SERIES
CM6460R
CM6460
CE
AN )
CT (µH
DU L
IN A
E PIC
AG TY
AK
LE
T
EN
RR UM
CU M
S AXI
RM M
D S)
TE MP
RA (A
CE
AN )
ST S
SI HM
RE M (O
DC MU
XI
MA
CE
AN )
CT (µH
DU %
IN -25
L2 /
or 5%
L1 +3
SH
DA
E
MB
NU
s
er
Surface Mount
Common Mode Choke
R*
-104
-154
-224
-334
-504
-754
-105
-125
-185
-225
-335
-505
-755
-106
SERIES CM6460 FERRITE CORE
100
0.006
7.00
150
0.010
5.50
220
0.012
5.00
330
0.017
4.00
500
0.024
3.30
750
0.035
2.70
1000
0.049
2.20
1200
0.068
1.70
1800
0.106
1.40
2200
0.150
1.10
3300
0.210
0.85
5000
0.320
0.70
7500
0.640
0.44
10000
0.900
0.33
0.7
1.0
1.4
1.8
2.2
3.0
4.0
5.0
5.5
7.0
9.5
14.0
22.0
29.0
*Complete part # must include series # PLUS the dash #
For surface finish information, refer to www.delevanfinishes.com
Actual Size
Mechanical Configuration
A flat top surface mount case
with excellent coplanarity of terminals.
Physical Parameters
Inches
A
0.400 ± 0.010
B
0.530 ± 0.010
C
0.125 ± 0.010
D
0.490 ± 0.010
E
0.290 ± 0.010
F
0.030 ± 0.010
G
0.060 (Ref. only)
Millimeters
10.16 ± 0.25
13.46 ± 0.25
3.17 ± 0.25
12.44 ± 0.25
7.37 ± 0.25
0.76 ± 0.25
1.52 (Ref. only)
Electrical Configuration
1) Inductance and DCR in table is for either L1 or L2.
2) Leakage Inductance tested at L1 with L2 shorted or at
L2 with L1 shorted.
3) Windings balanced within 2%
4) Inductance tested @ 10 kHz
Operating Temperature Range
–55°C to +105°C
Electrical Characteristics
Measured at +25°C
Rated RMS Current
Based upon 40°C temperature rise
from 25°C ambient
Maximum Power Dissipation at 25°C
0.605 Watts
Inductance Tolerance
Units are supplied to the tolerance indicated in
the tables @ 10KHz
Dielectric Withstanding Voltage
500 V RMS, 60Hz
Marking
Parts are printed with Delevan, Inductance Value, and dot at
terminal #1.
Packaging
Tape & reel (24mm):
13" reel, 350 pieces max.; 7" reel not available
Bulk option available
Weight (Grams)
2.5 (Ref.)
