Part number
CY2BM
CY3DM
CY3J
CY3JM
CY3JN
CY3A
CY3AP
CY4F
CY4E
CY4D
CY7A
CY7AP
CY5B
CY6B
CY6BP
CY6C
CY6CP
CY6G
CY7B
CY7BP
CY8G
CY8GP
CY8J
CY8JP
CY9B
CY12A
CY11B
CY11BP
CY12B
CY12BP
CY14A
CY14AC
CY14AP
CY14B
CY14BP
CY15A
CY16B
CY16BP
CY19A
CY19B
CY19BP
CY20A
CY20AP
CY22A
CY22AP
CY22B
CY22BP
CY24A
CY24AP
CY25A
CY27A
CY30B
CY36A
CY48A
CY100A
Freq. (MHz)
2.457600
3.579545
3.686400
3.686400
3.686400
4.000
4.000
4.096
4.194304
4.915200
5.000
5.000
5.068800
6.000
6.000
6.144
6.144
6.400
7.372800
7.372800
8.000
8.000
8.192
8.192
9.830400
10.000
11.059200
11.059200
12.000
12.000
14.318180
14.318180
14.318180
14.745600
14.745600
15.000
16.000
16.000
18.000
18.432
18.432
19.660800
19.660800
20.000
20.000
22.118400
22.118400
24.000
24.000
25.000
27.000
32.000
36.000
48.000
100.000
CL
32pF
18pF
series
18pF
20pF
series
20pF
20pF
12pF
series
series
20pF
series
series
20pF
30pF
20pF
20pF
series
20pF
series
20pF
series
20pF
series
series
series
20pF
series
20pF
series
18pF
20pF
series
20pF
series
series
20pF
series
series
20pF
series
20pF
series
20pF
series
20pF
series
20pF
series
series
series
series
series
series
Max ESR
320
175
175
175
175
100
100
100
75
75
50
50
50
40
40
40
40
40
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
40
40
40
40
40
40
40
90
CYxx Model
Leaded HC49 Crystal
0.400
(10.16)
0.150
(3.81)
CRYSTEK
3.579545
DC
0.425
(10.80)
0.183
(4.65)
0.019
(0.48)
Resistance at series resonance
Freq. (MHz)
1.8432 - 1.999
2.0 - 2.09
2.1 - 2.5
2.501 - 4.0
4.1 - 4.9
5.0 - 5.9
6.0 - 11.9
12.0 - 22.9
30.0 - 50.0
50.1 - 100.0
100.1 - 150.0
Max ESR
700
500
320
175
100
50
40
30
40
90
120
0.530
(13.46)
Max
Table 1
0.500
(12.70) 0.192 ±0.005
(4.88 ±0.13)
Min
Dimensions inches (mm)
All dimensions are maximum unless otherwise specified
3
rd
3
rd
3
rd
3
rd
3
rd
Frequency Range: 1.843200 MHz to 40 MHz (fund)
40 MHz to 100 MHz (3
rd
O/T)
100 MHz to 150 MHz (5
th
O/T)
Calibration Tolerance: ±50ppm (Standard p/n)
(Option) ±10ppm to ±100ppm
Frequency Stability: ±100ppm (Standard p/n)
(Option) ±15ppm to ±100ppm
Optional spacer available
Operating Temp. range:
(Option)
(Option)
Storage Temp. range:
Shunt Capacitance:
Drive level:
ESR:
Aging:
Insulation Resistance:
0 to 70°C (Standard p/n)
-20 to 70°C
-40°C to 85°C
-45°C to 90°C
7.0pF Max
100uW Typical
See table 1
<3ppm 1
st
year Max
500 Megaohms Min at 100Vdc
Build Your Own P/N
CY X X X X X - Freq
Frequency Tolerance
at 25°C
1
2
3
4
5
6
7
±10 ppm
±15 ppm
±20 ppm
±25 ppm
±30 ppm
±50 ppm
±100 ppm
B
C
D
E
F
G
H
I
±15 ppm
±20 ppm
±25 ppm
±30 ppm
±50 ppm
±100 ppm
±15 ppm
±20 ppm
Frequency Stability
over Temp Range
(0 to 70°C)
(0 to 70°C)
(0 to 70°C)
(0 to 70°C)
(0 to 70°C)
(0 to 70°C)
(-20 to 70°C)
(-20 to 70°C)
J
K
L
M
N
O
P
Q
±30ppm
±50 ppm
±100 ppm
±20 ppm
±25 ppm
±30 ppm
±50 ppm
±100 ppm
(-20 to 70°C)
(-20 to 70°C)
(-20 to 70°C)
(-40 to 85°C)
(-40 to 85°C)
(-40 to 85°C)
(-40 to 85°C)
(-40 to 85°C)
Load
Capacitance
1
2
3
4
5
6
7
8
Series
14 pF
16 pF
18 pF
20 pF
22 pF
25 pF
32 pF
S
Options
Spacer
Mode
Example:
CY4F51S-20.000 = ±25ppm at 25°C, ±50ppm 0 to 70°C, 20pF Load Cap, Fundamental,
with Spacer, 20.000 MHz
Specifications subject to change without notice.
1
3
5
Fundamental 1.8432-40 MHz
3
rd
Overtone 40-100 MHz
5
th
Overtone 100-150 MHz
CRYSTEK
CORPORATION
TD-021008 Rev. L
12730 Commonwealth Drive • Fort Myers, Florida 33913
Phone: 239-561-3311 • 800-237-3061
Fax: 239-561-1025 • www.crystek.com
