ALUMINUM ELECTROLYTIC CAPACITORS
TM
Timer Circuit Use
series
Ideally suited for timer circuits.
Excellent leakage current stability, even subjected to load or no load at high temperature
for a long time.
Compliant to the RoHS directive (2002/95/EC).
Products which are scheduled to be discontinued.
Not recommended for new designs
KL
High
Stability
TM
Performance Characteristics
Specifications
Item
Category Temperature Range
Rated
Voltage Range
Rated Capacitance Range
Capacitance Tolerance
Leakage Current
Tangent of loss angle (tan
δ)
– 40 to +85°C
10 to 50V
1 to 470µF
± 20% (M) (±10% (K) semi-standard) at 120Hz, 20°C
After 2 minutes' application of rated voltage, leakage current is 0.001CV+1 (µA) or less.
Measurement frequency : 120Hz at 20°C
Rated voltage (V)
tan
δ
(MAX.)
10
0.17
16
0.13
10
2
4
16
2
3
25
0.10
25
1.5
2
50
0.08
50
1.5
2
Within ±10% of the initial capacitance value
150% or less than the initial specified value
Less than or equal to the initial specified value
Measurement frequency : 120Hz
Stability at Low Temperature
Rated voltage (V)
Z– 25°C / Z+20°C
Impedance ratio
ZT / Z20 (MAX.)
Z– 40°C / Z+20°C
Endurance
The specifications listed at right shall be met when
the capacitors are restored to 20°C after the rated
voltage is applied for 2000 hours at 85°C.
Capacitance change
tan
δ
Leakage current
Shelf Life
Marking
After storing the capacitors under no load at 85˚C for 1000 hours and then performing voltage treatment based on JIS C 5101-
4 clause 4.1 at 20°C, they shall meet the specified values for the endurance characteristics listed above.
Printed with white color letter on black sleeve.
Radial Lead Type
Sleeve (P.E.T.)
φd
Type numbering system (Example : 10V 33
µ
F)
1
2
3
4
5
6
7
8
9 10
11
U TM 1 A 3 3 0 M PD
φD
+
0.5 MAX.
P
±
0.5
Configuration
Capacitance tolerance
(M :
±20%,
K :
±10%)
(mm)
Pressure
relief vent
L+
1MAX.
15
MIN
4
MIN
φD
6.3
P
8
10 12.5 16
Rated capacitance (33µF)
Rated voltage (10V)
Series name
Type
2.5 3.5 5.0 5.0 7.5
φd
0.5 0.6 0.6 0.6 0.8
•
Please refer to page 20 about the end seal configulation.
Configuration
φ
D
Pb-free leadwire
Pb-free PET sleeve
Dimensions
Cap.
(µF)
V
Code
10
1A
16
1C
25
1E
1
2.2
3.3
4.7
10
22
33
47
100
220
330
470
010
2R2
3R3
4R7
100
220
330
470
101
221
331
471
6.3
×
11
8
×
11.5
8
×
11.5
10
×
16
10
×
20
12.5
×
25
12.5
×
25
6.3
×
11
8
×
11.5
10
×
12.5
10
×
12.5
10
×
20
12.5
×
25
16
×
25
16
×
25
6.3
×
11
6.3
×
11
8
×
11.5
10
×
12.5
10
×
16
10
×
16
12.5
×
20
16
×
25
16
×
25
16
×
31.5
φ
D
×
L (mm)
50
1H
6.3
×
11
6.3
×
11
6.3
×
11
8
×
11.5
10
×
12.5
10
×
16
10
×
20
12.5
×
20
12.5
×
25
16
×
31.5
6.3
8
·
10
12.5
·
16
ED
PD
HD
Please refer to page 20, 21, 22 about the formed or taped product spec.
Please refer to page 4 for the minimum order quantity.
CAT.8100B
