SMT POWER INDUCTORS
Toroid - HCCI-80 Series
Height:
12.7mm Max
Footprint:
31.0mm x 25.4mm Max
Current Rating:
up to 38A
Inductance Range:
1.1µH to 18.1µH
Electrical Specifications @ 25°C — Operating Temperature -40°C to +130°C
6
Pulse
4,5
Part
Number
P0599NL
P0598NL
P0597NL
P0596NL
P0599NL
P0595NL
P0598NL
P0597NL
P0596NL
P0595NL
Inductance
@ Irated
(µH TYP)
1.1
1.6
2.45
3.2
4.3
4.52
6.4
9.8
12.8
18.1
Irated
(A)
38
34
27
24
19
19
17
13.5
12
9.5
Ω
DCR (mΩ)
TYP
1.1
1.4
2.2
3.0
4.4
4.2
5.6
8.8
12.0
16.8
MAX
1.3
1.6
2.5
3.5
5.1
4.8
6.4
10.1
13.8
19.3
Inductance
@ 0A
DC
(µH ±15%)
2.1
3.9
5.7
8.0
8.4
10.5
15.6
22.8
32.0
42.0
Reference
ET
(Volt-µsec)
4.20
4.20
6.00
4.20
8.40
9.00
8.40
12.00
8.40
18.00
Flux Density
Factor
(K1)
0.62
0.48
0.39
0.33
0.31
0.29
0.24
0.20
0.17
0.14
Core Loss
Factor
(K2)
1.50E-09
1.50E-09
1.50E-09
1.50E-09
1.50E-09
1.50E-09
1.50E-09
1.50E-09
1.50E-09
1.50E-09
Temp. Rise
Factor
Connection
(K3)
33.8
33.8
33.8
33.8
33.8
33.8
33.8
33.8
33.8
33.8
Parallel
Parallel
Parallel
Parallel
Series
Parallel
Series
Series
Series
Series
NOTES:
1. Temperature rise is 55°C in typical buck or boost circuits operating
at 300kHz with the rated Idc current and reference ET applied to the
inductor.
2. Total loss in the inductor is 1.8W for 55°C temperature rise above
ambient.
3. In high volt-time applications, additional heating in the component
can occur due to core losses in the inductor which may necessitate
derating the current in order to limit the temperature rise of the
component. In order to determine the approximate total losses
(or temperature rise) for a given application, both copper and core
losses should be taken into account.
Estimated Temperature Rise:
Trise = K3 * (Coreloss(W) + Copperloss(W))
.833
(C)
CopperLoss = Irms
2
* DCR_Typical (mΩ) / 1000
CoreLoss = K2 * (Freq_kHz)
1.26
* (ΔB)
2.11
ΔB
= K1 * Volt-µsec * 100
4. Optional Tape & Reel packaging can be ordered by adding a "T"
suffix to the part number (i.e. P0595NL becomes P0595NLT). Pulse
complies to industry standard tape and reel specification EIA481.
5. The "NL" suffix indicates an RoHS-compliant part number. Non-NL
suffixed parts are not necessarily RoHS compliant, but are electrically
and mechanically equivalent to NL versions. If a part number does
not have the "NL" suffix, but an RoHS compliant version is required,
please contact Pulse for availability.
6. The temperature of the component (ambient plus temperature rise)
must be within the stated operating temperature range.
Mechanical
4X
.320 ± .020
8,13 ± 0,51
1.097
27,86
2
1.000
25,40
3
P059X
.600
15,24
2
3
.400
10,16
Date Code
Country of Origin
Schematic
1
.155
3,94
1
4
4
1
4
Weight
. . . . . . . 18.7 grams
Tape & Reel.
. . . . . . 75/reel
Tube
. . . . . . . . . . . . 20/tube
Dimensions:
Inches
mm
Unless otherwise specified,
all tolerances are ± .010
0,25
1.220 MAX
30,99
SUGGESTED PAD LAYOUT
.500 MAX
12,70
2
1:1 ±1%
3
1.100
27,94
.006/0,15
4 SURFACES
USA 858 674 8100
•
Germany 49 7032 7806 0
•
Singapore 65 6287 8998
•
Shanghai
86 21 54643211 / 2
•
China 86 755 33966678
•
Taiwan 886 3 4641811
www.pulseeng.com
