PIN
RECEPTACLES
PIN RECEPTACLES
WITH ORGANIC FIBRE PLUG
®
SOLDER BARRIER
(SEE SPECIFIC CONTACT RANGE ON PAGES 254 - 262)
0337
0337-0-XX-XX-15-XX-10-0
.020
.078 DIA.
.058 DIA.
Solder mount in Ø .066” ± .003” PTH
#15
Contact for Ø .020” - .032” pins
Also available on 8mm wide carrier tape:
6,000 parts per 13” reel
4280
4280-0-XX-XX-16-XX-10-0
Solder mount in Ø .067” ± .003” PTH
#16
Contact for Ø .022” - .034” pins
Also available on 8mm wide carrier tape:
6,000 parts per 13” reel
.078 DIA.
.062 DIA.
5280
5280-0-XX-XX-16-XX-40-0
Solder mount in Ø .067” ± .003” PTH
#16
Contact for Ø .022” - .034” pins
Also available on 16mm wide carrier tape:
2,200 parts per 13” reel
0332
0332-0-XX-XX-18-XX-10-0
.018
Solder mount in Ø .079” ± .003” PTH
#18
Contact for Ø .037” - .043” pins
Also available on 16mm wide carrier tape:
2,200 parts per 13” reel
.020
.089
.100
.085 DIA.
.062 DIA.
.056 DIA.
.045
.089
.100
.090 DIA.
.072 DIA.
.062
.105
.088 .100
.056 DIA.
.047 DIA.
.009
.051 DIA.
.009
.051 DIA.
.009
.061 DIA.
.009
0479
0479-0-XX-XX-34-XX-10-0
.018
.090 DIA.
Solder mount in Ø .077” ± .003” PTH
#34
Contact for Ø .032” - .046” pins
Also available on 16mm wide carrier tape:
2,200 parts per 13” reel
0375
0375-0-XX-XX-02-XX-10-0
.030
.100 DIA.
Solder mount in Ø .087” ± .003” PTH
#02
Contact for Ø .040” - .050” pins
Also available on 12mm wide carrier tape:
4,500 parts per 13” reel
0353
0353-0-XX-XX-03-XX-10-0
.030
.125 DIA.
Solder mount in Ø .106” ± .003” PTH
#03
Contact for Ø .040” - .060” pins
Also available on 12mm wide carrier tape:
1,300 parts per 13” reel
0384
0384-0-XX-XX-23-XX-10-0
.028
.122 DIA.
Solder mount in Ø .105” ± .003” PTH
#23
Contact for Ø .045” - .065” pins
Also available on 12mm wide carrier tape:
2,000 parts per 13” reel
.072 DIA.
.140
.079 DIA.
.107
.120
.098 DIA.
.178 .192
.097 DIA.
.124
.140
.064 DIA.
.068 DIA.
.009
.009
.078 DIA.
.009
.088 DIA.
.009
0376
0376-0-XX-XX-07-XX-10-0
.030
.140 DIA.
.125 DIA.
Solder mount in Ø .133” ± .003” PTH
#07
Contact for Ø .065” - .082” pins
Also available on 16mm wide carrier tape:
1,500 parts per 13” reel
0321
0321-0-XX-XX-08-XX-10-0
.030
.156 DIA.
Solder mount in Ø .144” ± .003” PTH
#08
Contact for Ø .084” - .102” pins
Also available on 16mm wide carrier tape:
1,700 parts per 13” reel
3435
3435-0-XX-XX-47-XX-04-0
.072 DIA.
.064 DIA.
.030
.088
Solder mount in Ø .046” ± .003” PTH
#47
Contact for Ø .025” - .036” and .025”
square pins.
Also available on 24mm wide
carrier tape: 1,400 parts per 13” reel
.156 .181
.136 DIA.
.143 .165
.061 DIA.
.130
.210
.043 DIA.
.107 DIA.
.018
.122 DIA.
.018
.036 DIA.
SPECIFICATIONS:
Shell Material:
Brass Alloy 360, 1/2 Hard
Contact Material:
Beryllium Copper Alloy 172, HT
Solder Barrier:
Organic Fibre Plug
®
Dimensions: Inches
Tolerances On:
Lengths: ± .005
Diameters: ± .002
Angles:
±2°
RoHS - 2
ORDER CODE: XXXX - 0 - XX - XX -
XX
- XX - XX - 0
BASIC PART #
SPECIFY CONTACT FINISH:
SPECIFY PACKAGING:
27
30
μ”
GOLD OVER NICKEL (RoHS)
43
Discrete Receptacles
02
100
μ”
TIN/LEAD OVER NICKEL
67
Supplied on 13” Reels
80
200
μ”
TIN OVER NICKEL (RoHS)
SPECIFY SHELL FINISH:
01
200
μ”
TIN/LEAD OVER NICKEL
80
200
μ”
TIN OVER NICKEL (RoHS)
CONTACT:
#02, #07, #08, #15, #16, #18, #23, #34 or #47
CONTACT (DATA ON PAGES 254 - 262)
2011/65/EU
Mill-Max Mfg. Corp. • 190 Pine Hollow Road, P.O. Box 300, Oyster Bay, NY 11771 • 516-922-6000 • Fax: 516-922-9253 • www.mill-max.com
PAGE 197 | PIN RECEPTACLES
