CONDUCTIVE POLYMER ALUMINUM SOLID ELECTROLYTIC CAPACITORS
RNU
High Capacitance
Low ESR, High Capacitance, High ripple current.
Load life of 2000/5000 hours at 105°C.
Radial lead type : Lead free flow soldering condition
correspondence.
Compliant to the RoHS directive (2011/65/EU).
RNS
Higher
Capacitance
RNU
Higher
Capacitance
Specifications
Item
Category Temperature Range
Rated Voltage Range
Rated Capacitance Range
Capacitance Tolerance
Tangent of loss angle (tan
δ)
ESR ( 1)
Leakage Current ( 2)
–55 to
+105°C
2.5 to 63V
10 to 2700µF
±20% at 120Hz, 20°C
RNE
Performance Characteristics
Less than or equal to the specified value at 120Hz, 20°C
Less than or equal to the specified value at 100kHz, 20°C
Less than or equal to the specified value.
Test condition
Capacitance change
After 2 minutes' application of rated voltage at 20°C
105°C, rated voltage 2000 / 5000Hrs.
Within ±20% of initial value before test
150% or less than the initial specified value
150% or less than the initial specified value
Less than or equal to the initial specified value
Endurance
tan
δ
ESR( 1)
Leakage current ( 2)
1 ESR should be measured at both of the terminal ends closest to the capacitor body.
2 Conditioning : If any doubt arises, measure the leakage current after the voltage treatment of applying DC rated voltage continuously to the capacitor for 120
minutes at 105°C.
Dimensions
Lot No.
Capacitance
Aluminum case
P
±0.5
φD
±0.5
MAX.
Stand off
Wire(Lead free)
Type numbering system (Example : 25V 390µF)
Nichicon part number
R NU 1 E 3 9 1 M D N A S Q CG
Lead Forming
Control code
1
2
3
4
5
6
7
8
9
10 11 12 13 14 15 16
FP5K
62Ae
391
25
φ
d
L+α
MAX.
15
MIN.
4
MIN.
Product Logo
Voltage
Configuration
Capacitance tolerance (±20%)
Rated capacitance (390µF)
Rated voltage (25V)
Series name
Type
(mm)
φD×L
4×5
6.3×10
8×11.5
10×12.5
φd
0.45
0.5
0.6
0.6
P
1.5
2.5
3.5
5.0
α
1.0
1.0
1.5
1.5
FPCAP part number
FP
025
RE
391
M
NU
CG
5K
Control code
Lead Forming
Frequency coefficient of rated ripple current
Frequency
Coefficient
120 Hz
0.10
1 kHz
0.45
10 kHz
0.50
100 kHz
1.00
300 kHz
1.00
Series name
Capacitance tolerance (±20%)
Capacitance (390µF)
Configuration
Voltage(25V)
Type
Dimension table in next page.
92
CONDUCTIVE POLYMER ALUMINUM SOLID ELECTROLYTIC CAPACITORS
RNU
2.5
(0E)
Standard Ratings
Rated
Capacitance
(µF)
Case Size
φD
×L
(mm)
tan
δ
Leakage
Current
(µA, 2min.)
Rated Ripple
ESR
Current
(m )
(mArms)
(20°C/100kHz) (105°C/100kHz)
7
5700
7
6100
Rated Voltage Surge
Voltage
(V)
(V)
(code)
NICHICON
FPCAP
2.8
1500
2700
820
1000
8×11.5
10×12.5
8×11.5
8×11.5
8×11.5
10×12.5
10×12.5
6.3×10
8×11.5
8×11.5
8×11.5
8×11.5
8×11.5
10×12.5
4×5
4×5
8×11.5
10×12.5
6.3×10
6.3×10
8×11.5
8×11.5
8×11.5
8×11.5
10×12.5
10×12.5
10×12.5
8×11.5
10×12.5
8×11.5
8×11.5
8×11.5
8×11.5
8×11.5
8×11.5
10×12.5
10×12.5
10×12.5
10×12.5
8×11.5
10×12.5
8×11.5
10×12.5
10×12.5
8×11.5
10×12.5
10×12.5
0.08
0.08
0.08
0.08
0.08
0.08
0.08
0.08
0.08
0.08
0.08
0.08
0.08
0.08
0.12
0.12
0.08
0.08
0.08
0.08
0.08
0.08
0.08
0.08
0.08
0.08
0.08
0.12
0.12
0.12
0.12
0.12
0.12
0.12
0.12
0.12
0.12
0.12
0.12
0.12
0.12
0.12
0.12
0.12
0.12
0.12
0.12
938
1350
656
800
960
1440
1760
277
592
857
1033
1260
1512
1890
300
300
1640
2400
320
320
576
864
864
1056
1504
1504
2176
1560
2720
413
588
850
900
1100
1100
1650
1650
1950
1950
329
1050
390
470
680
416
492
706
RNU0E152MDN1□□
RNU0E272MDN1□□
RNU0G821MDN1□□
RNU0G102MDN1□□
RNU0G122MDN1□□
RNU0G182MDN1□□
RNU0G222MDN1□□
RNU0J221MDS1□□
RNU0J471MDN1□□
RNU0J681MDN1□□
RNU0J821MDN1□□
RNU0J102MDN1□□
RNU0J122MDN1□□
RNU0J152MDN1□□
RNU1A100MDS1□□
RNU1A100MDSASQ□□
RNU1A821MDN1□□
RNU1A122MDN1□□
RNU1C101MDS1□□
RNU1C101MDSASQ□□
RNU1C181MDN1□□
RNU1C271MDN1□□
RNU1C271MDNASQ□□
RNU1C331MDN1□□
RNU1C471MDN1□□
RNU1C471MDNASQ□□
RNU1C681MDN1□□
RNU1D391MDN1□□
RNU1D681MDN1□□
RNU1E330MDN1□□
RNU1E470MDN1□□
RNU1E680MDN1□□
RNU1E181MDN1□□
RNU1E221MDN1□□
RNU1E221MDNASQ□□
RNU1E331MDN1□□
RNU1E331MDNASQ□□
RNU1E391MDN1□□
RNU1E391MDNASQ□□
RNU1V470MDN1□□
RNU1V151MDN1□□
RNU1H390MDN1□□
RNU1H470MDN1□□
RNU1H680MDN1□□
RNU1J330MDN1□□
RNU1J390MDN1□□
RNU1J560MDN1□□
FP-2R5RE152M-NU□□
FP-2R5RE272M-NU□□
FP-4R0RE821M-NU□□
FP-4R0RE102M-NU□□
FP-4R0RE122M-NU□□
FP-4R0RE182M-NU□□
FP-4R0RE222M-NU□□
FP-6R3RE221M-NU□□
FP-6R3RE471M-NU□□
FP-6R3RE681M-NU□□
FP-6R3RE821M-NU□□
FP-6R3RE102M-NU□□
FP-6R3RE122M-NU□□
FP-6R3RE152M-NU□□
FP-010RE100M-NU□□
FP-010RE100M-NU□□-5K
FP-010RE821M-NU□□
FP-010RE122M-NU□□
FP-016RE101M-NU□□
FP-016RE101M-NU□□-5K
FP-016RE181M-NU□□
FP-016RE271M-NU□□
FP-016RE271M-NU□□-5K
FP-016RE331M-NU□□
FP-016RE471M-NU□□
FP-016RE471M-NU□□-5K
FP-016RE681M-NU□□
FP-020RE391M-NU□□
FP-020RE681M-NU□□
FP-025RE330M-NU□□
FP-025RE470M-NU□□
FP-025RE680M-NU□□
FP-025RE181M-NU□□
FP-025RE221M-NU□□
FP-025RE221M-NU□□-5K
FP-025RE331M-NU□□
FP-025RE331M-NU□□-5K
FP-025RE391M-NU□□
FP-025RE391M-NU□□-5K
FP-035RE470M-NU□□
FP-035RE151M-NU□□
FP-050RE390M-NU□□
FP-050RE470M-NU□□
FP-050RE680M-NU□□
FP-063RE330M-NU□□
FP-063RE390M-NU□□
FP-063RE560M-NU□□
7
7
7
7
7
20
7
7
7
7
9
7
220
220
10
9
25
25
8
8
8
8
10
10
10
14
12
24
24
24
16
16
16
14
14
14
14
24
20
25
24
24
26
25
25
5700
5700
5700
6100
6100
3200
5700
5700
5700
5700
6100
6100
700
700
5800
6200
2820
2820
5700
5000
5000
6100
6100
6100
6100
4970
5400
3600
3600
3600
4650
4650
4650
5000
5000
5000
5000
3600
3800
2400
2700
2700
2300
2600
2600
4.0
(0G)
4.6
1200
1800
2200
220
470
680
6.3
(0J)
7.2
820
1000
1200
1500
10
10
(1A)
11.5
10
820
1200
100
100
180
270
16
(1C)
18.4
270
330
470
470
680
20
(1D)
23.0
390
680
33
47
68
180
25
(1E)
28.7
220
220
330
330
390
390
35
(1V)
50
(1H)
63
(1J)
40.2
47
150
39
47
68
33
57.5
72.5
39
56
: Load life 5000hours.
Frequency Characteristics
(The frequency characteristics are typical and not a guaranteed value.)
6.3V 470µF
6.3V 470
µF
Taping specifications are
given in page 26, 27.
Please refer to page 3 for
the minimum order
quantity.
Impedance
Frequency (kHz)
93
Frequency (kHz)
