SCNR6045
SMD POWER INDUCTORS
●
Features
1. Open frame construction.
ELECTRICAL CHARACTERISTICS
Part Number
Inductance
Test
(uH)
Frequency
(1)
DC Resistance
(Ω
MAX)
(2)
Saturation Temperature
(3)
(4)
Current
Current
(A)
(A)
SCNR6045 Inductance decrease by current
1000
BC6045 Inductance decrease by current
SCNR6045-1R0
SCNR6045-1R3
SCNR6045-1R8
SCNR6045-2R3
SCNR6045-3R0
SCNR6045-4R5
SCNR6045-6R3
SCNR6045-100
SCNR6045-150
SCNR6045-220
SCNR6045-330
SCNR6045-470
SCNR6045-680
SCNR6045-101
1.0
1.3
1.8
2.3
3.0
4.5
6.3
10
15
22
33
47
68
100
100KHZ
100KHZ
100KHZ
100KHZ
100KHZ
100KHZ
100KHZ
100KHZ
100KHZ
100KHZ
100KHZ
100KHZ
100KHZ
100KHZ
18.2
20.8
23.4
30.0
35.0
43.0
54.0
83.0
114
175
240
330
470
720
8.5
8.0
7.0
6.0
5.0
4.0
3.8
3.0
2.3
1.9
1.5
1.3
1.0
0.8
4.30
Inductance(uH)
4.00
3.70
3.40
3.30
3.00
2.80
2.15
1.90
1.60
100
470
10
100
1
1R0
0.1
10
100
1000
10000
100000
DC cruuent(mA)
DC current (mA)
BC6045 Temperature rise
rise
current
SCNR6045 Temperature
by
by current
80
Temperature rise ℃
1.30
1.00
0.80
0.70
70
60
50
40
30
20
10
0
101
100
1R0
1000
2000
3000
4000
5000
6000
7000
8000
DC current(mA)
(1). Inductance tested at 0.25V, 0ADC and 25℃.
Tolerance of inductance: 1.0uH-6.3uH:±30% (N).
10uH-100uH:±20% (M).
(2).DCR measured at 25℃.
(3).The DC current at which the inductance decreases by 10% from its initial value.
(4).The DC current that results in a 40℃ temperature rise from 25℃ ambient.
Click here for
QUANTITY PER REEL & PACKING INFORMATION
Custom versions available upon request.
www.signaltransformer.com
©
2011 Signal Transformer –Specification subject to change without notice. 07.11
500 Bayview Avenue, Inwood, NY 11096
Toll Free 866-239-5777 • Tel 516-239-5777 • Fax 516-239-7208
