Stress in excess of any of the individual Absolute Maximum Ratings can cause immediate catastrophic damage to the
Active Cable even if all other parameters are within Recommended Operation Conditions. It should not be assumed
that limiting values of more than one parameter can be applied to the Active Cable concurrently. Exposure to any of the
Absolute Maximum Ratings for extended periods can adversely affect reliability.
Parameter
Storage Temperature
Case Temperature – Operating
3.3 V Power Supply Voltage
Data Input Voltage – Single Ended
Data Input Voltage – Differential
Control Input Voltage
Control Output Current
Relative Humidity
|V
DIP
- V
DIN
|
Vi
Io
RH
-0.5
-20
5
Symbol
T
S
T
C
V
CC
Min
-40
0
-0.5
-0.5
Max
85
70
3.6
V
CC
+0.5
1.0
V
CC
+0.5, 3.6
20
85
Units
°C
°C
V
V
V
V
mA
%
Reference
1
2
1. The position for case temperature measurement is shown in Figure 4.
2. This is the maximum voltage that can be applied across the differential inputs without damaging the input circuitry. The equivalent input
differential peak-to-peak voltage is twice this number.
Recommended Operating Conditions
Recommended Operating Conditions specify parameters for which the electrical characteristics hold unless otherwise
noted. Electrical characteristics are not defined for operation outside the Recommended Operating Conditions, reliability
is not implied and damage to the Active Cable may occur for such operation over an extended period of time.
Parameter
Case Temperature
3.3 V Power Supply Voltage
Signal Rate per Channel
Control* Input Voltage High
Control* Input Voltage Low
Two Wire Serial (TWS) Interface Clock Rate
TWS Write Cycle Time
Power Supply Noise
Receiver Differential Data Output Load
100
Vih
Vil
Symbol
Tc
Vcc
Min
0
3.135
2.5
2
-0.3
Typ
40
3.3
Max
70
3.465
10.0
Vcc+.3
0.8
400
40
50
Units
°C
V
GBd
V
V
kHz
ms
mVpp
Ω
Reference
1
2
3
* Control signals, LVTTL (3.3 V) compatible
1. The position of case temperature measurement is shown in Figure 4.
2. 8b10b coding is assumed
3. Power Supply Noise is defined as the peak-to-peak noise amplitude over the frequency range at the host supply side of the recommended
power supply filter with the Active Cable-end and recommended filter in place. Voltage levels including peak-to-peak noise are limited to the
recommended operating range of the associated power supply. See Figure 5 for a recommended power supply filter.
4
Active Cable-End Electrical Characteristics*
The following characteristics are defined over the Recommended Operating Conditions unless otherwise noted. Typical
values are for Tc = 40˚C, Vcc = 3.3 V
Parameter
10G Power Consumption (Per end)
10G Power Supply Current (Per end)
Power On Initialization Time
t
PWR INIT
Symbols
Min
Typ
Max
2.0
600
2000
Units
W
mA
ms
Reference
1
1. Power-on Initialization Time is the time from when the supply voltages reach and remain above the minimum Recommended Operating Conditions
to the time when the cable enables TWS access. The cable at that point is fully functional.
Transmitter Section Electrical Characteristics*
The following characteristics are defined over the Recommended Operating Conditions unless otherwise noted. Typical
values are for Tc = 40˚C, Vcc = 3.3 V
Parameter
Test conditions for Tx Characteristics:
Data Input Differential Peak-to-Peak
Voltage Swing
Data Input Rise & Fall Times (20% – 80%)
Data Input Deterministic Jitter
Data Input Total Jitter
ΔV
DI PP
175
30
1600
48
15
30
mVpp
ps
ps
ps
1
2
3
4
Symbol
Min
Typ
Max
Units
Reference
* For control signal timing including MODSelL, LPMode, ResetL, ModPrsL, IntL, SCL and SDA see Control Interface
1. This is a test condition and is not a required characteristic of the active cable. It is a Tx Recommended Operating condition. Data inputs are CML
compatible. Data Input Differential Peak-to-Peak Voltage Swing is defined as follows:
ΔV
DI pp
=
ΔV
DIH
–
ΔV
DIL
where
ΔV
DIH
= High State Differential
Data Input Voltage and
ΔV
DIL
= Low State Differential Data Input Voltage.
2. This is a test condition and is not a required characteristic of the transceiver. It is a Tx Recommended Operating condition.
3. This is a test condition and is not a required characteristic of the transceiver. It is a Tx Recommended Operating condition. Deterministic Jitter, DJ,
conforms to the dual-Dirac model where TJ(BER) = DJ + 2Q(BER)RJrms and RJrms is the width of the Gaussian component. Here BER = 10
-12
. DJ is
measured with the same conditions as TJ. Effects of impairments in the test signal due to the test system are removed from the measurement. All
channels not under test are operating with similar test patterns.
4. This is a test condition and is not a required characteristic of the active cable. It is a Tx Recommended Operating condition. Total Jitter, TJ, defined
for a BER of 10
-12
, is measured at the 50% signal level using using a 10.0 GBd Pseudo Random Bit Sequence of length 2
7
-1 (PRBS7), or equivalent,
test pattern .Effects of impairments in the test signals due to the test system are removed from the measurement. All channels not under test are
