MKP1848S DC-Link
www.vishay.com
Vishay Roederstein
Metallized Polypropylene Film Capacitors
DC-Link Capacitor
FEATURES
• Slim line, low building height
• Very long useful life time: Up to 100 000 h at
U
NDC
and 70 °C
• High ripple current capability, low ESR, low ESL
• Temperature range: 105 °C
• Mounting: Radial
• Material categorization: For definitions of
compliance please see
www.vishay.com/doc?99912
APPLICATIONS
• PV micro inverters
• LED street lighting
• On board chargers (EV/HEV), battery chargers
QUICK REFERENCE DATA
Rated capacitance range
Capacitance tolerance
Rated voltage range, U
NDC
Climatic testing class
Rated temperature
Maximum permissible case temperature
Maximum applicable peak to peak ripple voltage
Reference standards
Dielectric
Electrodes
Construction
Encapsulation
Terminals
Self inductance (L
S
)
Withstanding DC voltage between terminals
(1)
Insulation resistance
Life time expectancy
Marking
2 μF to 100 μF
5%
500 V to 1000 V
40/105/56
85 °C
105 °C, observing voltage derating
0.2 x U
NDC
IEC 61071, IEC 60068
Polypropylene film
Metallized dielectric capacitor
Mono construction
Plastic case sealed with resin; flame retardant
Tinned wire
< 1 nH per mm of lead spacing
1.5 U
NDC
for 10 s, cut off current 10 mA, rise time
1000 V/s
RC between leads, after 1 min > 10 000 s
For U
NDC
500 V measuring voltage 100 V
For U
NDC
> 500 V measuring voltage 500 V
Useful life time: > 100 000 h at U
NDC
and 70 °C
FIT: < 10 x 10
-9
/h (10 per 10
9
component h) at 0.5 x U
NDC
, 40 °C
C-value; tolerance; rated voltage; code for dielectric material;
code for manufacturing origin; manufacturer’s type designation;
manufacturer’s logo; year and week of manufacture
Notes
• For more detailed data and test requirements, contact
dc-film@vishay.com
• For general information like characteristics and definitions used for film capacitors follow the link:
www.vishay.com/doc?28147
(1)
See document “Voltage Proof Test for Metalized Capacitors” (www.vishay.com/doc?28169)
DC VOLTAGE RATINGS
U
NDC
at 85 °C
U
OPDC
at 70 °C
U
OPDC
at 105 °C
500 V
600 V
350 V
700 V
800 V
500 V
1000 V
1200 V
750 V
Revision: 19-Mar-13
Document Number: 26010
1
For technical questions, contact:
dc-film@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
MKP1848S DC-Link
www.vishay.com
COMPOSITION OF CATALOG NUMBER
Vishay Roederstein
MULTIPLIER
(nF)
10
100
1000
10 000
4
5
6
7
510
610
710
CAPACITANCE
(numerically)
P1
(mm)
27.5
PITCH
CODE
K
P
Y
Example:
1000 nF
10 000 nF
100 000 nF
1 μF
10 μF
100 μF
37.5
52.5
PRODUCT HEIGHT CODE
A
(2)
MKP
1848
S
6
10
70
J
P
4
B
B
C
TYPE CONSTRUCTION
D
(2)
E
(2)
F
METALLIZED POLYPROPYLENE
h = 12 mm
h = 15 mm
h = 18 mm
h = 20 mm
h = 22 mm
h = 24 mm
VOLTAGE
U
N
= 50 = 500 V
DC
U
N
= 70 = 700 V
DC
U
N
= 10 = 1000 V
DC
TOLERANCE
J
K
±5%
± 10 %
SPECIAL
CODE FOR TERMINAL
2
4
5
6
(1)
2 pins
4 pins P2 = 10.2 mm
4 pins P2 = 20.3 mm
6 pins P2 = 20.3 mm
Customized
Notes
(1)
(2)
Tabs terminals or customized terminals are available on request
Product height on request
Revision: 19-Mar-13
Document Number: 26010
2
For technical questions, contact:
dc-film@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
MKP1848S DC-Link
www.vishay.com
Vishay Roederstein
DIMENSIONS
in millimeters
l
w
h
lt
Ø dt
P1
P1 ± 0.5 mm
It = 6 mm + 0 mm/- 1 mm
P1
l
w
h
lt
Ø dt
P1
P1 and P2 ± 0.5 mm
It = 6 mm + 0 mm/- 2 mm
P2
P2
P1
l
w
h
lt
Ø dt
P2
2 x P2
P1 and P2 ± 0.5 mm
It = 6 mm + 0 mm/- 2 mm
P1
P2
P2
P1
Notes
• Standard dimension
• Ø dt ± 10 % of standard diameter specified
Revision: 19-Mar-13
Document Number: 26010
3
For technical questions, contact:
dc-film@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
MKP1848S DC-Link
www.vishay.com
Vishay Roederstein
tan
10 kHz
(< 10
-4
)
(4)
ELECTRICAL DATA AND ORDERING CODE
U
NDC
HEIGHT CAP.
(7)
(V)
(mm)
(μF)
DIMENSION
(5)
(mm)
w
12
5
7
10
15
15
20
30
50
(6)
10
500
15
18
20
30
50
20
30
24
50
100
(6)
12
3
5
7
10
15
15
20
30
(6)
7
700
10
18
15
20
30
15
20
24
30
50
(6)
39.0 24.0 57.5 52.5
70.0 24.0 57.5 52.5
20.3
20.3
8
8
240
400
10.5
-
11
18
6
-
5
3
220
-
200
200
MKP1848S63070JY*F
MKP1848S65070JY6F
27.0 18.0 42.0 37.5
39.0 18.0 42.0 37.5
35.0 18.0 57.5 52.5
50.0 18.0 57.5 52.5
30.0 24.0 42.0 37.5
39.0 24.0 42.0 37.5
10.2
10.2
20.3
20.3
10.2
10.2
17
17
8
8
17
17
170
255
160
240
255
340
6
8.5
7.5
-
8.5
6.5
9
8
11.5
9
11
7
9
-
7
6
8
5.5
7.5
5
5.5
4
110
110
220
-
110
110
95
95
200
200
95
95
MKP1848S61070JP*C
MKP1848S61570JP*C
MKP1848S62070JY*C
MKP1848S63070JY5C
MKP1848S61570JP*F
MKP1848S62070JP*F
33.0 15.0 57.5 52.5
45.0 15.0 57.5 52.5
62.0 15.0 57.5 52.5
24.0 18.0 42.0 37.5
20.3
20.3
20.3
10.2
8
8
8
17
120
160
240
119
6
8
-
5
6.5
8.5
12
5
12
9
-
15
10
7.5
5
11.5
220
220
-
110
200
200
200
95
MKP1848S61570JY*B
MKP1848S62070JY*B
MKP1848S63070JY6B
MKP1848S57070JP*C
39.0 24.0 57.5 52.5
70.0 24.0 57.5 52.5
24.0 12.0 31.5 27.5
27.0 15.0 31.5 27.5
27.0 15.0 42.0 37.5
33.0 15.0 42.0 37.5
20.3
20.3
-
-
10.2
10.2
7
7
35
35
17
17
350
700
105
175
119
170
11.5 12.5
-
3.5
5
5
6
22
-
-
5
6.5
4
-
14
8
15
11
3.5
2
-
-
11.5
8
250
-
45
45
110
110
220
220
-
-
95
95
MKP1848S65050JY*F
MKP1848S71050JY6F
MKP1848S53070JK2A
MKP1848S55070JK2B
MKP1848S57070JP*B
MKP1848S61070JP*B
27.0 18.0 42.0 37.5
39.0 18.0 42.0 37.5
35.0 18.0 57.5 52.5
50.0 18.0 57.5 52.5
30.0 24.0 42.0 37.5
39.0 24.0 42.0 37.5
10.2
10.2
20.3
20.3
10.2
10.2
15
15
7
7
15
15
225
300
210
350
300
450
6.5
8.5
8
-
8.5
11
7
9
8.5
12.5
9
12
6.5
5
6.5
-
5
3.5
5
4
5.5
3.5
4
2.5
125
125
250
250
125
125
110
110
220
220
110
110
MKP1848S61550JP*C
MKP1848S62050JP*C
MKP1848S63050JY*C
MKP1848S65050JY5C
MKP1848S62050JP*F
MKP1848S63050JP*F
33.0 15.0 57.5 52.5
45.0 15.0 57.5 52.5
62.0 15.0 57.5 52.5
24.0 18.0 42.0 37.5
20.3
20.3
20.3
10.2
7
7
7
15
140
210
350
150
6
8.5
-
5
6.5
9
13.5
5.5
9.5
6.5
-
10
8
5.5
3.5
7.5
250
250
-
125
220
220
220
110
MKP1848S62050JY*B
MKP1848S63050JY*B
MKP1848S65050JY6B
MKP1848S61050JP*C
h
l
-
-
10.2
10.2
30
30
15
15
150
210
150
225
P1
P2 dV/dt I
PEAK
(mm) (mm) (V/μs) (A)
I
RMS (2)
(A)
ESR
(3)
(m)
ORDERING CODE
(1)
2
4
2
4
2
4
PINS PINS PINS PINS PINS PINS
4
5
5
6.5
-
-
5
7
13
10
10
7
-
-
7.5
5
60
60
125
125
-
-
110
110
MKP1848S55050JK2A
MKP1848S57050JK2B
MKP1848S61050JP*B
MKP1848S61550JP*B
24.0 12.0 31.5 27.5
27.0 15.0 31.5 27.5
27.0 15.0 42.0 37.5
33.0 15.0 42.0 37.5
10.5 11.5
Revision: 19-Mar-13
Document Number: 26010
4
For technical questions, contact:
dc-film@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
MKP1848S DC-Link
www.vishay.com
Vishay Roederstein
tan
10 kHz
(< 10
-4
)
(4)
ELECTRICAL DATA AND ORDERING CODE
U
NDC
HEIGHT CAP.
(7)
(V)
(mm)
(μF)
DIMENSION
(5)
(mm)
w
12
2
5
7
15
10
15
20
3
5
1000
18
7
10
15
20
7
10
24
15
20
30
(6)
(6)
P1
P2 dV/dt I
PEAK
(mm) (mm) (V/μs) (A)
I
RMS (2)
(A)
ESR
(3)
(m)
ORDERING CODE
(1)
h
l
-
10.2
10.2
20.3
20.3
20.3
10.2
10.2
10.2
10.2
20.3
20.3
10.2
10.2
20.3
20.3
20.3
50
25
25
12
12
12
25
25
25
25
12
12
25
25
12
12
12
100
125
175
120
180
240
75
125
175
250
180
240
175
250
180
240
360
2
4
2
4
2
4
PINS PINS PINS PINS PINS PINS
3
4.5
5.5
5.5
7.5
-
3.5
4.5
6.5
7.5
-
-
6.5
8.5
8
9.5
-
-
4.5
6
6
8
11
3.5
5
7
8
9
10
6.5
9
8.5
10
15.5
16
16
12
13
9
-
27
16
12
8
-
-
12
8
9
7
-
-
11.5
8
10
6.5
5
19
11.5
8
6
6.5
5
8
6
6.5
5
4
40
105
105
160
160
-
105
105
105
105
-
-
105
105
160
160
-
-
90
90
140
140
140
90
90
90
90
140
140
90
90
140
140
140
MKP1848S52010JK2A
MKP1848S55010JP*B
MKP1848S57010JP*B
MKP1848S61010JY*B
MKP1848S61510JY*B
MKP1848S62010JY6B
MKP1848S53010JP*C
MKP1848S55010JP*C
MKP1848S57010JP*C
MKP1848S61010JP*C
MKP1848S61510JY5C
MKP1848S62010JY5C
MKP1848S57010JP*F
MKP1848S61010JP*F
MKP1848S61510JY*F
MKP1848S62010JY*F
MKP1848S63010JY6F
24.0 12.0 31.5 27.5
27.0 15.0 42.0 37.5
33.0 15.0 42.0 37.5
33.0 15.0 57.5 52.5
45.0 15.0 57.5 52.5
62.0 15.0 57.5 52.5
24.0 18.0 42.0 37.5
27.0 18.0 42.0 37.5
39.0 18.0 42.0 37.5
39.0 18.0 42.0 37.5
50.0 18.0 57.5 52.5
50.0 18.0 57.5 52.5
30.0 24.0 42.0 37.5
39.0 24.0 42.0 37.5
39.0 24.0 57.5 52.5
39.0 24.0 57.5 52.5
70.0 24.0 57.5 52.5
Notes
(1)
Change the * symbol with special code for the terminals
(2)
Maximum RMS current at 10 kHz, + 85 °C,
t
= + 15 °C, capacitance tolerlance
± 5 %
(3)
Equivalent series resistance typical values at 10 kHz
(4)
Maximum tan
values
(5)
Standard dimension
(6)
6 pins
(7)
Intermediate capacitance values available on request
PACKAGING INFORMATION
U
NDC
(V)
HEIGHT
(mm)
12
CAP.
(1)
(μF)
5
7
10
15
15
20
30
50
(2)
500
18
10
15
20
30
50
20
24
30
50
100
(2)
Ø dt
0.8
0.8
1.0
1.0
1.2
1.2
1.2
1.0
1.0
1.0
1.2
1.2
1.0
1.0
1.2
1.2
ORDERING CODE
(1)
MKP1848S55050JK2A
MKP1848S57050JK2B
MKP1848S61050JP*B
MKP1848S61550JP*B
MKP1848S62050JY*B
MKP1848S63050JY*B
MKP1848S65050JY6B
MKP1848S61050JP*C
MKP1848S61550JP*C
MKP1848S62050JP*C
MKP1848S63050JY*C
MKP1848S65050JY5C
MKP1848S62050JP*F
MKP1848S63050JP*F
MKP1848S65050JY*F
MKP1848S71050JY6F
MASS
(g)
7
10.5
14
18.5
22.5
31.5
43
15
15.5
25
30.5
41.5
25
32
41.5
78
SPQ
(3)
(pcs)
99
90
70
56
40
30
20
77
70
49
40
25
63
49
40
20
Revision: 19-Mar-13
Document Number: 26010
5
For technical questions, contact:
dc-film@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
京公网安备 11010802033920号
EEWORLD
