COUNT/RATE
COUNT/RATE
2108 SERIES
TOTALIZING COUNTER
• 8 Digit 7mm High LCD Display
• Replaceable Lithium Battery - 8 Year Life
• Compact Size
24 x 48mm (.95˝ x 1.89˝) Front Panel
37.5mm (1.48˝) Depth
C
UL
®
US LISTED
GENERAL FEATURES:
The 2108 Series is a totalizing counter housed in a DIN-sized (24 x 48mm)
enclosure. The 2108 has an eight digit 7mm high LCD display. The count
input (slow speed) and reset input can be by contact closure and by NPN
open collector transistor. The high speed input (7 kHz max) requires a 4
to 30 VDC voltage pulse and is compatible with 2 and 3 wire DC proximity
switches and encoders. The unit is powered by a 3 volt lithium battery with
an eight year life. When changing the battery, the current count value is
retained long enough to allow battery replacement without losing the count
value. The unit can be set remotely or from the front panel. The front panel
reset can be enabled or disabled with jumpering of terminals on back of unit.
WIRING:
87 610 340
1- Reset Input
2- Front Panel Reset Enable
3- Low Speed Input
4- OV
5- High Speed Input
1
2
3
4
5
Low
Speed
Front Reset
Enable
Reset
High
Speed
4 to 30 VDC
+
-
SPECIFICATIONS:
Power
. . . . . . . . . . . . . . . . .
Count Inputs
. . . . . . . . . . .
......................
......................
Low Speed
. . . . . . . . . . . . .
Minimum Pulse
. . . . .
Current Consumption
Leakage Current
. . . .
Residual Voltage
. . . .
High Speed
. . . . . . . . . . . .
1 State
. . . . . . . . . . . .
0 State
. . . . . . . . . . . .
Absorbed current
. . .
Reset Remote
. . . . . . . . . .
......................
......................
Reset Pushbutton
. . . . . . .
......................
Memory
. . . . . . . . . . . . . . .
Protection
. . . . . . . . . . . . .
......................
Connections
. . . . . . . . . . .
......................
Operating temperature
. . .
Storage temperature
. . . . .
Weight
. . . . . . . . . . . . . . . .
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
Lithium battery, 8 year life
Contact Closure (slow speed)
NPN open collector (slow speed)
Voltage input (high speed)
40 Hz
12 ms
52 µA max.
0.2 µA max.
0.4 V max.
7 kHz max.
4 to 30 VDC
0 to 1 VDC
6 mA at 24 VDC
Contact Closure
NPN open collector
12 ms min.
Activate with jumper across
terminals 2 & 4
Yes, 1 lithium battery - 8 year life
Front Panel IP64
Terminal IP20
Screw terminals
2 x 1.5mm
2
capacity
+32 to 131°F (0 to +55°C)
-13° to 158°F (-25°C to 70°C)
2.1 oz. (60g)
5
High Speed
7K Hz max
4
2
Front
Reset
4 Enable
3,1
Low Speed,
Reset
4
7
Press here to remove.
DIMENSIONS:
(mm)
+0.5
44.8
-0
30
CONFORMITY:
Electromagnetic environment
Radiated field
Fast transients
Damped oscillatory wave
Electrostatic discharge
IEC 1000-4-3, level 3, 10 V/M, 26 MHz to 1 GHz
IEC 1000-4-4, level 3, 1 KV
IEC 255.4, level 3, 1 KV
IEC 1000-4-2, level 3, 8 KV
22
-0
20
+0.3
ORDERING INFORMATION:
87 610 340
Products and specifications subject to change without notice.
Consult factory for application assistance.
204 Airline Drive, Suite 300, Coppell, Texas 75019 / Tel: (800) 677-5311 / FAX: (800) 677-3865 / www.crouzet-usa.com
7-5
