ECCOSORB®AN
Flexible Foam Sheet Broadband Microwave Absorber
FLEXIBLE FOAM SHEET BROADBAND MICROWAVE ABSORBER:
Eccosorb AN is a lightweight, flexible, polyurethane foam sheet broadband microwave absorber.
It is designed to reflect less than -17 dB of normal incident energy above specified frequencies and
relative to a metal plate.
FEATURES AND BENEFITS
•
•
•
•
Carbon loaded, multilayer absorber
Broadband free space absorber
Low weight
RoHS/Reach compliant
MARKETS
•
Commercial Telecom
•
Security and Defense
•
Test & Measurement
SPECIFICATIONS
TYPICAL PROPERTIES
Front surface color (facing oncoming EMI)
Back surface color
Max. Service Temperature °C (°F)
Power Handling, W/cm²
Fire Retardancy
ECCOSORB AN
White
Black
90 (194)
0.15
UL94-HBF
Data for design engineer guidance only. Observed performance varies in application.
Engineers are reminded to test the material in application.
APPLICATIONS
•
Eccosorb AN is commonly used for the lining of small test chambers to reduce reflections.
•
Eccosorb AN is being used for reducing crosstalk between adjacent antennas, shrouding
antennas to improve the antenna patterns and undesired backlobes, as well as selective
shadowing of parts of a target for RCS measurements.
•
Shadowing of posts and supports in anechoic chambers, and as absorbing blankets for testing
radar systems without harm to personnel.
•
For isolation of components or antennas by means of insertion loss, it can be used without a
metal backing.
AVAILABILITY
•
Eccosorb AN is available in six standard grades depending upon the lowest desired frequency of
operation, starting from 600 MHz.
•
Standard sheets are 61 cm X 61 cm (24” x 24”)
•
Eccosorb AN is available in other sizes and customer specified configurations, incorporating
miter cuts or attachment to metal parts.
•
It can be manufactured, on special order, on a mandrel, to take a contoured shape.
Americas: +1.866.928.8181
Europe: +49.(0).8031.2460.0
Asia: +86.755.2714.1166
www.lairdtech.com
Eccosorb® AN
Typical Reflectivity
0
-5
-10
Reflectivity (dB)
AN-72
AN-73
AN-74
AN-75
AN-77
AN-79
Reflectivity
range
(>17 dB)
AN-72
AN-73
AN-74
AN-75
>20 GHz
>7.5 GHz
>3.5 GHz
>2.4 GHz
>1.2 GHz
>600 MHz
Nominal
Thickness
cm (inch)
0.6 (0.24)
1.0 (0.39)
1.9 (0.75)
2.9 (1.14)
5.7 (2.24)
11.4 (4.49)
Nominal Weight
kg/piece (lb/piece )
0.25 (0.6)
0.50 (1.1)
0.70 (1.5)
0.80 (1.8)
1.50 (3.3)
2.95 (6.5)
-15
-20
-25
-30
0,5 0,9 1,1 1,5
2
4
6
8
10
12
14
16
18
Frequency (GHz)
AN-77
AN-79
ENVIRONMENTAL PROPERTIES
•
Eccosorb AN is not waterproof and will not operate correctly when wet. Since there is no
washout, it will function as expected after being allowed to dry.
•
A special CERSEAL coating to prevent moisture uptake in high humidity to moderately wet
environments is available on special request.
•
For high humidity to moderately wet environments, sealed versions of Eccosorb AN are
available. They are essentially the same material as Eccosorb AN but the absorber is sealed to
provide improved outdoor properties.
The available types are :
Eccosorb AN-xx-W :sealed with neoprene coated nylon fabric, color olive green.
Eccosorb AN-xx-WPC : sealed with a poly-urethane coating, different colors available on request
Eccosorb AN-xx-WPVC :sealed with a PVC plastic, different colors are available on request and
can be provided with eye-lets for fixing
•
Reflectivity performance is similar to the standard Eccosorb AN product;
INSTRUCTIONS FOR USE
•
To obtain low reflectivity, the absorbers must be mounted on a metal surface. If a metal surface
is not available, Eccosorb AN can be supplied metal backed with aluminum foil (ML).
•
For correct operation, Eccosorb AN must have the white (front) face towards the signal to be
attenuated.
•
Layering of multiple pieces or slicing off part of the thickness will degrade the overall
performance.
•
Reflectivity performance also degrades for off-normal bistatic incidence and at different rates
for different polarizations.
•
Eccosorb AN can be securely bonded to itself or to other materials such as metal, wood, and
common plastic composites. Our specific Eccostock® foam adhesive is recommended.
RFP-DS-AN 081215
