Manual Switches
Power Duty Pushbutton
INCANDESCENT, NEON, OR NON-LIGHTED DISPLAY
AML31/32 Series
Electrical Data
Buttons
Lamps and LEDs
Accessories
Mounting Dimensions
page 19
page 42
page 58
pages 56, 57
page 60
FEATURES
UL recognized, CSA certified.
AML31 lamp circuit independent of
switch circuit.
Buttons ordered separately.
*
*
CONTACT ARRANGEMENT
2 poles (Form X)
*AML31 Series: 2-pole.
*AML32 Series: 2-pole.
AML31 ORDER GUIDE
AML31 accepts one incandescent lamp which can be furnished installed or ordered separately.
AML31 E
Housing
Type
B
A
4
AC
Circuitry
Codes
2-Pole, Single-Throw
Normally-Open, Form X:
AD
AC
Alt.
Mom.
Action
Action
Bezel
Color
B
Black
Incandescent
Lamp Type
A
No Lamp Installed
B
6 V Lamp*
C
14 V Lamp*
E
28 V Lamp*
Terminal
Type
4
.187
×
.020
(Solder or
Quick-Connect
Standard Bezel:
AML31E
Rect. Non-Lighted
AML31F
Rect. 1 Lamp Ckt.
Full Guard Bezel:
AML31K
Rect. Non-Lighted
AML31L
Rect. 1 Lamp Ckt.
Manuals
* Lamps will be installed per each lamp circuit specified in the Housing Type.
Example:
AML31EBA4AC
Rectangular pushbutton switch housing,
non-lighted; black bezel; .187
×
.020 ter-
minals; momentary action; 2-pole, single-
throw, normally open, Form X.
AML32 ORDER GUIDE
AML32 has neon lamp wired to 125 or 250 VAC resistor.
AML32 F
Housing
Type
B
C
7
Terminal Type
Lamp Circuit
4
.187
×
.020
(Solder or
Quick-Connect)
with isolated
lamp circuit
7
.187
×
.020
with integral
lamp circuit
AC
Circuitry
Codes
2-Pole, Single-Throw
Normally-Open, Form X:
AD
AC
Alt.
Mom.
Action
Action
Bezel
Color
B
Black
Neon Lamp
Voltage/Color
Red
B
125 VAC
C
250 VAC
Clear
K
125 VAC
L
250 VAC
Green
M
125 VAC
P
250 VAC
Standard Bezel:
AML32F
Rect. 1 Neon Lamp
Full Guard Bezel:
AML32L
Rect. 1 Neon Lamp
Example:
AML32FBC7AC
Rectangular pushbutton switch housing;
black bezel; 250 volt, red neon lamp; .187
×
.020 terminals with integral lamp cir-
cuit; momentary action; 2-pole, single-
throw, normally open, Form X.
Honeywell Sensing and Control 1-800-537-6945 USA
Isolated neon circuit
Integral neon circuit
1-815-235-6847 International 1-800-737-3360 Canada
33
