The above part number refers to a 400 Z Series (0201) 1 pF capacitor,
P tolerance (±0.02 pF), 50 WVDC, with T termination (Tin Plated over Nickel Barrier Termination), RoHS Compliant), and tape and reel packaging.
ATC accepts orders for our parts using designations
with
or
without
the
“ATC” prefix. Both methods of defining the part number are equivalent, i.e.,
part numbers referenced with the “ATC” prefix are interchangeable to parts
referenced without the “ATC” prefix. Customers are free to use either in
specifying or procuring parts from American Technical Ceramics.
For additional information and catalogs contact your ATC
representative or call direct at (+1-631) 622-4700.
Consult factory for additional performance data.
A M E R I C A N
ATC North America
sales@atceramics.com
T E C H N I C A L
ATC Europe
saleseur@atceramics.com
C E R A M I C S
ATC Asia
sales@atceramics-asia.com
2
w w w.a tc e r a m ics .c o m
Mechanical Dimensions
B
1
Outline Dimensions
0.0128 ± 0.002
(0.325 ± 0.050)
0.023 ± 0.002
(0.60 ± 0.05)
W
L
T
0.009 ± 0.002
(0.225 ± 0.050)
B
2
Inches (mm)
L:
.023 ± .002 (.60 ± .050)
Z (0201)
W: .0128 ± .002 (.325 ± .050)
T: .009 ± 002 (.225 ± .050)
B
1
: .0.004 ±.004 (.10 ±.10)
B
2
: .0.006 ±.002 (.15 ±.05)
Inches (mm)
Suggested Mounting Pad Dimensions
L
W
T
Horizontal Mount
Case Size
B
A
C
D
B
A Min.
0.013
(0.33)
B Min.
0.010
(0.25)
C Min.
0.010
(0.25)
D Min.
0.030
(0.76)
Inches (mm)
Z 0201
Sales of ATC products are subject to the terms and conditions contained in American Technical Ceramics Corp. Terms and Conditions of Sale (ATC document
#001-992 Rev. B; 12/05). Copies of these terms and conditions will be provided upon request. They may also be viewed on ATC’s website at www.atceramics.
com/productfinder/default.asp. Click on the link for Terms and Conditions of Sale.
ATC has made every effort to have this information as accurate as possible. However, no responsibility is assumed by ATC for its use, nor for any infringements
of rights of third parties which may result from its use. ATC reserves the right to revise the content or modify its product without prior notice.
