REVISION(S)
LTR
DESCRIPTION
ECN: 0S60-0009-04
ECN: 0S60-0126-04
ECN: 0S60-0181-04
ECR-06-007721
INIT
APP'D
2
D
3-FINS HEAT SINK: 1.375 DIA.
0.479 HT.
A
B
C
D
E.T 1/13/04 S.D 1/13/04
E.T 5/14/04 B.P 5/14/04
E.T 7/19/04 B.P 7/19/04
D
E.T 3/29/06 C.W 3/29/06
NOTE:
3
1
4-LEGS LOW PROFILE
CLIP SIZE: 35mm
1. MATERIAL:
HEAT SINK: ALUM. (BLACK ANODIZE)
CLIP:
BLACK PEI (UL94-VO)
2. SPECIFICATION OF MAXIMUM LOAD ON THE BGA PACKAGE SHOULD
BE IDENIFIED BY THE USER BEFORE THE HEATSINK APPLICATION.
HEATSINK TORQUE SPECIFICATIONS CONVERTED TO FORCE.
C
BARE DIE PACKAGE:
2.0 INCH - LB TORQUE = 8.1 LBS FORCE
2.5 INCH - LB TORQUE =10.1 LBS FORCE
C
.012±.001
FULL SIZE LID PACKAGE:
2.0 INCH - LB TORQUE = 6.9 LBS FORCE
2.5 INCH - LB TORQUE = 8.7 LBS FORCE
3. REMOVE CLIP WITH REMOVAL TOOL P/N: 1542616-1.
.031 3X
.080 2X
1.375±.010
B
.349 MAX
DETAIL A
SCALE= 6X
4. RoHS COMPLIANT AND CERTIFIED.
B
.135
A
.108±.005
B
1.384 LIP LEG
1.474
.238±.005
1" - 27 UNS - 2A
THREAD
.479
B
1.390
SECTION B-B
Power
5 Watts
10 Watts
° C/W @ ° C/W @ ° C/W @ ° C/W @
Ambient 200 LFM 400 LFM 600 LFM
10.98
10.39
9.50
DO NOT SCALE
UNLESS OTHERWISE
SPECIFIED
TOLERANCES ARE:
.XX
.XXX
.XXXX
ANGLES
.
.
.
5.74
5.60
5.59
DRAWN BY:
3.72
3.61
3.59
DATE
3.00
2.93
2.90
MATERIAL:
CUSTOMER DRAWING
SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE
CONFIDENTIAL PROPERTY OF TYCO
ELECTRONICS. NOT TO BE DISCLOSED
TO OTHERS. REPRODUCED OR USED FOR
ANY PURPOSES EXCEPT AS AUTHORIZED
IN WRITING BY AN AUTHORIZED OFFICIAL
OF TYCO. MUST BE RETURNED TO TYCO
ON DEMAND, ON COMPLETION OF ORDERS
OR OTHER PURPOSES FOR WHICH LENT.
DIMENSONS ARE IN:
A
15 Watts
ITEM
1
2
3
8
7
DESCRIPTION
MOUNTING CLIP
HEAT SINK
INTERFACE
QTY
1
1
1
TITLE:
A
E.TAO
ENGINEER:
DATE
01/13/04
01/13/04
PROJECT
SYSTEM
SEE NOTE
FINISH:
35mm LOW PROFILE
HEATSINK ASS'Y
(HTS676-U)
8-1542003-6
SHEET:
S.DELPRETE
FILENAME
INCHES
SEE NOTE
TNIRD ANGLE
PROJECTION
SCALE:
1.5:1
SIZE:
PART NO:
1 OF 1
REV:
A
DWG. NO.
C-8-1542003-6
