Solid Wire
Stranded Wire
Terminal Torque
Terminal Protection Degree
Electrical Life
Mechanical Life
Wire Connection
18 AWG -10 AWG
18 AWG -6 AWG
2.8 Nm (25 lb-in.)
IP20
6000 cycles on/off
100000 cycles on/off
copper wire only 60/75°C
Seconds
40°C (104°F)
-25° to 60°C (-13° to 140°F)
-25° to 75°C (-13° to 167°F)
600
480
360
240
120
60
40
20
10
5
1
0.5
0.05
0.1
0.01
C
1
2
3
4
Multiple of Rated Current
D
14.5mm (0.57 in.)
5 6 7 8 9 10 12 14 16 20
1.05 1.3
109mm (4.29 in.)
45mm (1.77 in.)
69mm (2.72 in.)
DC
- short CirCuit interruptinG ratinG
No.
Poles
1
2
Type
DC
DC
0.2-32A
10kA@125V
10kA@250V
33-63A
10kA@125V
10kA@250V
6.5mm
(0.26 in.)
17.5mm (0.69 in.)
44mm (1.73 in.)
60mm (2.36 in.)
35mm (1.38 in.)
For ring tongue terminal version, replace “U” with “R” in part number. For example
1CR20L
instead of
1CU20L.
