1960 MHz Rx RF Filter
Data Sheet
Specifications
Parameter
Center Frequency
Maximum Insertion Loss (1930 - 1990 MHz): -30 to +85°C
Maximum Insertion Loss (1930 - 1990 MHz): +25°C
Passband Ripple (1930 - 1990 MHz): -30 to +85°C
Passband Ripple (1930 - 1990 MHz): +25°C
Absolute Attenuation: 10 - 1850 MHz
Absolute Attenuation: 1850 - 1910 MHz
Absolute Attenuation: 2040 - 2100 MHz
Absolute Attenuation: 2150 - 2210 MHz
Absolute Attenuation: 2210 - 4000 MHz
Input/Output Return Loss (1930 - 1990 MHz)
RF Power
Operating Temperature Range
Tape Information
Unit
MHz
dB
dB
dB p-p
dB p-p
dB
dB
dB
dB
dB
dB
dBm
°C
Minimum
-
-
-
-
-
20
12
25
20
15
7.4
-
-30
Typical
1960
2.1
2.1
0.3
0.4
22
27
26
24
25
11
-
25
Maximum
-
4.5
3.3
3.5
2.4
-
-
-
-
-
-
+13
+85
for PCS Applications
Part Number 855817
Schematic
• All dimensions in millimeters
Reel Information
• No matching required for 50Ω operation.
Package Outline
• Packaging quatity: 10,000 pcs / reel
Sawtek Inc.
Telephone: (407) 886-8860
• Ceramic surface mount package.
Fax: (407) 886-7061
Specifications subject to change or obsolescence without notice.
Page 2 of 2
