Product data sheet
Characteristics
XCSDMR5902
coded magnetic switch XCSDMR - SIL 3 - 1
NC+1 NO, NC staggered - cable 2 m
Main
Range of product
Product or component
type
Component name
Design
Size
Contacts type and com-
position
Contacts operation
Material
Electrical connection
Cable composition
Cable length
Number of poles
Approach directions
[Ue] rated operational
voltage
Preventa Safety detection
Coded magnetic switch
XCSDMR
Cylindrical
Ø 30 x 38.5 mm
1 NC + 1 NO
Staggered
Plastic
Pre-cabled
2m
2
1 direction
24 V
The information provided in this documentation contains general descriptions and/or technical characteristics of the performance of the products contained herein.
This documentation is not intended as a substitute for and is not to be used for determining suitability or reliability of these products for specific user applications.
It is the duty of any such user or integrator to perform the appropriate and complete risk analysis, evaluation and testing of the products with respect to the relevant specific application or use thereof.
Neither Schneider Electric Industries SAS nor any of its affiliates or subsidiaries shall be responsible or liable for misuse of the information contained herein.
4 x 0.25 mm²
Complementary
[Sa] assured operating distance
[Sar] assured tripping distance
[Ie] rated operational current
[Uimp] rated impulse withstand voltage
Resistance across terminals
Short circuit protection
Contacts material
Electrical durability
Maximum switching voltage
Switching capacity in mA
Insulation resistance
Breaking capacity
Switching frequency
Safety level
8 mm
20 mm
<= 100 A
2.5 kV conforming to EN/IEC 60947-5-1
10 Ohm
500 mA external cartridge fuse type gG (gl)
Rhodium
1200000 cycles
100 V DC
0.1...100 mA
1000 MOhm
<= 10 VA
150 Hz
Can reach category 4 (with the appropriate monitoring system and correctly
wired) conforming to EN/ISO 13849-1
Can reach PL = e (with the appropriate monitoring system and correctly wired)
conforming to EN/ISO 13849-1
Can reach SIL 3 (with the appropriate monitoring system and correctly wired)
conforming to EN/IEC 61508
B10d = 5000000 (value given for a life time of 20 years limited by mechanical or
contact wear)
Thermoplastic PBT
PVC
0.146 kg
Safety reliability data
Enclosure material
Cable material
Product weight
Feb 10, 2012
1
Environment
Standards
CSA C22-2 No 14
EN 1088
EN/IEC 60204-1
EN/IEC 60947-5-1
EN/ISO 12100
ISO 14119
UL 508
BG
CSA
UL
TH
-25...85 °C
-40...85 °C
10 gn (f = 10...150 Hz) conforming to IEC 60068-2-6
30 gn for 11 ms conforming to IEC 60068-2-27
>= 0.3 mT
Class II conforming to IEC 60536
IP66 conforming to IEC 60529
IP67 conforming to IEC 60529
Compliant
0729
Product certifications
Protective treatment
Ambient air temperature for operation
Ambient air temperature for storage
Vibration resistance
Shock resistance
Sensitivity to magnetic fields
Class of protection against electric shock
IP degree of protection
RoHS EUR status
RoHS EUR conformity date
2
