DA0886: DescriptionGaAs 6 Section Attenuator; CategoryWireless rf/communication Radio frequency and microwave; File Size38KB，1 Pages; ManufacturerDAICO; Websitehttp://www.daico.com/

Download Datasheet Parametric View All

DA0886 Overview

GaAs 6 Section Attenuator

DA0886 Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	DAICO
package instruction	DIP24,.6
Reach Compliance Code	unknow
Nominal attenuation	63 dB
Characteristic impedance	50 Ω
structure	COMPONENT
Maximum input power (CW)	26.99 dBm
Maximum insertion loss	7.5 dB
JESD-609 code	e0
Installation features	THROUGH HOLE MOUNT
Number of terminals	24
Maximum operating frequency	1000 MHz
Minimum operating frequency	10 MHz
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Package body material	METAL
Encapsulate equivalent code	DIP24,.6
power supply	5 V
RF/Microwave Device Types	VARIABLE ATTENUATOR
Maximum slew rate	5 mA
surface mount	NO
technology	GAAS
Terminal surface	Tin/Lead (Sn/Pb)
Maximum voltage standing wave ratio	1.4

Preview

Download Datasheet

View All

FE ATU RE S

10 - 1000 MHz

1 mA, +5 VDC

1 dB LSB, 63 dB Range

34 nSec Switching Speed

15 nSec Transiton Time

TTL Control

24 Pin DIP

See DA0786 for Surface Mount Version

PART IDENTIFICATION

1.27

MODEL NO.

DA088 6

GaAs 6 Section Attenuator

6 BIT

RF

IN/OUT GND GND GND GND GND GND GND GND GND GND OUT/IN

24

23

22

21

20

19

18

17

16

15

14

13

•

.20

•

• • •

•

1.100

.100 TYP

.018±.002 DIA

24 PLACES

•

1

12

• •

6

2DB

"0"

7

4DB

"0"

8

9

10

11

12

8DB 16DB GND GND GND

"0"

.600

24

13

.77

1

+5V

2

3

4

5

GND GND 32DB 1DB

"0"

.xx = .02

.xxx = .010

CONTRASTING

COLOR BEAD

G U AR ANT EE D P E RF ORM ANCE

TYPI CAL PE RF O R MAN C E

at 25

°C

1.8

8

Parameter

Operating Frequency

DC Current

Control Type

Min Typ Max Units

10

1

TTL

1000

5

MHz

mA

Conditions

At +5 VDC Supply

6 Line

Logic “0” = Thru

Logic “1” = Attenuation

VIH = +3.0 V

VIL = +0.5 V

10 - 100 MHz

100 - 1000 MHz

1, 2, 4, 8, 16, 32

±

(0.25 dB +2% of Atten.

Setting in dB)

1.6

6

Control Current

Insertion Loss

High

Low

1.4

4

I. LOSS

Attenuation

LSB

Range

Accuracy

0

4.2

6.3

1

0

±40

5.5

7.5

63

µA

dB

1.2

2

VSWR

1.0

0

1

4

10

40

100

400

1000

3000

FREQUENCY (MHz)

VSWR

Impedance

Switching Speed

Transition (Rise/Fall) Time

Switching

(Video)

Transients

Intercept Points

2nd

3rd

RF Power

Operate

No Damage

1.2/1

50

34

15

280

+64

+44

+12

-55

+25

1.4/1

50

OHMS

nSec

mV

dBm

°C

50% TTL to 90% / 10% RF

90% / 10% or 10% / 90% RF

Peak Value

70 MHz / 50 MHz

35 MHz / 50 MHz

0.1 dB Compression

TA

Operating Temperature

+10

+27

+125

DA I C O

In d u s t r i e s

Rev. A / Iss. 2
