This document was generated on 02/26/2018
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Overview:
Description:
0050348555
Active
Mini-Fit BMI Connectors
Mini-Fit BMI Header, Dual Row, Right Angle, with Snap-in Plastic Peg PCB Lock, 4
Circuits, PA Polyamide Nylon 6/6, UL 94V-0, with Matte Tin (Sn) Plating
Documents:
3D Model
Drawing (PDF)
Product Specification PS-45750-001-001 (PDF)
Product Specification PS-5556-002-001 (PDF)
General
Product Family
Series
Application
Comments
Product Specification TS-42404-001-001 (PDF)
Packaging Specification PK-42404-002-001 (PDF)
RoHS Certificate of Compliance (PDF)
Series image - Reference only
EU ELV
Not Relevant
EU RoHS
China RoHS
Compliant
REACH SVHC
Not Contained Per
-ED/01/2018 (15
January 2018)
Halogen-Free
Status
Low-Halogen
Need more information on product
environmental compliance?
Email productcompliance@molex.com
Please visit the Contact Us section for any
non-product compliance questions.
China ROHS
ELV
RoHS Phthalates
Green Image
Not Relevant
Not Contained
Overview
Product Name
UPC
Physical
Breakaway
Circuits (Loaded)
Circuits (maximum)
Color - Resin
Durability (mating cycles max)
Glow-Wire Capable
Guide to Mating Part
Lock to Mating Part
Material - Metal
Material - Plating Mating
Material - Plating Termination
Material - Resin
Net Weight
Number of Rows
Orientation
PC Tail Length
PCB Locator
PCB Retention
PCB Thickness - Recommended
Packaging Type
Pitch - Mating Interface
Plating min - Mating
Plating min - Termination
Polarized to Mating Part
Polarized to PCB
Shrouded
Stackable
Surface Mount Compatible (SMC)
Temperature Range - Operating
Termination Interface: Style
PCB Headers
42404
Board-to-Board, Power, Wire-to-Board
Current = 13A max. per circuit when header is mated to
a receptacle loaded with 45750 Mini-Fit Plus HCS Crimp
Terminal Crimped to 16 AWG wire., See Molex product
specification PS-45750-001 for additional current de-
rating information.
Mini-Fit BMI Connectors
Mini-Fit BMI
883906383824
No
4
4
Natural
30
No
Yes
Yes
Brass
Tin
Matte Tin
Nylon
1.874/g
2
Right Angle
3.30mm
Yes
Yes
1.80mm
Tray
4.20mm
1.524µm
1.270µm
Yes
Yes
Partial
No
No
-40°C to +105°C
Through Hole
Search Parts in this Series
42404 Series
Mates With
15060101 Mini-Fit BMI Panel Mount
Receptacle, 39012105 Mini-Fit Jr.
Receptacle, 15247101 Mini-Fit BMI Vertical
Receptacle Header, 444751021 Mini-Fit BMI
Vertical Receptacle Header, 245135 Mini-Fit
Jr. Cable Assembly
Electrical
Current - Maximum per Contact
Voltage - Maximum
Solder Process Data
Duration at Max. Process Temperature (seconds)
Lead-freeProcess Capability
Max. Cycles at Max. Process Temperature
Process Temperature max. C
Material Info
Engineering Number
Reference - Drawing Numbers
Packaging Specification
Product Specification
Sales Drawing
13.0A
600V
005
WAVE
001
240
A-42404-04B6
PK-42404-002-001
PS-45750-001-001, PS-5556-002-001,
TS-42404-001-001
SD-42404-222
