Product data sheet
Characteristics
RE48AMH13MW
time delay relay 2 functions - 0.02 s..300 h -
24..240 V AC - 2 OC
Product availability: Stock - Normally stocked in distribution facility
Price*: 86.00 USD
Main
Commercial Status
Range of product
Product or component
type
Electrical connection
Discrete output type
Contacts type and
composition
Component name
Time delay type
Commercialised
Zelio Time
Electronic timing relay
Plug-in sub-base 8 pin(s)
Relay
The information provided in this documentation contains general descriptions and/or technical characteristics of the performance of the products contained herein.
This documentation is not intended as a substitute for and is not to be used for determining suitability or reliability of these products for specific user applications.
It is the duty of any such user or integrator to perform the appropriate and complete risk analysis, evaluation and testing of the products with respect to the relevant specific application or use thereof.
Neither Schneider Electric Industries SAS nor any of its affiliates or subsidiaries shall be responsible or liable for misuse of the information contained herein. *Prices are indicative
Timed contact, AgNi (cadmium free)
Instantaneous contact, AgNi (cadmium free)
RE48A
A1
A2
H1
H2
0.02...1.2 s
0.05...3 s
0.2...12 h
0.2...12 min
0.2...12 s
0.5...30 h
0.5...30 min
0.5...30 s
2...120 h
2...120 min
2...120 s
5...300 h
5...300 min
5...300 s
24...240 V AC/DC 50/60 Hz
0.9...1.1 Us DC
0.85...1.1 Us AC
5A
Time delay range
[Us] rated supply
voltage
Voltage range
[In] rated current
Complementary
Product front plate size
Control type
Housing material
Repeat accuracy
Temperature drift
Voltage drift
Setting accuracy of time delay
Minimum pulse duration
Reset time
Pick up duration
On-load factor
Power consumption in VA
Power consumption in W
48 x 48 mm
Selector switch on front panel
Self-extinguishing
+/- 0.2 % of the maximum setting value conforming to IEC 61812-1
+/- 0.02 %/°C of the maximum setting value conforming to IEC 61812-1
+/- 1 %/V of the maximum setting value 24...48 V
+/- 0.2 %/V of the maximum setting value 48...240 V
+/- 5 % of full scale at 25 °C conforming to IEC 61812-1
20 ms
>= 25 ms on de-energisation
55 ms
100 %
4.8 VA 240 V
1.1 VA 24 V
1.7 W 240 V
0.5 W 24 V
Feb 28, 2016
1
Breaking capacity
Minimum switching current
Maximum switching current
Maximum switching voltage
Electrical durability
Mechanical durability
Output voltage
1250 VA
100 mA
5A
250 V AC/DC
100000 cycles
30000000 cycles
240 V 1.5 A AC-15
30 V 2 A DC-13
240 V 5 A AC-12
CE
2 kV (common mode) conforming to IEC 61000-4-5 level 3
1 kV (differential mode) conforming to IEC 61000-4-5 level 3
Base mounted: socket
Panel mounted: system supplied with the product
LED indicator green on steady: relay energised, no timing in progress
LED indicator green flashing: relay energised timing in progress
1 LED yellow output relay state
0.31 lb(US) (0.14 kg)
Marking
Surge withstand
Mounting support
Local signalling
Product weight
Environment
Humidity drift
Immunity to microbreaks
Dielectric strength
Protection against electric shocks
Standards
+/- 0.05 %/%RH of the maximum setting value conforming to IEC 61812-1
< 10 ms
1 kV 1 mA/1 minute conforming to IEC 61812-1
4 kV category 3 conforming to IEC 61812-1
4 kV category 3 conforming to IEC 60664-1
73/23/EEC
89/336/EEC
93/68/EEC
EN 50081-1/2
EN 50082-1/2
IEC 60669-2-3
IEC 61812-1
CSA
C-Tick
CULus
GL
UL
-40...158 °F (-40...70 °C)
-4...122 °F (-20...50 °C)
IP50 (front face) conforming to IEC 60529
IP40 (housing) conforming to IEC 60529
0.35 mm (f = 10...55 Hz) conforming to IEC 60068-2-6
93 % without condensation conforming to IEC 60068-2-3
8 kV (in air) conforming to EN/IEC 61000-4-2 level 3
6 kV (in contact) conforming to EN/IEC 61000-4-2 level 3
9.14 V/yd (10 V/m), 26 MHz to 1 GHz conforming to IEC 61000-4-3 level 3
4 kV, direct conforming to EN/IEC 61000-4-4 level 4
2 kV, capacitive connecting clip conforming to EN/IEC 61000-4-4 level 4
10 V (0.15...80 MHz) conforming to EN/IEC 61000-4-6 level 3
95 %/5 s conforming to EN/IEC 61000-4-11
60 %/100 ms conforming to EN/IEC 61000-4-11
30 %/10 ms conforming to EN/IEC 61000-4-11
Class B (0.15...30 MHz) conforming to EN 55022 (EN 55011 group 1)
Product certifications
Ambient air temperature for storage
Ambient air temperature for operation
IP degree of protection
Vibration resistance
Relative humidity
Resistance to electrostatic discharge
Resistance to electromagnetic fields
Resistance to fast transients
Immunity to radioelectric fields
Immunity to voltage dips
Disturbance radiated/conducted
2
