AN PA10
Power Amplifier Support Components
EVALUATION KIT
EK09 is an easy to use engineering platform for prototype
evaluation. Provided items include: PC boards to make a
five sided box, cage jacks and 200V ceramic bypass capaci-
tors. The top board has pads for two TO-3 packages and
one MO127 package. Two ends of the box are predrilled for
banana jacks and BNC connectors (not supplied). Amplifiers
and heatsinks are sold separately.
AN PA10
HEATSINKS
The following heatsinks are mechanically compatible with
this amplifier. Thermal ratings are for optimum mounting in
free air.
HS03 1.7°C/W
HS01 11.6°C/W
HS04 0.95°C/W
HS02 4.5°C/W
HS05 0.85°C/W
www.apexanalog.com
AN PA10U
Copyright © Apex Microtechnology, Inc. 2012
(All Rights Reserved)
NOV 2012
1
AN PA10U REVB
AN PA10
SOCKET
NOTES:
1. Base material is aluminum, 0.002” thick. Do not allow the
washer to touch pins of the amplifier.
2. For optimum thermal transfer, avoid abrasive handling of
washers which can damage their 0.5mil thick layer of thermal
compound with which each side is coated.
3. The dry thermal compound will flow filling header to heatsink
voids as soon as the material reached 60°C.
4. Do not store unused thermal washers above 40°C.
5. A new washer must be used for each mounting.
6. Part number TW03 consists of a package of 10 washers.
7. Thermal resistance is 0.1°C/W.
MS03
THERMAL WASHER
TW03
