Part Number:
Status:
Overview:
Description:
87607-1001
Active
EXTreme PowerPlus™ (SSI)
6.35mm Pitch, Power, 2.54mm Pitch, Signal, EXTreme PowerPlus™ (SSI) DPS
Receptacle, Through Hole, Right Angle, with Beveled Metal Pins, 26 Circuits, Power
Beta 1, Signal 24, Power Alpha 1, Lead-Free
Documents:
3D Model
Drawing (PDF)
Product Specification PS-87606-002 (PDF)
Application Specification AS-87631-018 (PDF)
RoHS Certificate of Compliance (PDF)
Series
image - Reference only
EU RoHS
ELV and RoHS
Compliant
REACH SVHC
Contains SVHC: No
Low-Halogen Status
Low-Halogen
China RoHS
Agency Certification
CSA
UL
LR19980
E29179
General
Product Family
Series
Application
Comments
Overview
Product Name
UPC
PCB Receptacles
87607
Board-to-Board, Power
Standard Power Blade Position: A1, B1
EXTreme PowerPlus™ (SSI)
EXTreme PowerPlus™
822348551880
Need more information on product
environmental compliance?
Email productcompliance@molex.com
For a multiple part number RoHS Certificate of
Compliance, click here
Please visit the Contact Us section for any
non-product compliance questions.
Physical
(p)ower-(s)ignal Configuration
Circuits (Loaded)
Circuits (maximum)
Color - Resin
Durability (mating cycles max)
Flammability
Glow-Wire Compliant
Guide to Mating Part
Lock to Mating Part
Material - Metal
Material - Plating Mating
Material - Plating Termination
Material - Resin
Net Weight
Number of Rows
Orientation
PC Tail Length
PCB Locator
PCB Retention
PCB Thickness - Recommended
Packaging Type
Pitch - Mating Interface
Plating min - Mating
Plating min - Termination
Polarized to Mating Part
Polarized to PCB
Surface Mount Compatible (SMC)
Temperature Range - Operating
Termination Interface: Style
1p - 24s - 1p
26
26
Black
100
94V-0
No
Yes
None
High Performance Alloy (HPA), Phosphor Bronze
Gold
Tin
High Temperature Thermoplastic
12.252/g
4
Right Angle
3.49mm
No
Yes
2.40mm
Tray
2.54mm, 6.35mm
0.762µm
2.540µm
Yes
Yes
No
-20°C to +105°C
Through Hole
Search Parts in this Series
87607Series
Mates With
87606 EXTreme PowerPlus™ (SSI) DPS
Header
Electrical
Current - Maximum per Contact
Voltage - Maximum
2.5A, 30A
50V
Solder Process Data
Duration at Max. Process Temperature (seconds)
Lead-free Process Capability
Max. Cycles at Max. Process Temperature
Process Temperature max. C
10
SMC & Wave Capable (TH only)
3
260
Material Info
Reference - Drawing Numbers
Application Specification
Product Specification
Sales Drawing
AS-87631-018
PS-87606-002
SD-87607-014
